The TM3DI32K is a digital input module from Schneider Electric. Moreover, it belongs to the Modicon TM3 series. In addition, it has 32 channels at 24 Vdc. Therefore, it saves space in high-density panels. Furthermore, it fits many Modicon PLCs.

Product Overview

• Model: TM3DI32K
• Brand: Schneider Electric
• Series: Modicon TM3
• Type: Digital input module, high density
• Lifecycle: Active (last verified 2026-09)

I/O Specifications Tree

• Channels
  • 32 inputs
• Signal
  • 24 Vdc, sink/source
  • Type 1 per IEC 61131-2
• Range
  • 24 Vdc nominal
  • 19.2 to 28.8 Vdc
• Input Current
  • 4 mA per channel at 24 Vdc
• Isolation
  • 500 V AC between input and internal logic
• Diagnostics
  • Module status
  • Bus status
• Response Time
  • 4 ms max turn on/off
• Wiring
  • Removable screw terminal block

Electrical Tree

• Supply Voltage
  • 24 Vdc via TM3 bus
• Bus Current
  • 70 mA at 5 V DC with all inputs on
  • 10 mA with all inputs off
• Power Consumption
  • Not available

Environmental Tree

• Operating Temperature
  • 0 to +55 °C
• Storage Temperature
  • -25 to +70 °C
• Protection Rating
  • IP20

Physical Tree

• Dimensions
  • 90 × 55.2 × 84.6 mm
  • 2-slot width
• Weight
  • 0.15 kg

Compatibility Tree

• Compatible Platforms
  • Modicon M221
  • Modicon M241
  • Modicon M251
  • Modicon M262
• Lifecycle
  • Active
  • Modicon TM3 expansion modules for M2xx/M340 PLCs
