FX2N-16MT-001 Mitsubishi PLC | FX2N Series Transistor Output 16 I/O Controller

FX2N-16MT-001 – Mitsubishi FX2N Series Micro PLC (8 Inputs / 8 Transistor Outputs)

FX2N-16MT-001 is a high-speed transistor output PLC from Mitsubishi FX2N series. It features 16 built-in I/O points, fast processing, and built-in positioning functions for precise machine control.

Controller Architecture & Core Specifications

• Mitsubishi FX2N Series – High-Performance Micro PLC Platform
  • Model: FX2N-16MT-001 – Main Unit (Transistor Output)
    • Power Supply
      • ▪ Supply voltage: 100-240V AC
      • ▪ Power consumption: 20W
      • ▪ DC5V internal power capacity: 900mA
      • ▪ DC24V service power supply: 400mA
    • I/O Configuration
      • ▪ Total I/O points: 16 (built-in)
      • ▪ Input points: 8 (DC input, sink/source)
      • ▪ Output points: 8 (transistor type, source)
      • ▪ Expandable up to 256 I/O points
    • Memory & Processing Speed
      • ▪ Built-in RAM: 8K steps (expandable to 16K)
      • ▪ CPU speed: 0.08 µs per basic instruction
      • ▪ Application instruction: 0.5 µs
      • ▪ High-speed execution for complex logic
    • Built-in Positioning
      • ▪ 2 axes independent positioning
      • ▪ Max output frequency: 20kHz
      • ▪ Perfect for motion control applications
    • Physical Dimensions
      • ▪ Size (WxHxD): 130 x 90 x 87 mm
      • ▪ Weight: 0.6 kg

Expandability & System Integration

• Expansion Capability
  • ▪ Control range: 16 to 256 I/O points
  • ▪ Connect I/O expansion modules on right side
  • ▪ Support special function modules (analog, temperature, positioning)
  • ▪ Quick-disconnect terminal block for easy maintenance
• Communication Features
  • ▪ Full communication function set
  • ▪ Suitable for global applications
  • ▪ Supports various network options
• Memory Options
  • ▪ Built-in RAM: 8K steps standard
  • ▪ Expandable to 16K steps with memory cartridge
  • ▪ EEPROM memory cartridge with program transfer

Advanced Features & Compatibility

• High-Speed Operation
  • ▪ Basic instruction: 0.21 µs/instruction
  • ▪ Application instruction: 0.5 µs/instruction
  • ▪ Large capacity memory: 32000 steps built-in
• Flexible Expansion Options
  • ▪ Special adapters and function expansion boards
  • ▪ Compatible with FX3 series expansion modules
  • ▪ High-speed system bus for intelligent functions
• Wiring & Maintenance
  • ▪ Quick-disconnect terminal block
  • ▪ Easy cable replacement without rewiring
  • ▪ Excellent maintainability for field service

Expert Review & Manager’s Insight

• Field Engineer Perspective
  • ▪ “FX2N-16MT-001 is ideal for high-speed positioning. The 20kHz output handles stepper and servo drives perfectly. Fast 0.08µs processing keeps up with demanding applications.”
  • ▪ “Quick-disconnect terminal block saves hours during maintenance. Swap the unit without touching wires.”
• Product Manager Insight
  • ▪ “This PLC offers excellent value with built-in 2-axis positioning. Expandable to 256 I/O makes it versatile for growing systems.”
  • ▪ “Transistor outputs provide fast switching for motion control. Perfect for packaging machines, pick-and-place, and labeling equipment.”

Suitable Devices & Application Scenarios

• Typical Applications
  • ▪ High-speed packaging machines – fillers, sealers, cartoners
  • ▪ Pick-and-place systems and assembly robots
  • ▪ Labeling machines and printing equipment
  • ▪ Small CNC machines and positioning tables
  • ▪ Conveyor systems with servo control
• Compatible Equipment
  • ▪ Stepper motors and servo drives
  • ▪ Sensors: encoders, proximity switches, photoelectric sensors
  • ▪ HMI: Mitsubishi GOT series touch panels
  • ▪ Drives: Mitsubishi inverters via communication
  • ▪ Expansion modules: analog, temperature, positioning, high-speed counter

Frequently Asked Questions (FAQ)

• What does MT in FX2N-16MT-001 mean?
  MT means transistor output type. This model has 8 transistor outputs (source type). Transistor outputs switch faster than relays. They are ideal for high-speed positioning and PWM control.
• What is the maximum I/O expansion?
  Local expansion supports up to 256 I/O points. Add I/O expansion modules and special function modules on the right side. Memory can expand from 8K to 16K steps.
• Does this PLC support positioning control?
  Yes. Built-in 2-axis independent positioning with 20kHz max output frequency. Works with stepper motors and servo drives. No extra positioning module needed for basic motion.
• Experience-based: How fast is program execution?
  Basic instructions run at 0.08 µs. This is very fast for a micro PLC. Good for applications needing quick response like high-speed counting and positioning.
• Buying guide: Warranty and shipping details?
  12 months warranty from shipment date. 12-24 hour dispatch on business days. Express delivery via FedEx, UPS, DHL with tracking. Contact us for volume pricing.

• Which PLC fits my needs: FX2N-16MT or FX3U?
  FX2N-16MT offers proven reliability with built-in 20kHz positioning. FX3U is newer with faster speed (0.08µs vs 0.21µs) and USB port. Choose FX2N for cost-effective motion control applications.

Contact & Order Support

• ▪ Email: sales@powergearx.com for quotes and technical questions
• ▪ WhatsApp: +86 18030005825 – fast response within 24 hours
• ▪ Shipping: FedEx, UPS, DHL express – 12-24h dispatch, worldwide tracking included
