SXDSZ32T2 Schneider TSX Micro 32-Point Discrete Output Module

TSXDSZ32T2 Schneider Electric Discrete Output Module for TSX Micro PLCs

• TSXDSZ32T2 is a discrete output module from Schneider Electric.
• It belongs to the TSX Micro PLCs series.
• Also, it works with the Modicon TSX Micro automation platform.
• The module drives 32 relay outputs at 24 VDC.
• Therefore, it suits many discrete control tasks.

Core Strengths

• High output count: 32 discrete points in one slot.
• Relay technology: handles mixed load types.
• Also, fast response: under 0.5 ms at state 0 and 1.
• Moreover, strong protection: zener diode and thermal breaker.
• Furthermore, reverse polarity protection guards the supply.
• Low power loss: only 3.2 W per module.
• As a result, panels stay cooler and last longer.

Technical Data

• Brand: Schneider Electric
• Model: TSXDSZ32T2
• Series: TSX Micro PLCs / Modicon TSX Micro automation platform
• Product name: Output Module
• Product type: Discrete output module
• EAN: 3389110738032
• Weight: 0.44 lbs (0.20 kg)
• Net weight: 0.42 kg
• Output type: Discrete
• Output technology: Relay
• Number of discrete outputs: 32 screw terminal block
• Discrete output voltage: 24 V DC
• Discrete output current: 0.5 mA
• Discrete output logic: Positive
• Output voltage limits: 19…30 V
• Output current limits: 0.625 A
• Maximum leakage current: 0.5 mA at state 0
• Residual voltage [Ures]: 0.3 V
• Load impedance ohmic: 48 Ohm
• Response time: under 0.5 ms at state 1
• Response time: under 0.5 ms at state 0
• Switching frequency: under 0.6/LI² Hz
• Output overvoltage protection: by zener diode
• Output short-circuit protection: thermal circuit breaker and current limiter
• Reverse polarity protection: reverse diode on power supply
• Paralleling of outputs: yes, 2 maximum
• Connection: screw terminal block
• Current consumption: 94 mA
• Power dissipation: 0.15 W per channel
• Power dissipation: 3.2 W per module
• Isolation voltage: 1500 V for 1 s
• Measurement range: not specified for this output module
• Frequency response: not specified for this output module
• Sensitivity: not specified for this output module
• Linearity: not specified for this output module
• Resolution: not specified for this output module
• Temperature range: see your TSX Micro rack limits
• Environmental tolerance: built for clean, dry control cabinets
• Anti-interference: 1500 V isolation and zener protection

Installation Guide

• First, check that your rack fits TSX Micro.
• Then, slide the module into a free slot.
• Next, wire loads with screw terminal blocks.
• Also, keep output cables away from signal wires.
• After that, confirm 24 VDC and 94 mA supply.
• Finally, test each output before full run.

Setup and Maintenance Convenience

• Screw terminals make wire checks fast.
• Also, 32 outputs cut the number of modules.
• Moreover, clear output count helps fault finding.
• Furthermore, low heat keeps cabinets cooler.
• Routine checks are enough for most sites.
• Therefore, keep spare fuses and relays on hand.

Compatibility Notes

• Works with TSX Micro PLCs racks.
• In addition, it suits 24 VDC relay loads.
• Also, it allows paralleling of 2 outputs.
• Moreover, it fits positive logic wiring.
• However, it needs a clean, dry panel.
• Therefore, check your load current before you buy.

Certifications and Compliance

• CE marking for European use.
• Also, it meets IEC industrial rules.
• Moreover, it carries marine approvals on request.
• Built by Schneider Electric, a trusted automation brand.

Package Contents

• 1 x TSXDSZ32T2 discrete output module
• 1 x Protective packaging
• 1 x Order documentation

Warranty and Shipping

• 12-month warranty covers manufacturing defects.
• Also, orders ship in 12-24 hours.
• Delivery by FedEx, UPS, or DHL.
• Moreover, tracking details come after dispatch.
• Contact sales@powergearx.com for order help.
• Or message +86 18030005825 on WhatsApp.

Expert Review

• The TSXDSZ32T2 is a strong pick for dense output panels.
• Its 32 relay outputs save rack space and cost.
• Also, 0.5 ms response keeps switching quick.
• Moreover, zener and thermal protection add safety.
• Furthermore, low 3.2 W loss cuts heat stress.
• However, it needs a stable 24 VDC supply.

Manager’s Insight

• This module sells well to panel builders and plant teams.
• Buyers often need many relay points in one slot.
• Therefore, stock it for TSX Micro users.
• Highlight the 12-month warranty and 12-24 hour dispatch.
• Also, mention screw terminals to build buyer trust.
• Finally, pair it with 24 VDC solenoids and lamps.

Best Fit Devices and Applications

• Solenoid and valve banks
• Indicator lamps and buzzers
• Relay and contactor coils
• Small motor starters
• Packaging and assembly lines
• Conveyor control panels
• Water treatment skids
• Factory retrofit projects

FAQ

• Q: How many outputs does the TSXDSZ32T2 offer?
  A: It offers 32 discrete relay outputs.
• Q: What voltage do the outputs use?
  A: They use 24 VDC with a 19 to 30 V range.
• Q: Can I parallel two outputs?
  A: Yes, you can parallel up to 2 outputs.
• Q: How fast does each output switch?
  A: It switches in under 0.5 ms.
• Q: What protects the module from shorts?
  A: A thermal breaker and current limiter protect it.
• Q: How do I pick the right output module?
  A: Match your load type, current, and rack series.
• Q: Do you offer a warranty?
  A: Yes, we offer a 12-month warranty.
• Q: How fast do you ship?
  A: We ship in 12-24 hours by FedEx, UPS, or DHL.
• Q: How do I reach your team?
  A: Email sales@powergearx.com or message +86 18030005825 on WhatsApp.

Buying Guide

• First, list your load types and current needs.
• Then, confirm your rack uses TSX Micro.
• Also, check that 24 VDC power is ready.
• After that, plan wiring for low noise.
• Moreover, keep spare screw terminals on hand.
• Finally, ask us for help before you order.
