6ES7467-5GJ02-0AB0 Siemens S7-400 IM467 PROFIBUS DP Master Module

Product Overview

• Siemens 6ES7467-5GJ02-0AB0 – PROFIBUS DP master interface module for SIMATIC S7-400 systems
  • Connects S7-400 CPU to PROFIBUS DP field devices using RS485
  • Supports up to 96 DP slaves on a single network segment
  • Transmits data at speeds up to 12 Mbit/s
  • Ideal for large distributed I/O networks in process and factory automation

Technical Specifications – Hierarchical View

• General information
  • Brand: Siemens
  • Model: 6ES7467-5GJ02-0AB0
  • Series: SIMATIC S7-400
  • Product type: IM 467 PROFIBUS DP Master Interface
  • Weight: approx. 700 g
  • Dimensions: 25 x 290 x 210 mm (W x H x D)
• Power supply
  • 5 V DC: required (±5%) from backplane bus
  • 24 V DC: required (±5%) for interface power
  • Current draw: max. 1300 mA from backplane bus
• PROFIBUS DP interface
  • Connector type: 9-pin Sub D socket
  • Physical layer: RS485
  • Transmission rate: up to 12 Mbit/s
  • Maximum DP slaves: 96
  • Connections: up to 32 (depending on CPU type)
• Advanced features
  • Equidistance: supported for synchronized communication
  • Direct data exchange: slave-to-slave communication supported
  • Modules per CPU: up to 10 in the CR (depending on CPU type)
• Environmental conditions
  • Operating temperature: 0 to 60 °C
  • Storage/transport temperature: -40 to 70 °C
  • Relative humidity: max. 95% at 26 °C
  • Installation altitude: up to 3000 m above sea level

Expert Review – Engineer’s Insight

• This module is the backbone of any S7-400 PROFIBUS network. It handles large numbers of slaves with reliable performance at 12 Mbit/s.
• Support for equidistance is critical for motion control applications. It ensures synchronized communication cycles for drives.
• Direct data exchange (slave-to-slave) reduces CPU load. Slaves can communicate without going through the CPU.
• The 1300 mA current draw is high. Verify your rack power supply capacity before adding multiple IM467 modules.

Compatible Devices & Applications

• Works with all SIMATIC S7-400 CPUs (standard and redundant systems)
• Connects to: ET200 remote I/O, SINAMICS drives, SEW drives, and any PROFIBUS DP slave
• Ideal for: process plants, manufacturing lines, material handling, and motion control systems
• Typical industries: automotive, chemical, pharmaceutical, and metal processing

Installation & Wiring Guide

• Installation steps
  • Mount IM 467 in an S7-400 rack (U-bus connector required)
  • Connect 24 V DC supply to the module terminals
  • Connect PROFIBUS cable to the 9-pin Sub D socket
  • Set the correct terminating resistors at both network ends
• Configuration notes
  • Use STEP 7 to configure DP slaves and assign addresses
  • Set bus parameters (baud rate, profile) in hardware config
  • Enable equidistance for time-critical applications
  • Verify the CPU supports the number of DP slaves you need

Package Contents

• 1x Siemens 6ES7467-5GJ02-0AB0 PROFIBUS DP master module
• No cables or connectors included (order separately)
• No configuration software included

Shipping & Warranty

• 12-month warranty against manufacturing defects
• Shipping: FedEx, UPS, DHL (calculated at checkout)
• Orders dispatch within 12-24 hours on business days

Comparison – IM467 vs CP443-5

• 6ES7467-5GJ02-0AB0 (IM467) – PROFIBUS DP master, 96 slaves, 12 Mbit/s, equidistance, slave-to-slave communication, 1300mA draw
• 6ES7443-5DX04-0XE0 (CP443-5) – PROFIBUS DP master, 32 slaves, 12 Mbit/s, lower power consumption, FMS support
• Choose IM467 for large networks with many slaves and advanced features
• Choose CP443-5 for smaller networks or when FMS is required

Frequently Asked Questions

• Q: How many DP slaves can I connect to the IM467?
  • A: Up to 96 slaves per module. The actual number depends on your CPU type and network cycle time requirements.
• Q: What is equidistance used for?
  • A: Equidistance ensures communication cycles have equal time intervals. This is essential for drive synchronization and closed-loop control.
• Q: Can slaves communicate directly with each other?
  • A: Yes, the IM467 supports direct data exchange (slave-to-slave). This reduces CPU load and speeds up data transfer.
• Q: Why does the module need both 5V and 24V power?
  • A: 5V comes from the backplane bus for internal logic. 24V supplies the PROFIBUS interface drivers. Both are required.
• Q: Can I use this module with a redundant S7-400 system?
  • A: Yes, the IM467 works in redundant configurations. You need two modules – one for each CPU in the redundant pair.

Buying Guide – Selection Advice

• Choose 6ES7467-5GJ02-0AB0 for large PROFIBUS networks with many slaves and time-critical communication.
• For smaller networks (under 32 slaves), consider CP443-5 as a lower-cost alternative.
• Check your CPU type – not all S7-400 CPUs support 96 slaves or 10 IM467 modules.
• Verify your rack power supply can handle 1300 mA per module.
• For long cable runs (>100m), use PROFIBUS repeaters to maintain signal quality.
