FR-D720S-0.75K-CHT Mitsubishi FR-D700 Inverter 0.75kW Single-Phase

FR-D720S-0.75K-CHT | Mitsubishi Electric | FD7200 Inverter

Description

• The FR-D720S-0.75K-CHT is a compact and reliable inverter from Mitsubishi Electric.
• It belongs to the FR-D700 series and drives motors up to 0.75 kW.
• This single-phase 200–240V input unit delivers three-phase output for small automation tasks.
• Well-suited for conveyors, pumps, fans, and simple machine tools.
• Built with IP20 protection and self-cooling design for easy panel mounting.
• Lightweight at 1.1 kg, it saves space and simplifies installation.

Technical Data

• Brand: Mitsubishi Electric
• Model: FR-D720S-0.75K-CHT
• Series: FR-D700
• Module Type: Inverter
• Applicable Motor Capacity: 0.75 kW
• Rated Current: 4.2 A
• Overload Current Rating: 150% for 60s, 200% for 0.5s (inverse-time characteristics)
• Output Voltage: Three-phase 200 to 240V
• Input Voltage/Frequency: Single-phase 200 to 240V, 50Hz/60Hz
• Power Supply Capacity: 2.3 kVA
• Protective Structure: Enclosed type (IP20) per JEM1030
• Cooling System: Self-cooling
• Weight: 1.1 kg
• Measurement Range: 0 to 240V AC
• Frequency Response: 0.2 to 400 Hz
• Sensitivity: 0.1% of full scale
• Linearity: ±0.5%
• Resolution: 0.01 Hz
• Temperature Range: -10°C to 50°C (non-condensing)
• Environmental Tolerance: 90% RH max, indoor use
• Noise Immunity: Meets IEC 61800-3

Installation Guide

• Mount the inverter on a vertical surface inside a control panel.
• Keep at least 10 cm clearance on top and bottom for airflow.
• Use single-phase 200–240V supply on the input terminals.
• Connect the three-phase motor to the output terminals U, V, W.
• Tighten terminal screws to the torque specified in the manual.
• Ground the unit properly to reduce electrical noise.

Commissioning and Maintenance Ease

• Parameter setting is simple via the built-in operation panel.
• Auto-tuning helps match the inverter to the motor quickly.
• Fault codes appear on the display for fast troubleshooting.
• Regularly check cooling fins and clean dust to maintain airflow.
• No routine lubrication or part replacement is needed.

Compatibility Notes

• Works with standard three-phase induction motors up to 0.75 kW.
• Compatible with Mitsubishi FR Configurator software for setup.
• Can be used with PLCs and sensors via analog or digital I/O.
• Not designed for single-phase motors or high-frequency spindles.

Certifications

• CE marked for European conformity.
• UL listed for safety in North America.
• RoHS compliant for restricted substances.
• Meets JEM1030 enclosure standard.

Packing List

• 1 x FR-D720S-0.75K-CHT inverter
• 1 x Instruction manual (English)
• 1 x Safety warning sheet
• 1 x Terminal cover (pre-installed)

Warranty and Shipping

• Warranty: 12 months from delivery date.
• Dispatch: Ships within 12 to 24 hours after payment.
• Couriers: FedEx, UPS, DHL available.
• Tracking number provided once the parcel leaves our warehouse.

Expert Review

• The FR-D720S-0.75K-CHT offers a solid balance of size, cost, and reliability.
• Its single-phase input makes it ideal for small workshops or retrofit jobs.
• The 150% overload for 60s handles brief load spikes without tripping.
• IP20 rating means it must sit inside a clean cabinet.
• Setup is straightforward for technicians familiar with Mitsubishi drives.
• For 0.75 kW pumps and fans, this model is a practical choice.

Manager’s Insight

• This inverter fills a niche for low-power, single-phase applications.
• Customers often choose it for packaging machines and small mixers.
• Stock levels are stable, and lead times are short.
• Pair it with a line reactor if the supply is noisy.
• It is not a servo drive, so avoid position control tasks.

Best Applications and Equipment

• Small conveyors and belt feeders.
• Centrifugal pumps up to 0.75 kW.
• Low-power fans and blowers.
• Simple winding and rewinding machines.
• Bench-top test rigs and educational kits.
• Woodworking and light metal cutting tools.

FAQ

• Q: Can this inverter run a 1.5 kW motor?
  A: No. The maximum motor capacity is 0.75 kW.
• Q: What is the input phase?
  A: It accepts single-phase 200–240V.
• Q: Does it come with a braking resistor?
  A: No. You can add an external braking resistor if needed.
• Q: How do I reset a fault?
  A: Press the stop/reset key on the panel or cycle power.
• Q: Is this drive suitable for a CNC spindle?
  A: Not really. It lacks the high-speed and positioning features of a spindle drive.
• Q: What wire size should I use?
  A: 1.5 mm² to 2.5 mm² copper wire is typical for this power level.
• Q: Can I mount it sideways?
  A: No. Keep it vertical for proper cooling.
• Q: Does it support Modbus?
  A: No built-in Modbus. Use optional communication cards if needed.
• Q: How do I choose between this and a 1.5 kW model?
  A: Match the inverter to your motor kW. For 0.75 kW, choose this unit.
• Q: What if the motor runs in reverse?
  A: Swap any two output wires (U, V, W) or change the direction parameter.

Buying Guide

• Check your motor nameplate for kW and current first.
• Confirm your supply is single-phase 200–240V.
• Decide if you need a keypad or remote operation.
• Allow space for heat dissipation inside the panel.
• Order a braking resistor only if your load needs fast stops.
• Keep a spare unit if downtime is costly.
• Contact us for bulk pricing or technical questions.
