Long-Cable Vibration Probe for Standard Installations
The Bently Nevada 330104-00-16-50-02-00 is designed for applications requiring significant cable reach. This 5-meter integrated cable probe simplifies wiring in standard industrial environments, connecting directly to its dedicated proximitor.
Model Configuration Explained
Full Product Identification: 330104-00-16-50-02-00
- Product Line: 330104 (3300 XL 8mm, M10x1, Armored)
- Unthreaded [00]: 0 mm (Fully Threaded Body)
- Case Length [16]: 160 mm
- Cable Length [50]: 5.0 Meters Attached
- Connector [02]: Standard Miniature ClickLoc
- Approvals [00]: Standard Industrial (Non-Hazardous Area)
Key Technical Parameters
- Sensing Capability: 2.0 mm linear range. Set to -9 Vdc output.
- Critical Note: Compatible only with the 5-meter Proximitor sensor.
- Electrical Spec: Resistance: 8.73 Ω ± 0.50 (for 5m cable).
- Build Quality: Stainless steel construction with PPS tip and Viton seal.
- Operating Range: Reliable from -52°C to +177°C. Humidity stable.
Ordering & Service Information
- Supplied Item: One probe with 5-meter attached cable.
- Warranty Coverage: Includes a full 12-month warranty.
- Delivery Method: Fast, secure shipping via FedEx, UPS, or DHL services.
Expert Guidance & FAQ
System Design
- Q: Why is the cable length fixed at 5 meters, and why is it so important?
- A: The 330104-00-16-50-02-00 is part of a calibrated system. The 5m cable and matching 5m proximitor are tuned together. Using a different length would cause incorrect vibration readings.
Mounting & Application
- Q: I have a 160mm case that is fully threaded. How do I install it correctly?
- A: Thread the probe directly into your mounting hole. The entire 160mm case is threaded, but you must not engage more than the specified 15 mm of threads to avoid damaging the probe.
Product Selection
- Q: When should I choose this standard 5m model over a certified one?
- A: Select the 330104-00-16-50-02-00 for standard factory floors without explosive atmospheres. If your area is classified as hazardous, you need a model with ATEX/IECEx approvals.
Technical Specifications
- Q: Can I cut and re-terminate the 5-meter cable if it’s too long?
- A> No. The cable length is integral to the probe’s calibration and electrical characteristics. Cutting the cable will ruin the probe’s performance and void the warranty.
Procurement & Logistics
- Q: What is the process for ordering and receiving this item?
- A: Order the 330104-00-16-50-02-00 through our site or sales team. We process quickly and ship via your choice of DHL, FedEx, or UPS, with tracking provided. The 12-month warranty starts upon delivery.
Need a long-cable solution for your machine? Contact us for expert configuration support.
