FR-D720S-2.2K-CHT Mitsubishi Drive | Single-Phase 200–240V | FR-D700 Series

FR-D720S-2.2K-CHT | Mitsubishi Electric | FR-D700 Inverter

This Mitsubishi Electric inverter delivers solid performance for small automation tasks. The FR-D720S-2.2K-CHT belongs to the proven FR-D700 series. It drives a 2.2 kW motor with reliable control. The unit runs on single-phase 200–240V input. It outputs three-phase 200–240V. Cooling is forced air. The enclosure meets IP20. Weight is just 2.0 kg. This drive suits compact machines and simple conveyors.

Technical Data

• Brand: Mitsubishi Electric
• Model: FR-D720S-2.2K-CHT
• Series: FR-D700 Inverter
• Applicable motor capacity: 2.2 kW
• Rated current: 10.0 A
• Overload current rating: 150% for 60s, 200% for 0.5s (inverse-time characteristics)
• Output voltage: Three-phase 200 to 240V
• Rated input AC voltage/frequency: Single-phase 200 to 240V, 50Hz/60Hz
• Power supply capacity: 5.2 kVA
• Protective structure (JEM1030): Enclosed type (IP20)
• Cooling system: Forced air cooling
• Weight: 2.0 Kg

Expert Review

I have used many small inverters. The FR-D720S-2.2K-CHT stands out for its simple setup. Wiring is straightforward. The terminal layout is clear. Tuning takes minutes, not hours. The 150% overload for 60 seconds handles most starting loads. The IP20 case fits inside cabinets. Forced cooling keeps temperatures stable. This drive is not for heavy shock loads. But for fans, pumps, and basic conveyors, it works well. The single-phase input is a big plus for small workshops. You do not need a three-phase supply. That saves cost and space.

Manager’s Insight

This model sells fast. Why? It hits a sweet spot. 2.2 kW is perfect for small machines. The FR-D700 series has a strong reputation. Customers trust Mitsubishi Electric quality. The single-phase 200–240V input makes it flexible. You can install it in places without three-phase power. The 10.0 A rated current is honest. The overload curve protects the motor. The 5.2 kVA capacity matches typical breakers. This unit moves quickly from stock. Most buyers are system integrators and machine builders. They value reliability over fancy features. This drive delivers exactly that.

Best Applications and Equipment

• Small conveyors and belt systems
• Fans and blowers up to 2.2 kW
• Centrifugal pumps for water or coolant
• Simple mixers and agitators
• Packaging and labeling machines
• Woodworking and light metal tools
• Automatic doors and gates
• Small HVAC units

Installation Guide

• Mount the drive vertically on a flat panel.
• Keep 10 cm clearance above and below.
• Use a single-phase 200–240V supply.
• Connect motor wires to U, V, and W terminals.
• Tighten terminal screws to the specified torque.
• Ground the unit properly for safety.
• Do not block the cooling fan intake.
• Avoid dusty or wet locations.

Commissioning and Maintenance

• Set motor parameters before first run.
• Use the operation panel for quick tuning.
• Check rotation direction without load first.
• Monitor current draw during normal operation.
• Clean air filters every three months.
• Inspect terminals for tightness yearly.
• Replace cooling fan after 3–5 years.
• Keep a log of any fault codes.

Compatibility Notes

• Works with standard three-phase induction motors.
• Compatible with Mitsubishi FR series options.
• Supports Modbus RTU via optional card.
• Can connect to PLCs with analog outputs.
• Fits most IP20 control cabinets.
• Use with circuit breakers rated for 5.2 kVA.

Certifications and Standards

• CE marked for European conformity.
• UL listed for North American safety.
• RoHS compliant for hazardous substances.
• JEM1030 protective structure (IP20).
• Designed for industrial EMC environments.

Package Contents

• 1 x FR-D720S-2.2K-CHT inverter
• 1 x operation manual
• 1 x safety instruction sheet
• 1 x terminal cover (pre-installed)
• 1 x mounting bracket set

Warranty and Shipping

• Warranty: 12 months from delivery date.
• Dispatch: Ships within 12–24 hours.
• Carriers: FedEx, UPS, DHL.
• Tracking number provided after dispatch.
• Packaging meets international shipping standards.

Frequently Asked Questions

Q: What motor size can this drive run?

A: It runs a 2.2 kW motor. Do not exceed this rating. The 10.0 A output current sets the limit. For smaller motors, you can adjust settings. But stay within the current range.

Q: Does it work with single-phase power?

A: Yes. The input is single-phase 200–240V. You do not need three-phase supply. This makes installation easier in small shops. Just connect live and neutral. Then wire the motor to the output.

Q: How long can it handle overload?

A: It handles 150% for 60 seconds. It also handles 200% for 0.5 seconds. These are inverse-time characteristics. This protects the drive from short spikes. But do not run overload continuously.

Q: What is the IP rating?

A: The enclosure is IP20. It blocks solid objects larger than 12.5 mm. It does not protect against water. Install it in a dry cabinet. Keep dust and moisture away.

Q: How fast do you ship?

A: We dispatch in 12–24 hours. We use FedEx, UPS, or DHL. You get a tracking number. Delivery times depend on your location. Most orders arrive within 3–7 business days.

Q: Is this drive easy to maintain?

A: Yes. The fan is easy to reach. Terminals are clearly labeled. You can clean filters without special tools. Check connections once a year. Replace the fan after 3–5 years. That keeps the drive running.

Q: Can I use this inverter for a pump?

A: Yes, for simple centrifugal pumps. It handles steady loads well. Avoid positive displacement pumps. They need high starting torque. This drive works best with variable torque loads.

Q: What if I need technical help?

A: Contact our team anytime. Email us at sales@powergearx.com. Or message us on WhatsApp at +86 18030005825. We respond within one business day.

Buying Guide

• Check your motor power first. Stay at or below 2.2 kW.
• Confirm you have single-phase 200–240V power.
• Measure your cabinet space. The unit is compact but needs airflow.
• Decide if you need Modbus or analog control.
• Order spare fuses and filters with the drive.
• Buy from an authorized source for warranty coverage.
• Ask about bulk pricing for multiple units.
• Verify the IP20 rating fits your environment.

SEO Meta Description

Mitsubishi FR-D720S-2.2K-CHT inverter. 2.2 kW, single-phase 200–240V, 10.0 A, IP20. 12-month warranty. Ships in 12–24 hours via FedEx, UPS, DHL.
