Name: RECA-01 ABB EtherCAT Adapter Single Port 3ABD0000045102 Drive Module
SKU: RECA-01
Price: 277.00 USD
Availability: InStock

Product details

Product Overview

RECA-01 is a single-port EtherCAT adapter from ABB. It plugs into the option slot on the drive control board. This module adds fast, reliable EtherCAT connectivity to compatible drives. It is built for industrial automation systems that need simple integration and stable communication.

The adapter uses a 34-pin parallel bus connector and two RJ-45 ports (X1 and X2). It draws about 290 mA at 5 V from the drive board. The estimated minimum lifetime is 100,000 hours. All materials are UL/CSA approved. It meets EMC standards EN 50081-2 and EN 50082-2.

For inquiries, contact sales@powergearx.com or +86 18030005825.

Technical Data

Brand: ABB
Model: RECA-01
Product ID: 3ABD0000045102
Type: EtherCAT adapter, single port
Net weight: 0.5 kg
Net dimensions (D x H x W): 15.5 cm x 5.2 cm x 22.5 cm
Mounting: Into an option slot on the drive control board
Degree of protection: IP20
Ambient conditions: Follow the drive hardware manual
Settings: Through drive parameters
Connectors: 34-pin parallel bus connector; 2 RJ-45 connectors (X1 and X2)
Current consumption: 290 mA average at 5 V, supplied by the drive control board
Estimated min. lifetime: 100,000 h
Approvals: All materials UL/CSA approved
EMC compliance: EN 50081-2 and EN 50082-2
EtherCAT link: All EtherCAT compliant devices
Medium: 100 base TX
Termination: Internal
Wiring: CAT 5 UTP, CAT 5 FTP (recommended), or CAT 5 STP (recommended)
Connector: RJ-45
Maximum segment length: 100 m
Serial communication type: Full duplex
Transfer rate: 100 Mbit/s
Protocol: EtherCAT

Installation Guide

Power down the drive before you start.
Open the option slot on the drive control board.
Insert the RECA-01 module into the slot.
Secure the module in place.
Connect EtherCAT cables to X1 and X2.
Use CAT 5 FTP or STP cable for best results.
Keep cable runs under 100 m per segment.
Power up the drive and set parameters as needed.
Check link status on both RJ-45 ports.

Commissioning and Maintenance

Configure the adapter through drive parameters.
No special software is required for basic setup.
Internal termination reduces wiring work.
The module needs no routine maintenance.
Check connectors for dust or damage during service.
Keep the drive enclosure closed to maintain IP20 protection.
Follow the drive manual for ambient limits.
Use standard EtherCAT tools for diagnostics.

Compatibility Notes

Works with all EtherCAT compliant devices.
Fits ABB drive option slots as specified.
Uses standard CAT 5 cabling.
Supports full duplex 100 Mbit/s links.
Designed for ABB drive control boards with option slots.
Check your drive model before you order.

Certifications and Standards

Materials are UL/CSA approved.
EMC: EN 50081-2 and EN 50082-2.
EtherCAT compliant link.
IP20 rated when installed correctly.

Package Contents and Warranty

1 x ABB RECA-01 EtherCAT adapter module
1 x quick reference note (if included by supplier)
12-month warranty from the seller
Dispatch in 12 to 24 hours
Shipping by FedEx, UPS, or DHL
Track and confirm delivery with the carrier

Expert Review

The RECA-01 is a simple, focused module. It does one job well: it adds EtherCAT to ABB drives. Installation is quick. The internal termination saves time. The 100 Mbit/s link is fast enough for most motion and control tasks. The 100,000-hour lifetime estimate is a strong point. The IP20 rating means it belongs inside a cabinet. Buyers should confirm the drive slot type first. For teams already using EtherCAT, this adapter keeps wiring simple and familiar.

Manager’s Insight

This adapter suits system integrators who need fast delivery and a known brand. It avoids complex setup. Stock is available. Orders ship in 12 to 24 hours by FedEx, UPS, or DHL. The 12-month warranty covers the module. Use it in drive cabinets, not in wet or dusty open areas. It works best in standard industrial control rooms.

Ideal Devices and Applications

ABB drives with option slots
EtherCAT motion control networks
Factory automation cells
Packaging and material handling lines
Machine tools and production equipment
Systems that need a short segment length of 100 m or less
Control cabinets with IP20 protection

FAQ

Q: What is the main function of the RECA-01?
A: It adds a single EtherCAT port to an ABB drive through the option slot.

Q: Does it work with non-ABB EtherCAT devices?
A: Yes, it works with all EtherCAT compliant devices on the network.

Q: How fast is the data link?
A: The link runs at 100 Mbit/s with full duplex.

Q: What cable should I use?
A: Use CAT 5 FTP or STP for best results. CAT 5 UTP also works.

Q: What is the maximum cable length?
A: Keep each segment at 100 m or less.

Q: How do I configure the module?
A: Set it through the drive parameters. No extra software is needed.

Q: What is the current draw?
A: It draws about 290 mA at 5 V from the drive board.

Q: How long does it last?
A: The estimated minimum lifetime is 100,000 hours.

Q: What is the protection rating?
A: IP20. Keep it inside a control cabinet.

Q: How fast is shipping?
A: Orders dispatch in 12 to 24 hours by FedEx, UPS, or DHL.

Q: What warranty do I get?
A: A 12-month warranty from the seller.

Q: How do I choose the right adapter?
A: Check your drive model and option slot type first. Then confirm you need one EtherCAT port. If you need more ports or other protocols, choose a different module.

Q: Can I install it myself?
A: Yes, if you follow the drive manual. Power down first. Insert the module into the slot. Connect the cables. Then power up and set parameters.
