BMXDAO1605 Schneider Electric Modicon X80 Discrete Output Module
The BMXDAO1605 is a 16-channel AC Triac output module from Schneider Electric. Moreover, it belongs to the Modicon X80 series. This module switches 100-240 V AC field devices. Therefore, it suits both M340 and M580 controllers. Also, the design is compact and robust. As a result, it saves panel space and cuts wiring time.
Why Choose This Module
- 16 Triac outputs in one slot.
- Also works with 100-240 V AC loads.
- Moreover, group-to-group isolation boosts safety.
- Furthermore, a front status LED speeds up checks.
- Besides, it is a shared platform for M340 and M580.
- Finally, an active lifecycle means long-term support.
Technical Specifications
- Brand: Schneider Electric
- Model: BMXDAO1605
- Series: Modicon X80
- Module type: Discrete output module
- Channels: 16
- Signal type: Triac, bidirectional thyristor
- Output range: 100-240 V AC
- Resolution: Not applicable, discrete
- Accuracy: Not applicable, discrete
- Frequency response: Follows AC line frequency
- Sensitivity: Not applicable, discrete output
- Linearity: Not applicable, discrete output
- Isolation: Group-to-group
- Diagnostics: Module status LED
- Connection: 20-pin terminal block
- Supply voltage: 100-240 V AC field
- Power consumption: 2.6 W
- Bus current: 110 mA at 24 V DC
- Temperature range: 0°C to +60°C operating
- Storage temperature: -25°C to +70°C
- Humidity: 5% to 95%, non-condensing
- Protection rating: IP20
- Dimensions: 100 x 28 x 93 mm
- Weight: 0.18 kg
- Lifecycle: Active, last verified 2026-09
Installation Guide
- First, mount the module on a Modicon X80 rack.
- Then, keep power off during wiring.
- Also, use the 20-pin terminal block.
- Next, match AC line and load wires.
- Moreover, respect group isolation rules.
- Finally, check the front LED after power-up.
Setup and Maintenance
- For example, auto-detection works with M340 and M580.
- Also, no calibration is needed.
- Moreover, the LED shows module health fast.
- In addition, hot-swap support cuts downtime.
- Therefore, clean with a dry cloth only.
Compatibility
- Schneider Electric Modicon M340 controllers.
- Also, Schneider Electric Modicon M580 controllers.
- Moreover, Modicon X80 racks and power supplies.
- Furthermore, standard 20-pin terminal blocks.
Certifications
- CE marking for European markets.
- Also, UL listed for North America.
- Moreover, RoHS compliant materials.
- Meanwhile, ATEX rating depends on the final setup.
Packing List
- 1 x BMXDAO1605 module.
- Also, 1 x terminal block.
- Moreover, 1 x quick start guide.
- Finally, 1 x protective carton.
Warranty and Shipping
- Therefore, every unit carries a 12-month warranty.
- Also, orders ship within 12-24 hours.
- Moreover, carriers include FedEx, UPS, DHL.
- In addition, a tracking number is sent on dispatch.
- Still, you can ask questions at sales@powergearx.com or +86 18030005825.
Expert Review
The BMXDAO1605 is a solid pick for AC switching. For example, Triac outputs remove moving parts. As a result, this raises long-term reliability. Moreover, group isolation protects nearby circuits. Also, the 16-channel layout saves rack space. Furthermore, engineers will like the simple LED diagnostics. Therefore, the module fits both M340 and M580 racks. Thus, one part covers many projects.
Manager’s Insight
Stock this module for plant upgrades. In addition, it serves two controller families. Therefore, fewer SKUs sit on the shelf. Also, AC Triac outputs cover lamps, valves, and small motors. Moreover, the shared X80 platform lowers training cost. Furthermore, lifecycle is active, so support is safe. Meanwhile, fast shipping keeps projects on schedule. Thus, contact sales@powergearx.com for bulk pricing.
Best Fit Devices and Applications
- For example, AC solenoid valves.
- Also, indicator lamps and beacons.
- Moreover, small AC motors and fans.
- In addition, heating elements with low load.
- Furthermore, packaging and assembly lines.
- Besides, water treatment panels.
- Finally, building automation cabinets.
FAQ
Q: What does the BMXDAO1605 control?
A: It switches 16 AC devices from 100 to 240 V.
Q: Does it work with the M580?
A: Yes. Moreover, it fits M340 and M580 racks.
Q: Is calibration required?
A: No. Therefore, discrete outputs need no calibration.
Q: How fast is shipping?
A: Orders leave in 12 to 24 hours.
Q: Which couriers do you use?
A: We ship by FedEx, UPS, and DHL.
Q: What is the warranty?
A: Also, every unit carries a 12-month warranty.
Q: Can I mix AC and DC loads?
A: No. However, this module is for AC loads only.
Q: How do I check module health?
A: Watch the front status LED.
Q: Experience tip, what causes early Triac failure?
A: High inrush loads stress the output. Therefore, add a snubber or derate the load. Also, keep cabinet heat low.
Q: Buying advice, when should I pick this model?
A: Choose it for dense AC switching. Also, choose it when you run M340 or M580 racks. However, for DC loads, pick a DC output module instead.
Q: Do you offer bulk pricing?
A: Yes. Therefore, email sales@powergearx.com or message +86 18030005825.
