Schneider iC60N 2P C20 Acti9 Miniature Circuit Breaker 20A

iC60N 2P C20 Acti9 Miniature Circuit Breaker by Schneider Electric

• Model iC60N 2P C20 is a compact 2-pole miniature circuit breaker from the Acti9 iC60 range.
• It carries 20 A with a C curve trip profile for general industrial and commercial circuits.
• Schneider Electric builds it for DIN rail mounting, fast wiring, and long service life.
• This breaker suits distribution boards, control panels, and final circuit protection.
• It combines thermal-magnetic protection with a 6 kA breaking capacity at 230/400 V.
• The Acti9 iC60 platform supports easy upgrades, common accessories, and clear status indication.
• Users get reliable overcurrent protection, short-circuit protection, and isolation in one device.

Technical Data

• Brand: Schneider Electric
• Series: Acti9 iC60
• Model: iC60N 2P C20
• Module type: Miniature circuit breaker (MCB)
• Poles: 2P
• Rated current: 20 A
• Trip curve: C curve, thermal-magnetic
• Magnetic trip range: 8 x In, plus or minus 20 percent
• Breaking capacity: 6 kA at 230/400 V AC
• Rated voltage: 400 V AC, 125 V DC
• Frequency: 50/60 Hz AC
• Measurement range: 20 A nominal current protection
• Response: Thermal for overload, magnetic for short circuit
• Sensitivity: C curve trips above 8 x In magnetic threshold
• Linearity: Stable trip behavior across rated current range
• Resolution: Single-pole plus neutral style 2P protection
• Temperature range: -35 to 70 degrees Celsius
• Environmental tolerance: Handles harsh panel and cabinet conditions
• Interference resistance: Designed for industrial electromagnetic environments
• Standard: EN/IEC 60898-1, EN/IEC 60947-2
• Mounting: 35 mm DIN rail
• Mechanical life: 20,000 cycles
• Electrical life: 10,000 cycles
• Dimensions: 85 x 36 x 78.5 mm
• Weight: 0.25 kg
• Lifecycle: Active in production, Acti9 range, last verified 2026-09

Installation Guide

• Mount the device on a standard 35 mm DIN rail.
• Use cables rated for 20 A and the local wiring code.
• Tighten terminals to the torque stated by Schneider Electric.
• Keep clearance around the breaker for heat release.
• Check polarity and phase labeling before power-up.
• Confirm the C curve suits the load inrush current.
• Do not exceed 400 V AC or 125 V DC ratings.

Commissioning and Maintenance

• Test the manual switching action after installation.
• Verify trip function with a suitable circuit breaker tester.
• Record the set current and circuit tag for future checks.
• Inspect terminals for loose wires during routine service.
• Replace the unit if contact wear or trip drift appears.
• The 10,000 electrical cycles rating supports long maintenance intervals.

Compatibility Notes

• Fits Acti9 iC60 distribution boards and compatible enclosures.
• Works with standard DIN rail accessories and busbars.
• Pairs with Acti9 auxiliaries for signaling and remote indication.
• Suitable for industrial control panels and commercial boards.
• Not a substitute for RCD protection where earth leakage safety is required.

Certifications and Standards

• Meets EN/IEC 60898-1 for household and similar installations.
• Meets EN/IEC 60947-2 for industrial circuit breakers.
• Carries the Schneider Electric quality and traceability system.
• Complies with RoHS and REACH where applicable.
• Marked for 6 kA breaking capacity at 230/400 V AC.

Expert Review

• The iC60N 2P C20 is a workhorse breaker for daily industrial use.
• Its C curve balances motor inrush and cable protection well.
• The 6 kA rating fits many sub-distribution and final circuit needs.
• Schneider Electric accessories make system expansion simple.
• For heavy inductive loads, check 8 x In magnetic trip margins.
• Build quality and 20,000 mechanical cycles support long panel life.

Manager’s Insight

• Stock this Acti9 iC60 model for common 20 A two-pole jobs.
• It reduces SKU sprawl because one breaker covers many AC circuits.
• The active lifecycle status protects long-term project supply.
• Pair it with Acti9 auxiliaries to cut wiring time on site.
• Use clear labels and torque checks to lower callback risk.
• For DC systems, confirm the 125 V DC limit before ordering.

Best Applications

• Industrial control panels with mixed motor and resistive loads.
• Commercial distribution boards for lighting and socket circuits.
• Small machine feeders that need 20 A two-pole protection.
• HVAC panels and pump controls with moderate inrush.
• Workshop sub-panels and retail power circuits.
• Building services where DIN rail space is tight.

FAQ

• What does C20 mean on this breaker?
  The C shows a C curve. The 20 shows a 20 A rated current.
• Can I use it for a 20 A motor circuit?
  Yes, if the inrush current stays within the 8 x In magnetic range.
• Is this breaker suitable for DC?
  Yes, up to 125 V DC. Check polarity and wiring rules first.
• How many modules wide is it?
  It is 36 mm wide, which is two standard 18 mm modules.
• What is the difference between iC60N and iC60H?
  The iC60N offers 6 kA. The iC60H offers higher breaking capacity.
• Does it include an RCD function?
  No. Add a separate RCD or RCBO for earth leakage protection.
• How do I know it is genuine?
  Buy from authorized channels and check the Schneider Electric marking and batch code.
• What should I check before buying?
  Confirm poles, current, curve, voltage, and breaking capacity.
• Can I use it in a 400 V three-phase panel?
  Yes, for two-pole circuits rated up to 400 V AC.
• What is the expected service life?
  It offers 20,000 mechanical cycles and 10,000 electrical cycles.
• Do you ship quickly?
  Yes. Orders ship in 12-24 hours via FedEx, UPS, or DHL.

Buying Guide

• Match the rated current to the cable and load.
• Pick the trip curve based on inrush current.
• Check breaking capacity against the available fault level.
• Confirm pole count and voltage for your system.
• Choose Acti9 accessories for easier panel integration.
• Order genuine Schneider Electric parts for warranty support.

Package List and Warranty

• 1 x Schneider Electric iC60N 2P C20 miniature circuit breaker
• 1 x Product identification label with model and batch details
• 1 x Protective packaging for safe transport
• Warranty: 12 months from delivery
• Dispatch: Ships in 12-24 hours after order confirmation
• Couriers: FedEx, UPS, DHL
