Product Introduction
The 330192-00-20-50-00 is a 3300 XL 8 mm ETR Probe from Bently Nevada. It delivers reliable, non-contact vibration and position monitoring for critical machinery. This probe features a 3/8-24 UNF thread with armor for enhanced durability. Its design ensures accurate measurements in demanding industrial environments.
Model Number Breakdown
- 330192 — 3300 XL 8 mm ETR Probe, 3/8-24 UNF thread, with armor
- -00 — Agency Approval: Not required
- -20 — Overall Case Length: 2.0 inches
- -50 — Total Length: 5.0 meters (16.4 feet)
- -00 — Unthreaded Length: Minimum 0.0 inch
- -50 — Total Length: 5.0 meters (16.4 feet)
Technical Specifications
- Brand: Bently Nevada
- Model: 330192-00-20-50-00
- Series: 3300 XL 8 mm ETR Probe
- Thread Type: 3/8-24 UNF, with armor
- Unthreaded Length: Minimum 0.0 in (must be 0.8 in less than case length)
- Overall Case Length: 2.0 in (Option 20)
- Total Length: 5.0 meters (16.4 feet)
- Designed for use with the 5 meter Proximitor sensor only
- DC Resistance: 8.73 ± 0.50 Ω (center to outer conductor)
- Probe Tip Material: Polyphenylene sulfide (PPS)
- Case Material: AISI 303 or 304 stainless steel (SST)
- Thread Engagement: Maximum length 0.563 in
- Pressure Seal: Viton® O-ring for differential pressure sealing
- Temperature Range (Standard): -52°C to +177°C (-62°F to +350°F)
- Extended Tip Range: -52°C to +218°C (-62°F to +425°F)
- Extended Cable Range: -51°C to +260°C (-60°F to +500°F)
- Note: Exposing probe below –34˚C (-30˚F) may cause premature pressure seal failure
- Humidity Tolerance: Less than 3% change in Average Scale Factor after 56 days at 93% RH (IEC 68-2-3)
- Agency Approval: Option 00 (not required for this variant)
Hazardous Area Certifications
- ia (Intrinsically Safe)
- Class I, Zone 0: AEx/Ex ia IIC T5…T1 Ga
- Class I, Groups A, B, C, D
- Class II, Groups E, F, G
- Class III
- Requires installation with intrinsic safety zener barriers (drawing 141092) or galvanic isolators
- nA / ec (Nonincendive)
- Class I, Zone 2: AEx/Ex nA IIC T5…T1 Gc
- Class I, Division 2, Groups A, B, C, D
- Class I, Zone 2: AEx/Ex ec llC T5…T1 Gc
- Requires installation with nonincendive circuit per drawing 140979
- Temperature Schedule (EPL Ga and Gc)
- T1: -55°C to +232°C
- T2: -55°C to +177°C
- T3: -55°C to +120°C
- T4: -55°C to +80°C
- T5: -55°C to +40°C
Installation & Compatibility
- Proximitor Compatibility: Designed for use with the 5 meter Proximitor sensor only
- Extension Cables: Compatible with
- Alternative Probes: For different length or application needs, consider
- 3300 5mm Proximity Probes series
- Pressure Seal Testing: Contact custom design department if test is required
Maintenance & Serviceability
- Troubleshooting: Measure DC resistance between center and outer conductors
- Nominal value: 8.73 ± 0.50 Ω
- Maintenance: No routine maintenance required due to solid-state construction
- Field Replacement: Standardized thread and length options simplify interchangeability
- Shipping: In-stock items ship within 12-24 hours
- Carriers: FedEx, UPS, DHL
Package Contents
- 1 x 3300 XL 8 mm ETR Probe (330192-00-20-50-00)
- Installation guide
- Factory calibration certificate
Warranty & Support
- Warranty: 12 months against manufacturing defects
- Support: Contact sales@powergearx.com or +86 18030005825 (WhatsApp)
Manager’s Insight
This probe is ideal for high-speed turbomachinery including steam turbines, compressors, and large pumps. The 5-meter total length eliminates extension cables in remote installations. The ia rating supports intrinsically safe applications with proper barriers.
Expert Review
The 3300 XL series delivers proven linearity and repeatability. The 8 mm probe provides excellent sensitivity for detecting small shaft movements. The Viton® seal reliably prevents process fluid ingress. For modular systems, pair with extension cables like 330190-085-00-CN or 330190-085-00-05.
Frequently Asked Questions (FAQ)
- What is the maximum cable length without signal degradation?This 5.0-meter probe works only with the 5-meter Proximitor sensor. Longer runs need extension cables with proper impedance matching.
- Can this probe be used in wet or corrosive environments?Yes. Stainless steel case and PPS tip resist corrosion. The Viton® O-ring provides moisture sealing.
- How do I verify probe health before installation?Measure DC resistance between center and outer conductors. Expected reading is 8.73 ± 0.50 Ω.
- What is the difference between 8 mm and 5 mm proximity probes?The 8 mm probe offers larger target area and different linear range. For smaller shafts, consider the 3300 5mm Proximity Probes series.
- What mounting torque is required?Apply 15-20 ft-lbs for the 3/8-24 UNF thread. Ensure at least 0.8 inches of unthreaded length relative to case length.
- Is pressure seal testing included?No. Probes are not pressure tested before shipment. Contact custom design department if testing is required.
Selection Guide
- Choose 330192-00-20-50-00 if:
- You need 5.0 meter total length and 2.0 inch case
- Agency approval is not required
- Application is non-hazardous or uses external barriers
- Choose 330190-085-00-CN if:
- You need extension cable for longer reach between probe and Proximitor
- Choose 330190-085-00-05 if:
- You need 5.0 meter extension cable with connector for modular system design
