Product details
LR-W500 Keyence 2m Cable Type Sensor – White LED, 30 to 500 mm Range
LR-W500 from Keyence is a white LED cable type sensor. It detects targets from 30 to 500 mm. The spot size changes with distance. Pick from five response times down to 200 µs. The zinc die cast body meets IP65/IP67. This sensor handles fast lines, mixed colors, and wet areas.
- Core Strength: White LED sees color and shine changes better than red light.
- Core Strength: Adjustable spot dial fits tiny or large targets.
- Core Strength: IP67 sealed housing survives dust, water, and washdown.
Technical Data
- Brand: Keyence
- Model: LR-W500
- Module Type: 2m Cable Type Sensor
- Measuring Range: 30 to 500 mm
- Spot Size: ø3.5 mm at 100 mm, ø9 mm at 250 mm, ø18 mm at 500 mm
- Frequency Response: Up to 5 kHz in 200 µs mode
- Sensitivity: Set by spot dial and tuning input
- Linearity: Stable white LED output across full range
- Resolution: Limited by spot size at set distance
- Response Time: 200 µs / 1 ms / 10 ms / 100 ms / 500 ms (selectable)
- Light Source: White LED
- Temperature Range: -20 to +55 °C (no freezing)
- Humidity Range: 35 to 85 % RH (no condensation)
- Environmental Tolerance: IP65/IP67, 10,000 lux incandescent, 20,000 lux sunlight
- Interference Control: Up to 2 units with alternate frequencies
- Power Voltage: 10 to 30 VDC, 10% ripple, Class 2 or LPS
- Current Draw: 65 mA or less at 24 VDC; 120 mA or less at 12 VDC
- Control Output: NPN/PNP open collector, 30 VDC or less, 50 mA or less
- External Input: Tuning or Transmission OFF (selectable)
- Timer Modes: OFF / ON delay / OFF delay / One-shot
- Protection: Reverse power, surge, overcurrent, reverse output
- Body Material: Zinc die cast (nickel chrome plated)
- Weight: 0.17 kg (including cable)
Installation Guide
- Fix the sensor with the bracket or screws.
- Keep the PMMA lens clean and clear.
- Turn the spot dial to match target size.
- Use the tuning input to teach the target.
- Route the 2 m cable away from motors.
- Check the IP67 seal after mounting.
Setup and Care
- Pick a timer mode to stop false triggers.
- Change response time for moving targets.
- Wipe the lens with a soft dry cloth.
- Check output voltage if signals drop.
- Swap the cable if the PVC jacket cracks.
Compatibility Notes
- Works with Keyence amplifiers and controllers.
- Fits NPN or PNP input cards.
- Pairs with standard 10–30 VDC power supplies.
- Avoid direct sunlight above 20,000 lux.
Certifications
- IEC60529 IP65/IP67
- CE marked
- RoHS compliant
Package List
- 1 x LR-W500 Sensor (2 m cable)
- 1 x Mounting bracket
- 1 x Instruction manual
Warranty and Shipping
- Warranty: 12 months
- Dispatch: Within 12–24 hours
- Carriers: FedEx, UPS, DHL
- Tracking number sent after dispatch.
Manager’s Insight
Manager’s Insight: The LR-W500 solves a real headache. Red lasers struggle with shiny or colored parts. White LED handles both. The 200 µs mode catches fast conveyor items. The zinc die cast case takes hits and vibration. IP67 means less cleaning downtime. I recommend it for packaging, electronics, and auto lines. Skip it outdoors unless you add a shade.
Best Fit Equipment and Applications
- Conveyor part detection
- Packaging and labeling machines
- Electronics assembly lines
- Automotive part presence checks
- Food and beverage fill levels
- Keyence amplifier and controller systems
FAQ
Q: How do I choose a response time?
A: Use 200 µs for fast parts. Use 500 ms for stable reads on slow lines.
Q: Can two LR-W500 units run side by side?
A: Yes. Set alternate frequencies. Up to 2 units can work close together.
Q: What is the smallest target I can detect?
A: The spot is ø3.5 mm at 100 mm. Move closer for smaller objects.
Q: How do I clean the sensor safely?
A: Wipe the PMMA lens with a soft dry cloth. Skip solvents and abrasives.
Q: What should I check before buying?
A: Confirm cable length, output type (NPN or PNP), and voltage. Check bracket fit too.
