Name: Bently Nevada 330104-00-09-15-01-00 Probe | 1.5 Meter Cable &amp; 90mm Case for Flexible Installation
SKU: 330104-00-09-15-01-00
Price: 248.00 USD
Availability: InStock

Product details

Versatile Mid-Range Probe for Common Machine Monitoring

The Bently Nevada 330104-00-09-15-01-00 offers a balanced design. It features a standard 90mm case and a practical 1.5-meter cable. This provides extra reach over the basic 1.0m model. It is a reliable and cost-effective choice for most industrial vibration applications.

Balanced Benefits

Extra Cable Length: 1.5 meters offers more routing flexibility than a standard 1m probe.
Standard Case: 90mm length fits the majority of common machine mounting points.
Protected Connection: ClickLoc connector includes a protector for safe handling.
Proven Durability: Built with industrial-grade stainless steel and PPS materials.
Wide Compatibility: Works seamlessly with all 3300 XL monitoring systems.

Part Number Structure

Product Family: 330104 (3300 XL 8mm Armored Probe)
Detailed Configuration: 330104-00-09-15-01-00
- 00: Unthreaded Section = 0 mm
- 09: Overall Case Length = 90 mm
- 15: Attached Cable Length = 1.5 meters
- 01: Connector = ClickLoc with Protector
- 00: Agency Approvals = Not Required

Core Technical Data

Linear Range: 0.25 mm to 2.3 mm from target.
Optimal Gap: Set for -9 Vdc output (~1.27 mm).
Electrical Value: 7.73 Ω ± 0.50 Ω resistance (for 1.5m).
Construction: AISI 303/304 SST case, PPS tip, Viton seal.
Temperature Range: -52°C to +177°C operation.

Practical FAQ

Selection & Application

Why choose 1.5 meters over the standard 1.0-meter cable?
The 330104-00-09-15-01-00 provides extra slack. This is useful when routing around obstacles or connecting to a junction box that is not directly behind the probe.
Is the 90mm case a common size?
Yes. The 90mm (approximately 3.5 inch) case is a very standard length. It fits most pump, motor, and fan bearing housings without modification.

Performance & Specifications

Why is the resistance slightly higher than the 1.0m probe?
Electrical resistance increases with cable length. The specified 7.73 Ω for the 1.5m model is normal and calibrated for accurate system performance.
Can I use this in high humidity environments?
Yes. The probe is tested to show less than 3% change in output after prolonged exposure to 93% relative humidity.

Ordering & Service

What is your shipping and guarantee policy?
We ensure quick dispatch via major carriers like UPS, DHL, and FedEx. Every Bently Nevada 330104 probe is backed by a reliable 12-month warranty for your peace of mind.
