Product details
Product Overview
This is the Bently Nevada 330103-00-06-10-12-00. It is a standard 8mm proximity probe. It has a 1-meter cable for easy connection. Use it to monitor machine vibration and position. It helps find problems early to avoid downtime.
Model Number Explained
- Base Model: 330103 – 3300 XL 8mm Probe, M10x1 thread.
- Suffix -00 – Unthreaded Length: 0 mm (Fully Threaded Case).
- Suffix -06 – Overall Case Length: 60 mm.
- Suffix -10 – Cable Length: 1.0 meter.
- Suffix -12 – Connector: Miniature ClickLoc with FluidLoc cable.
- Suffix -00 – Agency Approvals: Not required for this order.
Key Specifications
- Product Identification: Bently Nevada 330103-00-06-10-12-00
- Measurement Details:
- Linear Range: 0.25 mm to 2.3 mm.
- Best Gap: Set to 1.27 mm (for -9 Vdc).
- DC Resistance: 7.59 Ω ± 0.50 Ω (for 1m cable).
- Mechanical Design:
- Case: 303/304 Stainless Steel, fully threaded (M10x1).
- Tip: PPS (Polyphenylene Sulfide) material.
- Size: Case length is 60 mm.
- Environmental Ratings:
- Temperature: Standard range from -52°C to +177°C.
- Sealing: Viton O-ring for internal pressure seal.
- Humidity: Stable performance in wet conditions.
- Cable & Connector: 1.0 meter long with FluidLoc jacket. Miniature ClickLoc connector.
Main Features & Benefits
- Ready to Use: 1-meter cable is perfect for common installations.
- Durable Cable: FluidLoc cable resists oils and chemicals.
- Simple Mounting: Fully threaded M10x1 design installs quickly.
- Accurate Data: Provides reliable vibration signals for analysis.
- Wide Compatibility: Works with standard 3300 XL monitoring systems.
Frequently Asked Questions
Product Details & Selection
- What does “Agency Approval Option: 00” mean?
- This specific probe configuration does not include extra safety certifications like ATEX. It is for use in standard, non-hazardous industrial areas.
- What is the advantage of the FluidLoc cable?
- The FluidLoc cable jacket provides excellent resistance to moisture, oils, and many chemicals. This increases reliability in wet or dirty machine environments.
Installation & Application
- How do I install a fully threaded (0mm unthreaded) probe?
- Screw it directly into a tapped M10x1 hole. You can also use a locknut on the threads. Do not screw it in more than 15mm.
- Can I use this 1-meter probe for any machine?
- Yes, it is a general-purpose length. It is ideal when the monitoring system is close to the measurement point, like on pump or motor bearing housings.
Ordering & Support
- What if I need a longer cable?
- The Bently Nevada 330103 model comes in other lengths. Contact us with your required cable length, and we can find the right part number for you.
- What is included with my purchase?
- You get the genuine probe with a 12-month warranty. We ship fast using FedEx, UPS, or DHL to get it to your site quickly.
Questions about this product? Our team is here to assist you.
Quick contact: sales@powergearx.com or +86 18030005825.
