Siemens 6ES7215-1AF40-0XB0 Safety CPU | 1215FC DC/DC/DC

Siemens 6ES7215-1AF40-0XB0 Safety CPU with Advanced Control Features

The Siemens 6ES7215-1AF40-0XB0 delivers superior safety and control performance. This advanced safety CPU combines comprehensive I/O with dual PROFINET ports. It offers reliable operation for demanding industrial automation applications with integrated safety functions.

Key Product Advantages

• 14 digital inputs and 10 digital outputs for flexible control
• 2 analog inputs and 2 analog outputs for precise measurement
• Dual PROFINET ports with integrated switch capability
• 250 KB work memory for complex safety programs
• Integrated safety functions up to SIL 3 and PL e
• Wide power supply range (20.4-28.8V DC)
• Compact design with extensive expansion options
• High-speed counters and pulse outputs

Technical Specifications

• Product Type: CPU 1215FC DC/DC/DC
• Firmware Version: V4.6
• Power Supply: 24V DC (20.4-28.8V range)
• Current Consumption: 500 mA (CPU only)
• Program Memory: 250 KB integrated work memory
• Data Memory: 4 MB load memory
• Digital Inputs: 14 channels, 24V DC
• Digital Outputs: 10 channels, 24V DC, 0.5A
• Analog Inputs: 2 channels, 0-10V DC, 10-bit
• Analog Outputs: 2 channels, 0-20 mA DC, 10-bit
• Communication: 2x PROFINET ports with switch
• Safety Rating: SIL 3, PL e (ISO 13849-1)
• Operating Temperature: 0°C to 55°C
• Dimensions: 130 x 100 x 75 mm (W x H x D)
• Weight: 500 grams
• Protection Class: IP20

Safety & Performance Features

• Integrated safety functions for machine protection
• High-speed outputs (100 kHz) for precise control
• Four pulse train outputs for motion applications
• Six high-speed counters for accurate measurement
• PROFIsafe support for safety communication
• Media redundancy (MRP) for network reliability
• OPC UA server for data access and monitoring
• Web server with user-defined web pages

Communication & Networking

• Dual Ethernet ports with integrated switch
• PROFINET IO controller and device support
• SIMATIC communication and S7 routing
• Open IE communication (TCP/IP, ISO-on-TCP, UDP)
• MODBUS protocol support
• Maximum 64 simultaneous connections
• TLS encryption for secure communication
• MRP client for network redundancy

Expansion Capabilities

• Up to 8 signal modules for I/O expansion
• 3 communication modules for network options
• 1 signal board for additional functions
• Support for safety expansion modules
• SIMATIC memory card for data storage
• Flexible configuration for various applications
• Easy integration with existing systems
• Scalable architecture for future growth

Industrial Durability

• Robust construction for industrial environments
• Vibration resistance: 2g for panel mounting
• Shock resistance: 15g peak acceleration
• High immunity to electromagnetic interference
• Compliance with international safety standards
• UL, cULus, FM, and KC certifications
• Suitable for harsh operating conditions
• Long-term reliability and performance

Package & Delivery Information

• Individual protective packaging
• Package dimensions: 13.90 x 10.80 x 8.50 cm
• Net weight: 0.415 kg per unit
• Fast worldwide shipping via FedEx, UPS, DHL
• Professional documentation included
• Manufactured in Germany
• Quality assurance and testing
• Ready for immediate installation

Professional Support & FAQ

• What safety certifications does this CPU have?
• The 6ES7215-1AF40-0XB0 achieves SIL 3 according to IEC 61508 and Performance Level e (PL e) according to ISO 13849-1 for maximum safety
• How many PROFINET ports are available?
• This safety CPU features two PROFINET ports with integrated switch functionality for flexible network configurations and daisy-chaining
• What expansion capabilities does it support?
• The system supports up to 8 signal modules, 3 communication modules, and 1 signal board for comprehensive system expansion
• Can it handle motion control applications?
• Yes, with four high-speed outputs (100 kHz) and support for up to 8 positioning axes, it’s suitable for various motion control tasks
• What programming software is required?
• STEP 7 V18 or higher TIA Portal with safety options is needed for programming both standard and safety functions
