OTB1E0DM9LP is a distributed I/O module from Schneider Electric. It belongs to the Advantys OTB series. This unit works as a bus coupler and I/O slave. It is not a programmable controller. It brings 20 I/O points to your Ethernet network. The module supports Modbus TCP and EtherNet/IP. It fits compact machines and remote panels. The design saves wiring time and panel space.

The module offers 12 digital inputs and 8 digital outputs. Two outputs are solid-state PNP. Six outputs are relay type. Two high-speed counters reach 20 kHz. Two pulse outputs reach 7 kHz. You can add up to 7 TM2 expansion modules. This gives flexible growth for small and medium tasks. The built-in web server helps with setup and checks. Transparent Ready Class A10 adds open Ethernet support.

Note: This model is discontinued. The suggested replacement is TM3BCEIP plus TM3 distributed I/O. Last verified: 2026-09.

Technical Specifications

• Brand: Schneider Electric
• Model: OTB1E0DM9LP
• Series: Advantys OTB
• Device Type: Bus coupler / distributed I/O slave
• Function: Not a programmable controller

• I/O Capacity
  • Digital Inputs: 12
  • Input Type: 24 Vdc, sink/source, Type 1 per IEC 61131-2
  • Digital Outputs: 8
  • Output Split: 2 solid-state PNP 0.3 A + 6 relay 2 A
  • Analog Inputs: None
  • Analog Outputs: None
  • High-Speed Counters: 2 × 20 kHz
  • Pulse Outputs: 2 × 7 kHz pulse generator
  • Expansion Modules: Up to 7 TM2 modules

• Communication
  • Built-in Port: 1 × Ethernet RJ45
  • Speed: 10/100 Mbit/s
  • Protocols: Modbus TCP, Ethernet TCP/IP, web server
  • Conformance: Transparent Ready Class A10
  • Network Interface: EtherNet/IP and Modbus TCP
  • Comms Expansion: None

• Electrical
  • Supply Voltage: 24 V DC
  • Voltage Range: 20.4 to 26.4 V
  • Power Consumption: 19 W
  • Bus Current: 700 mA at 26.2 V

• Environmental
  • Operating Temperature: 0 to +55 °C
  • Storage Temperature: -25 to +70 °C
  • Relative Humidity: 10 to 95%, non-condensing
  • Protection Rating: IP20

• Physical
  • Dimensions: 90 × 55 × 70 mm
  • Weight: 0.195 kg

• Status
  • Lifecycle: Discontinued
  • Replacement: TM3BCEIP + TM3 distributed I/O
  • Last Verified: 2026-09
  • Original Lifecycle Note: Active Advantys OTB distributed I/O on EtherNet/IP, Modbus, CANopen

Installation Guide
