Product details
Powergear X Automation’s Insight
- The CEV58M-00167 is a cornerstone of the TR Electronic 58mm series, designed for high-speed synchronous automation.
- Integrating a robust Profibus-DP V0 interface, this absolute multi-turn encoder eliminates the need for homing cycles.
- Engineers prioritize the CEV58M-00167 for its incredible 33-bit total resolution and programmable gear functions.
- The ZB36 flange and radial connection design facilitate easy mechanical integration.
- It excels in environments requiring absolute position retention during power interruptions.
Core Engineering Specifications
- Brand: TR Electronic
- Model Key: CEV58M-00167
- Resolution: 8,192 steps per revolution (13-bit)
- Rotation Capacity: 4,096 total revolutions (12-bit)
- Data Interface: Profibus-DP (PNO Class 2 Profile)
- Baud Rate: High-speed 12 MBaud maximum support.
- Operating Voltage: 11 V DC to 27 V DC (24 V DC Nominal).
- Current Load: 120 mA typical (unloaded).
- Shaft Configuration: 10mm diameter with flat (10FL/19.5).
- Protection Rating: IP65 dust and water resistance.
- Temperature Tolerance: Standard -20 °C to +80 °C operation.
- Mechanical Lifecycle: Bearing life >= 3.9E+10 revolutions.
Ideal Equipment Integration
- Siemens Simatic: Full compatibility with S7 series PLCs via GSD files.
- Logistics Systems: Precise positioning for high-speed sorting lines.
- Metal Fabrication: Angle feedback for synchronized heavy-duty bending machines.
- Assembly Lines: Position monitoring for multi-axis indexing tables.
Diagnostic Capabilities & Maintenance
- Remote Configuration: Change resolution and velocity parameters via the fieldbus tool.
- Signal Integrity: RS485 differential output ensures stability in EMI-heavy zones.
- Mounting Stability: Supports up to 100N radial shaft load at the mounting point.
- Self-Monitoring: Integrated internal diagnostics for hardware status and transmission errors.
Global Logistics & Guarantee
- Dispatch Timeline: Fast 12-48 hour shipping for in-stock units.
- Courier Partners: International express via FedEx, UPS, or DHL.
- Quality Assurance: Standard 12-month comprehensive warranty included.
- Inquiries: Send requests to sales@powergearx.com.
- Support: Direct access via WhatsApp: +86 18030005825.
Expert FAQ & Selection Guide
What happens if the Profibus baud rate is set incorrectly for the CEV58M-00167?
- The encoder supports auto-detection. It will search and lock onto the network speed (up to 12 Mbit/s) automatically.
Can the CEV58M-00167 replace a Class 1 encoder?
- Yes, it is fully backward compatible with Class 1 while offering advanced Class 2 diagnostic features.
Is the 10mm shaft diameter strictly fixed?
- This specific CEV58M-00167 features a 10mm shaft. For 6mm or 12mm variants, please consult our technical team.
How do I handle the termination resistor on the last Profibus node?
- The termination must be activated in the final connector cap to ensure signal reflection is minimized.
Why choose the radial connector version over axial?
- Radial layout allows for a shallower installation depth, ideal for compact machine housings.
