Yokogawa AAV144-S50 Analog Input Module 16-Ch Isolated -10-10 V

Product Brief

Yokogawa AAV144-S50 Analog Input Module delivers precise voltage measurement for industrial automation. This 16-channel isolated module handles -10 to 10 V signals with excellent accuracy. It safeguards your system with 1500 V AC isolation and robust input protection. The module suits distributed control systems (DCS), programmable logic controllers (PLC), and data acquisition applications. Its compact design and fast 10 ms update period ensure reliable performance in harsh environments.

Technical Specifications

• Brand: Yokogawa
• Model: AAV144-S50
• Input Channels: 16 isolated channels
• Input Signal Range: 1 to 5 V, -10 to 10 V (selectable for CH1-CH16)
• Allowable Input Voltage: ±30 V
• Isolation Voltage: 1500 V AC (1 min, input to system)
• Input Resistance (Power ON): 1 MΩ
• Input Resistance (Power OFF): 200 kΩ
• Accuracy: ±4 mV (±20 mV full scale)
• Data Update Period: 10 ms
• Temperature Drift: ±4 mV/10°C (±20 mV/10°C)
• Max Current Consumption: 500 mA @ 5 V DC
• Weight: 0.2 kg
• External Communication: Pressure clamp terminal, MIL connector, dedicated KS1 cable

Model & Suffix – Hierarchical Tree

• AAV144 – Analog Input Module (-10 to +10 V, 16-ch, Isolated)
  • -S – Standard Type (no explosion protection)
    • 50 – Basic Type (0)

Key Features & Benefits

• High Accuracy: ±4 mV ensures precise signal conversion
• Galvanic Isolation: 1500 V AC protects control circuits
• Wide Input Range: Supports both 1-5 V and -10-10 V
• Fast Update: 10 ms refreshes data rapidly
• Temperature Stability: Low drift of ±4 mV per 10°C
• Compact & Light: 0.2 kg saves panel space
• Flexible Connectivity: Pressure clamp, MIL, or KS1 cable

Environmental & Compliance

• Operating Temperature: 0 to 55°C (ambient)
• Storage Temperature: -20 to 70°C
• Humidity: 5 to 95% RH (non-condensing)
• EMC Immunity: Conforms to IEC 61000-4 series
• Safety Standards: UL, CSA, CE marked
• Protection Class: IP30 (front panel)

Installation & Maintenance

• Mounting: DIN-rail or direct panel mounting
• Wiring: Use shielded twisted-pair cables for analog signals
• Commissioning: Default settings suit most applications; DIP switches for range selection
• Diagnostics: LED indicators for power, communication, and channel status
• Maintenance: No routine calibration needed; periodic visual inspection recommended

Compatibility & Integration

• Works with Yokogawa CENTUM VP, ProSafe-RS, and other DCS platforms
• Supports Modbus RTU, PROFIBUS DP, and DeviceNet via optional adapters
• Compatible with third-party PLCs (Siemens, Rockwell, Schneider) using MIL or KS1 cable
• Fully integrated with Yokogawa FieldMate tool for configuration

Package Contents

• AAV144-S50 Analog Input Module (1 unit)
• Pressure clamp terminal connector (included)
• MIL connector cable (1.5 m)
• Quick start guide & product CD
• Warranty registration card

Warranty & Logistics

• Warranty: 12 months against manufacturing defects
• Shipping: 12-24 hours dispatch (business days)
• Express Carriers: FedEx, UPS, DHL (tracking provided)
• Packaging: Anti-static ESD bag + reinforced carton

Expert Review – Manager’s Insight

“The AAV144-S50 stands out for its rock-solid isolation and fast 10 ms update. In field tests, we observed drift below ±3 mV even at 50°C. It simplifies wiring with clamp terminals and reduces troubleshooting time. For critical loops like temperature or pressure, this module is a cost-effective workhorse. Recommended for greenfield projects and retrofits.” – Senior Product Manager

Applicable Equipment & Scenarios

• DCS Systems: Yokogawa CENTUM, Honeywell TDC, Emerson DeltaV
• PLC Systems: Siemens S7, Rockwell ControlLogix, Schneider M580
• Applications: Temperature sensors (thermocouples, RTDs), pressure transmitters, flow meters, level sensors
• Industries: Oil & gas, chemical, power, water treatment, pharmaceutical

Frequently Asked Questions (FAQ)

• Can I mix 1-5 V and -10-10 V inputs on different channels?
• No. The input signal range is set globally for all 16 channels. Choose either 1-5 V or -10-10 V via DIP switch.
• What is the maximum cable length for analog signals?
• We recommend 200 m maximum for unshielded cable, and 500 m for shielded twisted-pair cable to maintain accuracy.
• Does the module support hot-swapping?
• Yes, but ensure the system is properly grounded to avoid transient voltage damage.
• How do I clean the terminal connectors?
• Use isopropyl alcohol and a soft brush. Do not use compressed air near the internal components.
• Can I use this module with a 24 V DC power supply?
• The module requires a stable 5 V DC supply (500 mA). A separate 24 V supply is not needed.

Purchase Guidance & Selection Tips

• Select AAV144-S50 if you need 16 isolated channels and standard accuracy (±4 mV).
• For -10-10 V applications, choose this model; for 4-20 mA, consider AAV144-S40.
• Always verify the input resistance matches your sensor’s output impedance (1 MΩ is suitable for most transmitters).
• Order the KS1 dedicated cable if you require quick disconnection in frequent maintenance areas.
• Check your DCS firmware version – CENTUM VP R5.02 or higher is recommended.
