Product Overview: Heavy-Duty Vibration Sensing
This is the Bently Nevada 3300 XL 11 mm Proximity Probe. It is a high-performance sensor for industrial machinery health monitoring. The model 330702-00-26-10-12-05 features a robust armor and FluidLoc cable. It delivers reliable data for predictive maintenance. It is made in the U.S.A. for quality assurance.
Have questions? Our technical team is ready to help. Contact us at sales@powergearx.com or +86 18030005825 via WhatsApp.
Key Features & Benefits
- Superior Sealing: FluidLoc cable and Viton O-ring resist moisture and oil.
- Robust Construction: 11mm probe with 304 stainless steel case and armor for tough environments.
- Precision Measurement: Provides stable gap-to-voltage data for accurate vibration analysis.
- Global Compliance: Comes with multiple agency approvals for international projects.
- Easy Connection: Miniature ClickLoc connector ensures a secure, quick setup.
Detailed Technical Specifications
- Core Identification
- Brand: Bently Nevada
- Series & Type: 3300 XL 11 mm Proximity Probes
- Full Model Number: 330702-00-26-10-12-05
- 330702: 11 mm Probe, 1/2-20 UNF thread, with armor
- 00: Unthreaded Length = 0.0 in
- 26: Overall Case Length = 2.6 in
- 10: Total Cable Length = 1.0 metre
- 12: Connector = Miniature coaxial ClickLoc, FluidLoc cable
- 05: Agency Approval = Multiple Approvals
- Physical & Mechanical Data
- Probe Thread: 1/2-20 UNF
- Max Thread Engagement: 0.750 in
- Case Torque (Recommended): 15.2 N•m (133 in•lb)
- Connector Torque (Max): 0.565 N•m (5 in•lb)
- Minimum Bend Radius: 25.4 mm (1.0 in)
- Case Material: AISI 304 Stainless Steel
- Tip Material: Polyphenylene Sulfide (PPS)
- Shipping Weight: 0.17 Kg
- Electrical & Performance Data
- Nominal DC Resistance (RPROBE): 5.9 Ω ± 0.5 (for 1.0m cable)
- Cable Type: 75 Ω triaxial, FEP insulated (FluidLoc)
- Cable Length Options: 1, 5, or 9 meters
- Environmental Ratings
- Operating Temperature: -51°C to +177°C
- Pressure Seal: Viton O-ring (not pressure tested by default)
- Temperature Classifications: Available for EPL Ga, Gc, and Dc (T1 to T5).
- Note: Temperatures below -34°C may damage the seal.
Professional FAQs
- What does “FluidLoc cable” mean for my application?
FluidLoc cable has a special FEP insulation. It resists oils, coolants, and chemicals. It is perfect for wet or dirty machinery environments. - How do I properly torque the probe case?
Use a torque wrench. Apply 15.2 N•m (133 in•lb) to the 1/2-20 thread. Do not exceed 45.2 N•m. This prevents damage and ensures a good seal. - Can this 330702 probe measure axial thrust position?
Yes. The 11mm size is often used for thrust position. Pair it with the correct proximitor. Ensure proper gap calibration. - Why is the storage temperature important?
Storing the probe below -34°C can crack the Viton O-ring. A cracked seal causes failure in pressurized applications. Always store in a mild environment. - What length cable should I order?
Choose based on distance from probe to monitor. Standard is 1m, 5m, or 9m. Add extra length for routing. Avoid sharp bends below 1-inch radius.
Ordering & Support Guide
- Warranty: This product includes a 12-month warranty.
- Shipping: We ship quickly worldwide via FedEx, UPS, and DHL.
- Choosing the Right Model: Confirm your thread size is 1/2-20 UNF. Select the FluidLoc cable for harsh fluids. Pick the cable length that reaches your system.
- Need a Custom Test? Standard probes are not pressure tested. Contact us for special pressure seal validation before shipment.
Ready to order or need a quote? Email sales@powergearx.com or message us on WhatsApp at +86 18030005825 for fast service.
