Product details
Bently Nevada 3300 NSv Proximity Probe
This is the 330901-00-12-70-01-05 model. It is part of the trusted 3300 NSv series. Made in the USA. This probe offers high-performance vibration sensing. It features a long 7-meter cable for flexible installation in tight spaces.
Product Configuration Breakdown
- Base Model 330901: 3300 NSv Probe, 1/4-28 UNF thread, No Armor.
- Unthreaded Length 00: 0 inches. The case is fully threaded.
- Case Length 12: 1.2 inches total length.
- Cable Length 70: 7.0 meters (23.0 feet) integrated cable.
- Connector Type 01: ClickLoc connector with a protective cover.
- Agency Approval 05: Includes multiple safety certifications.
Technical Specifications
- Brand & Model: Bently Nevada 330901-00-12-70-01-05
- Product Line: 3300 NSv Proximity Sensor System
- Key Electrical Data:
- Cable Type: 75 Ω coaxial with FEP insulation.
- Probe Resistance (RPROBE): 5.9 Ω ± 0.9 Ω (for 7.0m cable).
- Output Signal: Linear voltage proportional to gap.
- Mechanical Design:
- Case Material: High-grade AISI304 Stainless Steel.
- Tip Material: Durable Polyphenylene Sulfide (PPS).
- Sealing: Viton O-ring for environmental protection.
- Thread: 1/4-28 UNF. Max engagement 0.563 inches.
- Torque: Recommended 11.3 N•m (100 in•lb).
- Environmental Ratings:
- Operating Temperature: -52°C to +177°C.
- Storage Temperature: -52°C to +177°C.
- Note: Avoid sustained temperatures below -34°C.
Certifications & Approvals
The 330901-00-12-70-01-05 carries multiple agency approvals (option 05). This ensures compliance for use in regulated industrial environments.
Package & Support Details
- Package Includes: One NSv probe with 7.0m cable and connector protector.
- Warranty: Full 12-month manufacturer warranty against defects.
- Shipping: Fast international shipping via FedEx, UPS, or DHL.
Expert FAQs
Product Specifications
Q: What does “NSv” stand for in this series?
A: NSv refers to Bently Nevada’s “Non-Contact Sealed” vibration probe series, designed for robust industrial environments.
Q: This probe has a 1/4-28 UNF thread. Is this common?
A: Yes. The 1/4-28 UNF thread is a standard imperial size widely used in North American machinery for smaller probe installations.
Installation & Use
Q: How do I properly torque the probe during installation?
A: Use a calibrated torque wrench. Tighten to the recommended 11.3 N•m (100 in•lb). Do not exceed the maximum of 33.9 N•m to avoid damage.
Q: Can I use this long 7m cable in high-temperature areas?
A: The FEP-insulated cable is rated for the full operating temperature range. Ensure it is routed away from direct heat sources above 177°C.
Purchasing & Service
Q: What is your service policy for this model?
A> We provide a 12-month quality guarantee. Your order is processed quickly and shipped via reliable express carriers like DHL or FedEx.
