Name: Bently Nevada 330901-00-09-70-02-05 Probe | 7m Cable, Hazardous Area Approved, 1/4-28 UNF
SKU: 330901-00-09-70-02-05
Availability: InStock

Product details

Long-Reach Hazardous Area Vibration Probe

This is the Bently Nevada 330901-00-09-70-02-05. It is a long-cable proximity probe from the 3300 NSv series. It has a 7.0-meter cable for remote sensor placement. The probe carries major safety certifications for hazardous locations. Its 1/4-28 UNF thread is a common industrial standard. This model is made in the USA.

Key Advantages

Long Cable Run: 7.0 meters allows flexible installation over longer distances.
Safety Certified: Approved for use in hazardous areas (CSA, ATEX, IECEx).
Industrial Standard: 1/4-28 UNF thread fits a wide range of mounting points.
Robust Construction: Stainless steel body and PPS tip handle tough conditions.
Trusted Brand: Genuine Bently Nevada product for reliable performance.

Understanding Your Model Number

330901 – 3300 NSv Probe, 1/4-28 UNF Thread
00 – Unthreaded Section: 0.0 inches
09 – Case Length: 0.9 inches
70 – Total Cable: 7.0 meters
02 – Connector: Miniature ClickLoc
05 – Approvals: CSA, ATEX, IECEx (Multiple)

Product Specifications

Product: Bently Nevada 330901-00-09-70-02-05
Type: 3300 NSv Proximity Probe
Cable: 7.0m, 75 Ω coaxial with FEP insulation
Resistance (RPROBE): 5.9 Ω ± 0.9 Ω
Thread: 1/4-28 UNF (Max engagement: 0.563 in)
Torque: Max 33.9 N•m, Recommend 11.3 N•m
Case: AISI 304 Stainless Steel
Tip: PPS (Polyphenylene Sulfide)
Seal: Viton O-ring
Temperature: -52°C to +177°C (Operate & Store)
Approvals: CSA, ATEX, IECEx (Option 05)

Installation & Use Guide

Install using the recommended torque value to avoid damage.
Do not expose the probe to long periods below -34°C to protect the seal.
This model is certified for hazardous areas. Follow all relevant safety codes.
Connect to a compatible 3300 NSv or specified monitor system.

Frequently Asked Questions (FAQ)

Certification & Use

Q: What does the “05” suffix mean for this probe?
A: The “05” means this 330901 probe has multiple agency approvals. It is certified by CSA, ATEX, and IECEx. You can use it in classified hazardous areas when installed correctly.

Q: Can I use this 7m probe in a standard 5m system?
A: You must check your system compatibility. The longer 7m cable affects the probe’s electrical characteristics (resistance is 5.9Ω). Ensure your monitor or proximitor is calibrated or rated for use with a 7-meter probe.

Selection & Service

Q: Why choose a 7-meter probe over a shorter one?
A: Choose a 7m probe when the monitoring equipment is far from the measurement point. It reduces the need for extension cables. This simplifies wiring in large machinery or complex installations.

Q: What is your warranty and shipping policy?
A: We provide a full 12-month warranty on this product. We ship orders promptly using reliable carriers like FedEx, UPS, and DHL to ensure fast delivery.

Q: The probe is not pressure tested. Is it safe for pressurized applications?
A: The probe has a Viton O-ring seal designed for differential pressure. However, Bently Nevada does not test each unit before shipping. For high-pressure or safety-critical applications, you should conduct your own tests or consult their custom department.
