Product details
3300 XL Compact Vibration Probe
This is the Bently Nevada 330101-00-33-05-02-00. A compact and robust 3300 XL 8mm probe. Perfect for installations with tight space limits. It delivers reliable vibration and position data.
Model Structure Analysis:
- 330101 – 3300 XL 8mm Probe Base
- 00 – Unthreaded: 0.0 in
- 33 – Case: 3.3 inches (84 mm)
- 05 – Cable: 0.5 meter (1.6 ft)
- 02 – Connector: ClickLoc Coaxial
- 00 – Not Required
The short 3.3-inch case fits shallow mounting points. The 0.5-meter cable is ideal when the proximitor is mounted very close. It reduces cable clutter. Built with the same rugged 8mm technology.
Get support for your application: Email Sales or Message +86 18030005825 on WhatsApp.
Primary Technical Specifications
- Full Part Number: Bently Nevada 330101-00-33-05-02-00
- Product Family: 3300 XL Proximity Probe System
- Probe Diameter: 8mm, No Armor
- Case Length: 3.3 in (84 mm) – Compact
- Integrated Cable: 0.5 m (1.6 ft) – Short
- Electrical Range: 2.0 mm (80 mils) Linear
- Output Ratio: 7.87 V/mm (200 mV/mil)
- Standard Gap (Vibration): -9 Vdc Output
- Probe DC Resistance: 7.45 Ω ± 0.50 Ω
- Temperature Operation: -52°C to +177°C
- Thread Standard: 3/8-24 UNF
- Environmental Seal: Viton® O-ring
- Construction: PPS Tip, SST Case
Application & Purchasing FAQ
Q: When should I choose this short 0.5-meter cable version?
A: Choose this when your 3300 XL proximitor sensor is mounted directly on or very near the machine case. It creates a clean, low-profile installation.
Q: The model ends in “00”. What does this mean?
A: The suffix “00” often indicates a standard base configuration with no special options or revisions beyond the main code.
Q: Is the 3.3-inch case too short for some applications?
A: It is purpose-built for shallow mounting bosses or where space behind the mounting point is limited. Always check your mechanical drawings.
Q: What is a common mistake during the first power-up?
A: Not allowing the system to thermally stabilize. The probe and proximitor output can drift slightly in the first 30 minutes after power is applied.
Q: What is your shipping and warranty policy for this item?
A: Every 330101-00-33-05-02-00 probe includes a 12-month product warranty. We ship stock items swiftly using FedEx, UPS, and DHL to meet project deadlines.
Need this compact probe for your OEM design? Contact us for pricing.
