S7-1200 CPU 1214C 6ES7214-1AG40-0XB0 | Compact Automation Controller

Compact Industrial Controller

The Siemens 6ES7214-1AG40-0XB0 CPU 1214C provides reliable automation control. This compact S7-1200 PLC combines digital and analog I/O in one unit. It offers excellent performance for small to medium applications. Authors: Powergear X Automation

Built-in I/O Configuration

• 14 digital inputs (24V DC) for sensor connections
• 10 digital outputs (24V DC, 0.5A each) for actuators
• 2 analog inputs (0-10V) for process variable monitoring
• 6 high-speed counters for precise measurement
• 4 high-speed outputs (100kHz) for motion control
• All I/O points integrated on main CPU unit

Key Specifications

• Brand: Siemens | Model: 6ES7214-1AG40-0XB0
• Series: S7-1200 Compact CPU 1214C
• Memory: 150KB work memory, 4MB load memory
• Power Supply: 20.4-28.8V DC with reverse protection
• PROFINET: 1 port with 100 Mbit/s speed
• Expansion: Up to 8 signal modules, 3 communication modules
• Dimensions: 110x100x75 mm (WxHxD)
• Weight: 415 grams for easy installation

Communication Features

• PROFINET IO Controller and Device capability
• TCP/IP, ISO-on-TCP, UDP protocols supported
• Web server for remote monitoring and diagnostics
• OPC UA Server for data exchange
• S7 communication for Siemens network integration
• MODBUS protocol support available

Advanced Control Functions

• PID control for process regulation
• Motion control with positioning capability
• High-speed counting up to 100kHz
• Data logging and recipe management
• Diagnostic buffer for error tracking
• Password protection for security

Environmental Ratings

• Operating Temperature: -20°C to +60°C
• Storage Temperature: -40°C to +70°C
• Protection Class: IP20 for cabinet installation
• Humidity: 95% maximum, non-condensing
• Vibration Resistance: 2g for reliable operation
• Approvals: CE, UL, cULus, FM, RCM, KC

Package Contents & Support

• CPU 1214C unit with built-in I/O
• Required documentation and manuals
• 12-month product warranty included
• Shipping: FedEx, UPS, DHL available
• Delivery: 3-5 business days standard

Common Questions

• What software is needed for programming?
• STEP 7 (TIA Portal) V18 or higher is required for configuration.
• How many analog outputs does this CPU have?
• This model has 2 analog inputs but no built-in analog outputs.
• Can I connect HMI panels directly?
• Yes, through the PROFINET interface for seamless integration.
• What expansion options are available?
• It supports up to 8 signal modules and 3 communication modules.
• Is there a memory card slot?
• Yes, for SIMATIC memory card to expand storage capacity.
