iC60N 2P C63 Schneider Acti9 Miniature Circuit Breaker 63A C-Curve 6kA MCB

Product Overview

• • Model BMXXBC015K is a Modicon X80 X-bus expansion cable.
  • It connects multiple racks in a daisy-chain setup.
  • This cable supports shared I/O for M340 and M580 platforms.

Product Overview

• • • iC60N 2P C63 is a miniature circuit breaker.
    • Brand: Schneider Electric. Series: Acti9 iC60.
    • It has 2 poles and a 63A rating.
    • The trip curve is C. Magnetic trip at 8×In ±20%.
    • Breaking capacity: 6 kA at 230/400V.
    • Lifecycle: Active in the Acti9 range.

Electrical Specifications

• • • Poles
      • 2P
    • Rated current
      • 63A
    • Trip curve
      • C curve
      • Thermal-magnetic
      • Magnetic trip 8×In ±20%
    • Breaking capacity
      • 6 kA @ 230/400V
      • IEC 60898-1
    • Rated voltage
      • 400V AC
      • 125V DC

Standards and Certifications

• • • Standards
      • EN/IEC 60898-1
      • EN/IEC 60947-2

Environmental Data

• • • Operating temperature
      • -35 to 70 °C

Physical Data

• • • Mounting
      • 35 mm DIN rail
    • Mechanical life
      • 20,000 cycles
    • Electrical life
      • 10,000 cycles
    • Dimensions
      • 85 × 36 × 78.5 mm (H×W×D)
    • Weight
      • 0.25 kg

Manager’s Insight

• • • This breaker fits many small power circuits.
    • The C curve handles motor and inductive loads.
    • 6 kA covers most commercial and light industrial panels.
    • It is easy to install on standard DIN rail.
    • Good choice for panel builders who need fast stock.

Best Use Cases

• • • Lighting and socket circuits
    • Small motors and pumps
    • HVAC control panels
    • Commercial distribution boards
    • Light industrial machines
    • DC control circuits up to 125V

Expert Review

• • • The iC60N 2P C63 is a solid, no-fuss MCB.
    • Build quality is typical of Schneider Acti9 gear.
    • Installation is quick on 35 mm rail.
    • Contacts feel firm and snap in cleanly.
    • Users should check load type before choosing C curve.
    • It is not a substitute for a main breaker.

FAQ

• • • Q: What does the C curve mean?
      A: It trips at 5 to 10 times the rated current.
    • Q: Can I use it for a motor?
      A: Yes, if the motor current stays within 63A.
    • Q: Does it work on DC?
      A: Yes, up to 125V DC.
    • Q: How many poles does it have?
      A: It has two poles.
    • Q: What is the warranty?
      A: It comes with a 12-month warranty.
    • Q: How fast is shipping?
      A: Orders leave in 12-24 hours.
    • Q: Which couriers do you use?
      A: We ship by FedEx, UPS, and DHL.
    • Q: Is it in production?
      A: Yes, the Acti9 range is active.
    • Q: Can I mount it sideways?
      A: Follow the datasheet for orientation rules.
    • Q: How do I pick the right rating?
      A: Match the breaker to your cable and load size.

Buying Guide

• • • Check your panel voltage before ordering.
    • Pick 63A only if your wiring supports it.
    • Use C curve for motors and transformers.
    • Use B curve for pure resistive loads.
    • Buy extra units for future panel changes.
    • Confirm DIN rail space: 36 mm wide.
    • Ask about bulk pricing for projects.
    • Email sales@powergearx.com for stock.
    • Or chat on WhatsApp: +86 18030005825.

Order and Support

• • • Inquiries: sales@powergearx.com
    • WhatsApp: +86 18030005825
    • Ships in 12-24 hours via FedEx, UPS, DHL.
    • Warranty: 12 months.
