The Ultimate Long-Range Certified Vibration Probe
This is the Bently Nevada 3300 XL 11 mm Proximity Probe. Model 330702-00-30-90-12-05 is the top choice for extreme applications. It combines maximum 9-meter reach, a 3-inch deep case, FluidLoc cable, and global safety approvals. And it delivers reliable signals over long distances in harsh, certified environments. It is engineered for critical asset protection.
Deploying sensors in complex, large-scale plants? Get expert advice: sales@powergearx.com or +86 18030005825.
Unbeatable Combination of Features
- Maximum Cable Reach: 9.0-meter FluidLoc cable for the most demanding long-distance layouts.
- Deep Mounting Capability: 3.0-inch case length installs securely in thick housings or bosses.
- Worldwide Compliance: Carries multiple safety approvals (ATEX, IECEx, CSA) for global projects.
- Superior Environmental Defense: FluidLoc cable resists aggressive fluids, oils, and chemicals.
- Armored Durability: Full stainless steel armor protects the cable from abrasion and impact.
Technical Configuration Deep Dive
- Product Profile
- Brand: Bently Nevada
- Family: 3300 XL 11mm Proximity Probes
- Full Part Number: 330702-00-30-90-12-05
- 330702: 11mm Diameter, 1/2-20 UNF, Armored
- 00: Unthreaded Portion = 0 in
- 30: Case Length = 3.0 in
- 90: Total Cable = 9.0 meters
- 12: Cable/Connector = FluidLoc, ClickLoc
- 05: Approvals = Multiple (CSA, ATEX, IECEx)
- Physical & Installation Data
- Body Material: AISI 304 Stainless Steel
- Tip Material: PPS (Polyphenylene Sulfide)
- Mounting Thread: 1/2-20 UNF
- Case Depth: 3.0 inches (76.2 mm)
- Optimal Torque: 15.2 N•m (133 in-lb)
- Internal Seal: Viton® O-Ring
- Electrical & Signal Specifications
- Cable Construction: 75 Ω Triaxial, FEP Insulation
- Cable Length: 9.0 meters (29.5 feet)
- DC Resistance (RPROBE): 8.5 Ω ± 1.1
- Connection: Miniature Coaxial ClickLoc
- Bend Radius: Do not bend below 25.4 mm (1.0 in).
- Certifications & Limits
- Temperature Range: -51°C to +177°C
- Key Approvals: ATEX, IECEx, CSA (Intrinsic Safety).
- Storage Alert: Never expose to below -34°C before installation to preserve the seal.
Professional FAQs & Selection Strategy
- What are the main uses for a 9-meter, certified probe?Ideal for large turbines, generators, or compressors where the monitoring panel is far away and the area is classified as hazardous (Zone 1/Div. 1).
- Does the longer cable affect system calibration?Yes, the system must be calibrated for the 9m cable length. The higher probe resistance (8.5 Ω) is automatically compensated by compatible Bently Nevada monitors.
- How do I handle and route 9 meters of armored cable?Plan the route first. Use wide, sweeping bends. Secure the cable regularly with cushioned clamps. Avoid tight loops that stress the cable.
- Can I use this 330702-00-30-90-12-05 in an unclassified area?Yes, its certifications do not limit use to hazardous areas only. It performs excellently in any demanding industrial setting.
- Is the 3-inch case a standard or special length?A 3-inch case (Option 30) is a less common, extended length. It is specified for applications requiring deeper penetration into the mounting structure.
Purchase with Confidence
- Warranty Assurance: This product is guaranteed for 12 months from shipment.
- Reliable Shipping: We deliver worldwide using express carriers like FedEx, UPS, and DHL.
- Buying Guidance: Select this model for long-distance, certified, fluid-exposed monitoring. Ensure your system supports 9m probes. Confirm your hazardous area classification.
- Volume & Project Quotes: Contact us for competitive pricing on large orders.
For project specifications and lead times. Reach our team at sales@powergearx.com or WhatsApp: +86 18030005825.
