Product details
Product Overview
- Pro-Face PFXGP4201TADW – compact 3.5″ TFT HMI for industrial control.
- Delivers clear QVGA (320×240) resolution with 65,536 colors.
- Resistive touch panel rated for 1,000,000+ operations.
- Runs on 24 Vdc, consumes ≤9.6 W, and withstands harsh environments.
- Ideal for machine automation, process monitoring, and data entry terminals.
Key Technical Data
- Brand: Pro-Face
- Model: PFXGP4201TADW
- Display: 3.5″ TFT LCD, 320×240 (QVGA), 65,536 colors
- Touch Panel: Analog resistive, 1,024 x 1,204 resolution
- Brightness: 8-level software adjustable
- Backlight: White LED, 50,000 hrs life (non-replaceable)
- Serial COM1: RS-232C, up to 115.2 kbps
- Serial COM2: RS-422/485, up to 187.5 kbps (MPI)
- USB: Type A (host) & mini-B (device), USB 2.0
- Voltage: 24 Vdc (19.2–28.8 Vdc), 9.6 W max
- In-rush current: ≤30 A
- Noise immunity: 1,000 Vp-p, 1 µs pulse
- Dielectric strength: 1,000 Vac for 1 min
- Insulation resistance: ≥10 MΩ at 500 Vdc
Environmental & Mechanical
- Operating temp: 0 to 50 °C
- Storage temp: -20 to +60 °C
- Humidity: 10–90% RH (non-condensing)
- Vibration: IEC/EN 61131-2 compliant (5–150 Hz)
- Shock: 147 m/s², 3 times each axis
- Protection: IP65f / NEMA 4X/13 (front panel)
- Dimensions: 132 x 106 x 42 mm
- Panel cut-out: 118.5 x 92.5 mm
- Weight: 0.4 kg
Installation & Commissioning
- Panel cut-out: 118.5 x 92.5 mm, thickness 1.6–5 mm.
- Use M4 screws for secure mounting.
- Functional grounding: 100 Ω or less, 2 mm² wire.
- Natural air cooling – no extra fan needed.
- Software setup via USB or serial ports.
- 8-level brightness adjustment via touch or software.
Compatibility & Connectivity
- Supports PLCs via RS-232C, RS-422/485, and MPI.
- USB-A for external storage or peripherals.
- USB mini-B for PC communication.
- Compatible with Pro-Face screen editor software.
- Multi-language fonts: Japanese, ANK, Chinese, Korean, Thai, Cyrillic.
Certifications & Standards
- IEC/EN 61131-2 compliant.
- IP65f / NEMA TYPE 4X/13 front protection.
- Pollution degree 2 environment.
- CE marked for industrial use.
Package Contents
- PFXGP4201TADW HMI unit
- Mounting gasket
- Installation screws
- Quick start guide
- (Software and cables sold separately)
Warranty & Shipping
- Warranty: 12 months from delivery.
- Shipping: 12–24 hours dispatch.
- Carriers: FedEx, UPS, DHL (express).
Expert Review
- “Reliable 3.5” HMI for tight spaces. The resistive touch handles gloves well. COM2 with MPI support saves cost on adapters.” – Senior Controls Engineer
Manager’s Insight
- “Pro-Face GP4200 series offers a balanced price-performance ratio. Its long backlight life and wide temperature range reduce maintenance visits.” – Product Manager
Applications
- Small to mid-size machine control panels.
- Packaging, textile, and printing machinery.
- HVAC and building automation.
- Test & measurement equipment.
- Remote data entry terminals.
FAQ – Frequently Asked Questions
- What is the backlight service life?
50,000 hours continuous at 25 °C. - Is the backlight user-replaceable?
No. Contact your distributor for replacement. - Can I connect to a Siemens PLC?
Yes via COM2 (RS-422/485) using MPI protocol. - What is the touch panel lifetime?
Over 1,000,000 touches. - Does it support Chinese fonts?
Yes, Simplified/Traditional Chinese via font setting. - What is the inrush current?
30 A maximum. - Is the unit waterproof?
IP65f only when properly installed in an enclosure.
Selection Guide – Tips from Experience
- Choose GP4200 for space-limited panels. Its 3.5″ size fits small cabinets.
- For multi-drop networks, use COM2 (RS-485) for longer distances.
- If you need fast screen switching, 65k colors ensures crisp graphics.
- Always use the provided gasket to maintain IP65 rating.
- Check your PLC communication speed – GP4200 supports up to 187.5 kbps.
