Schneider Electric iC60N 2P C10 Acti9 Miniature Circuit Breaker 10A C-Curve

Product At a Glance

• Model BMXXBE1000 links X80 racks over the X-bus.
• It comes from Schneider Electric and the Modicon X80 line.
• This is a rack expansion module, not an I/O card.
• It joins many racks into one system.
• It fits the far right XBE slot.
• It works with M340 and M580 racks.

Why Choose It

• Free slots: It does not touch slots 00 to 11.
• Clean link: Two 9-pin SUB-D ports handle in and out.
• Clear view: RUN, COL, and address LEDs show state.
• Light body: Only 0.10 kg.
• Small face: Just 28 mm wide.
• Long life: The X80 family stays active.

Technical Data

• Brand: Schneider Electric
  • Model: BMXXBE1000
  • Series: Modicon X80
  • Type: X-bus expansion module
• Role:
  • Job: X-bus link between racks
  • Mount: Right-end XBE slot
  • Slots used: 1, outside 00-11
• Ports:
  • Count: 2
  • Style: 9-pin SUB-D
  • Use: X-bus in and out
• Lights:
  • RUN: run state
  • COL: collision state
  • Address: rack ID 0 to 3
• Climate:
  • Run: 0°C to +60°C
  • Store: -25°C to +70°C
  • Moisture: 5% to 95%, no condensation
  • Seal: IP20
• Body:
  • Size (H x W x D): 100 x 28 x 93 mm
  • Weight: 0.10 kg
• State: Active. Last checked 2026-09.

How to Fit It

• Find the XBE slot on the right end.
• Slide the unit in until it sits firm.
• Tighten the front screw.
• Plug the first SUB-D cable into the in port.
• Run the second cable from the out port to the next rack.
• Keep X-bus cable short and tidy.
• Set the rack address with the LEDs as your guide.

Run and Service

• Check RUN light on power up.
• Watch COL for bus clashes.
• Read the address LEDs to confirm rack ID.
• Log the address map in your file.
• Clean the face with a dry cloth.
• Do not unplug cables while live.
• Keep one spare for fast swap.

Works With

• Modicon M340 racks
• Modicon M580 racks
• X80 power supplies and racks
• X-bus 9-pin SUB-D cable sets
• Not for Quantum or Premium racks

Marks and Rules

• CE, UL, and RoHS marks are typical here.
• Ask us for the exact file with your order.
• Follow local cabinet and wiring codes.

What You Get

• 1 x Schneider Electric BMXXBE1000
• 1 x start leaflet
• Sealed factory box

Cover and Delivery

• Warranty: 12 months
• Pick time: 12 to 24 hours
• Couriers: FedEx, UPS, DHL
• Track link sent at dispatch.
• Write to sales@powergearx.com for stock.
• Reach us on +86 18030005825 for help.

Expert Review

• This is the part that grows an X80 system.
• It keeps every I/O slot free for real cards.
• Wiring is simple with two SUB-D links.
• The LEDs take the guesswork out of bus faults.
• The one limit is clear: IP20, so keep it in a cabinet.

Manager’s Insight

• Buy this when one rack is not enough.
• It spreads I/O across the plant and cuts cable runs.
• Hold a spare to keep lines up.
• Fast pickup keeps downtime low.
• 12-month cover gives peace of mind.

Best Use Cases

• Large factory lines with many racks
• Water and waste plants
• Power and energy sites
• Oil and gas process units
• Food and drink plants
• Steel and cement mills

Buying Guide

• Count your racks before you buy.
• Check that each rack has an XBE slot.
• Order the right SUB-D cable length.
• Plan rack addresses up front.
• Ask for date code and firmware.
• Mail sales@powergearx.com for a quote.

FAQ

• Q: Does it use a normal I/O slot?
  A: No. It sits in the XBE slot on the right end.
• Q: How many racks can I link?
  A: That depends on your CPU and bus rules. Check the manual.
• Q: Why is the COL light on?
  A: Two racks likely share the same address.
• Q: Can I use a long cable?
  A: Keep it short. Long runs raise bus errors.
• Q: Do I need a terminator?
  A: Follow the X80 rules for the last rack.
• Q: What is the warranty?
  A: 12 months from the ship date.

Contact

• Email: sales@powergearx.com
• WhatsApp: +86 18030005825
• Site: https://www.powergearx.com/
