Bently Nevada Long-Reach Vibration Probe
Introducing the Bently Nevada 330901-00-18-70-02-CN. This NSv series proximity probe features a long 7-meter cable. It is perfect for installations where the monitoring system is far from the measurement point.
Model Code Explained
- Product Family: 330901 (NSv Probe, 1/4-28 UNF Thread)
- Configuration Breakdown:
- -00: Unthreaded Length = 0.0 inch (Fully Threaded)
- -18: Overall Case Length = 1.8 inches
- -70: Total Cable Length = 7.0 meters (23 feet)
- -02: Connector Type = Standard ClickLoc
- -CN: Agency Approval = Country Specific
Product Specifications
- Complete Model: 330901-00-18-70-02-CN
- Series: 3300 NSv Proximity Probes
- Origin: Made in U.S.A.
- Mounting Thread: 1/4-28 UNF
- Probe Resistance: 5.9 Ω (± 0.9 Ω) for 7m cable
- Cable Specification: 75 Ω Coaxial with FEP Insulation
- Materials: AISI 304 SST Case, PPS Tip
- Temperature Rating: -52°C to +177°C Operating
- Installation Torque: Recommended 11.3 N•m (100 in-lb)
- Max Thread Engagement: 0.563 inch
- Seal: Viton O-Ring for Pressure Differential
- Weight: Approx. 14 to 150 grams
FAQ: Expert Insights
Product Features & Use
- Why would I need a 7-meter cable on my probe?
- A long cable is essential when the transducer or monitoring rack is located far from the machine. It eliminates the need for intermediate junction boxes and long field wiring runs.
Technical Specifications
- The probe resistance is higher for this 7m model. Is this a problem?
- No. The system is designed to account for cable length. The specified resistance (5.9Ω ±0.9Ω) is correct for the 7m cable and is compatible with Bently Nevada monitors when properly configured.
- What does “Country Specific (CN)” approval mean?
- This indicates the probe meets specific certification requirements for certain countries or regions. Contact us with your location to confirm compliance for your project.
Installation & Ordering
- How do I manage such a long cable during installation?
- Carefully coil the excess cable in a protected location. Use cable ties loosely. Avoid sharp bends and ensure the cable is not pinched or stretched.
- What are my purchase options and support?
- This 330901-00-18-70-02-CN probe is in stock. It comes with a 12-month quality warranty. We offer express global shipping via UPS, FedEx, and DHL.
Choosing This Model
Select the 330901-00-18-70-02-CN when you need a long 7m cable with a compact 1.8-inch body. Its UNF thread suits many industrial applications. Verify your country’s certification requirements before ordering.
