Honeywell 900P01-0701 AC Power Supply | Series 900 120/240V Module

Product Overview

Honeywell 900P01-0701 is a rugged 120/240VAC Power Supply for industrial control systems. It accepts wide input range 90 to 264 V AC with frequency 47 to 63 Hz. The unit delivers 41W output power with screw terminals for easy wiring. Test jacks provide 5 V DC and 24 V DC for diagnostics. Internal fuse is non-replaceable for safety. Operating temperature -40°C to 70°C with T4 rating.

Model Structure: 900P01-0701

• 900
  • Series: Honeywell Series 900 Power Supply
• P01
  • Type: AC Input Power Supply Module
• 0701
  • Variant: 120/240V AC, 41W output

Key Specifications

• Brand: Honeywell
• Model: 900P01-0701
• Product Type: 120/240V AC Power Supply
• Input Voltage: 90 to 264 V AC, 47 to 63 Hz
• Input Current: 1.4 A max continuous
• Inrush Current: 40 Amps peak-to-peak for 120 ms at 240 V AC
• Input Rating: 130 VA
• Output Rating: 41W
• Fuse: Internal non-replaceable
• Hold-up Time: 20 ms @ 115V AC, 60 Hz max load
• Wiring: Screw terminals, 0.3 mm² to 3.3 mm² (#12-22 AWG)
• Test Jacks: 5 V DC, 24 V DC
• Ambient Temperature: T4, -40°C to 70°C

Installation Guide

• Mounting: Install in Series 900 I/O rack or panel.
• Wiring: Use screw terminals. Wire size #12-22 AWG.
• Grounding: Follow local electrical codes. Ensure proper earth ground.
• Test Points: Use test jacks to verify 5V and 24V outputs.

Maintenance Tips

• Inspection: Check terminals annually for tightness.
• Cleaning: Keep vents clear of dust. Use dry compressed air.
• Fuse Warning: Internal fuse is non-replaceable. Do not attempt to open.
• Temperature: Ensure adequate ventilation for -40°C to 70°C operation.

Package Contents

• Includes: Honeywell 900P01-0701 power supply module, installation manual.
• Warranty: 12 months against manufacturing defects.
• Note: Fuse is internal and non-serviceable.

Shipping Options

• Couriers: FedEx, UPS, DHL express worldwide.
• Packaging: Anti-static protective box with foam.

Typical Applications

• Control Panels: Powers Honeywell Series 900 I/O modules.
• Industrial Automation: Provides 24V DC to field devices.
• Process Plants: Reliable AC to DC conversion in harsh environments.
• Test Benches: Use test jacks for troubleshooting.

Key Benefits

• Wide Input Range: 90-264V AC works globally.
• Rugged Design: -40°C to 70°C operation for extreme sites.
• Easy Wiring: Screw terminals accept #12-22 AWG.
• Built-in Test Points: Quick voltage checks without meters.

Expert FAQs

• Q: What happens if the internal fuse blows?A: The fuse is non-replaceable. The entire module must be replaced. This ensures safety and prevents improper repairs.
• Q: Can I use this supply on 120V and 240V without switching?A: Yes, it auto-ranges from 90 to 264V AC. No manual switch needed.
• Q: What is the purpose of the test jacks?A: They provide safe access to 5V and 24V DC for diagnostics. Plug meter leads directly to check output.
• Q: How much inrush current should I expect?A: 40 Amps peak for 120 ms at 240V. Design your circuit breakers to handle this.
• Q: What wire size fits the screw terminals?A: Accepts 0.3 mm² to 3.3 mm² (AWG #12 to #22). Use proper ferrule for stranded wire.
• Q: Does the 12-month warranty cover the non-replaceable fuse?A: Warranty covers defects. If fuse blows due to internal fault, module is replaced. External overcurrent not covered.
• Q: How fast is shipping for urgent needs?A: FedEx, UPS, DHL express deliver in 2-3 days. Tracking provided.
• Q: Can this supply power 24V DC field instruments?A: Yes, 41W total. Calculate load: 24V at 1.7A max approx. Ensure total stays under 41W.
• Q: What is T4 temperature rating?A: T4 means surface temperature below 135°C. Safe for hazardous locations with proper enclosure.

Selection Guide

• Choose 900P01-0701 if: You need 41W AC/DC for Series 900 racks. Wide temperature range required. Global voltage compatibility needed.
• Alternative: For higher power, consider 900P01-0702 (higher wattage). For DC input, use 900P01-0801 series.
• Installation Tip: Use twisted pair for AC wiring to reduce noise. Keep AC and DC wires separate.
• Spare Strategy: Stock one spare module. Non-replaceable fuse means quick swap on failure.
• Test Point Use: Label test jacks in panel for easy technician access. Saves troubleshooting time.
