HG-MR23 Mitsubishi HG/MELSERVO-J4 High-Speed Servo Motor

HG-MR23 Servo Motor – High Precision Motion Control

The HG-MR23 servo motor delivers advanced sensing technology. It captures the most intricate movements with high accuracy. This model ensures smooth and reliable operations for robotics, manufacturing machinery, and automated assembly lines. As a key part of Mitsubishi HG / MELSERVO-J4 series, the HG-MR23 combines compact design with powerful performance.

Rated capacity: 0.2 kW. Rated speed: 3000 RPM. Max speed: 6000 RPM. Straight shaft type. Dual encoder: absolute and incremental. IP65 protection class. Dimensions: 60 x 77.1 x 76.6 mm. Weight: 910 grams. Easy to integrate into space-limited systems.

Mitsubishi HG-MR23 works with 200 Volts AC power supply. Rated torque: 0.64 Nm. Maximum torque: 1.9 Nm. Inertia: 0.0865 kg·cm². No brake included. Ideal for applications needing both finesse and force.

Technical Specifications

• Brand: Mitsubishi
  • Model: HG-MR23
  • Series: HG / MELSERVO-J4
• Power & Performance:
  • Rated Capacity: 0.2 kW
  • Rated Torque: 0.64 Nm
  • Maximum Torque: 1.9 Nm
  • Rated Speed: 3000 RPM
  • Maximum Speed: 6000 RPM
  • Inertia: 0.0865 kg·cm²
  • Power Supply: 200 Volts AC
• Physical Characteristics:
  • Shaft Type: Straight shaft
  • Brake: No
  • Protection Class: IP65
  • Dimensions: 60 x 77.1 x 76.6 mm
  • Weight: 910 grams (1.36 kg / 3.00 lbs)
• Encoder & Feedback:
  • Encoder Type: Absolute and Incremental
  • Linear Resolution: Up to 4,194,304 pulses/rev
• Environmental Tolerance:
  • Operating Temperature: 0 to +40 °C
  • Storage Temperature: -15 to +70 °C
  • Ambient Humidity: 5% to 90% RH (non-condensing)
  • Vibration Resistance: 5.9 m/s² at 10 to 55 Hz
  • Noise Immunity: High resistance to electrical interference

Installation Guide

• Mounting:
  • Flat and rigid surface only
  • Keep 10 mm clearance for cooling
• Coupling:
  • Use straight shaft coupler
  • Ensure balanced alignment
• Electrical:
  • Connect 200V AC power supply
  • Follow Mitsubishi wiring diagrams

Debugging & Maintenance Ease

• Plug-and-play with MELSERVO-J4 amplifiers
• Auto-tuning reduces setup time
• Front panel LED indicates status
• Easy access to encoder connector
• No brake means fewer moving parts

Compatibility

• Drives:
  • Mitsubishi MELSERVO-J4 series
  • MR-J4-10B to MR-J4-40B amplifiers
• Accessories:
  • HG series cables
  • HG series mounting brackets
• Protocols:
  • Absolute communication
  • Incremental communication

Certifications

• CE marked
• UL recognized
• RoHS compliant
• IP65 tested (IEC 60529)

Package Contents

• 1 x HG-MR23 servo motor
• 1 x straight shaft key
• 1 x mounting screws set
• 1 x quick start guide
• No brake unit included

Warranty & Shipping

• Warranty:
  • 12-month warranty from purchase date
• Shipping:
  • 12-24 hour dispatch for in-stock items
  • Express couriers: FedEx, UPS, DHL
  • Tracking number within 24 hours

Expert Review

The HG-MR23 excels in high-speed, low-inertia applications. Its dual encoder feedback removes the need for separate limit sensors. The straight shaft simplifies coupling, reducing installation errors. IP65 rating makes it reliable in dusty or wet environments. For 0.2 kW class motion control, this motor offers excellent value and Mitsubishi build quality.

Manager‘s Insight

We recommend the HG-MR23 for upgrade projects from older MR-J2S systems. Its 6000 RPM max speed suits pick-and-place and high-speed conveyors. The compact size saves cabinet space. Stock levels are stable, and spare parts remain available. A solid choice for OEMs seeking certified, long-life servo motors.

Suitable Devices & Applications

• Robotic arms (assembly and soldering)
• CNC routers and engraving machines
• Automated pick-and-place systems
• Labeling and packaging machines
• Small conveyor drives
• Medical device positioning stages

Frequently Asked Questions (FAQ)

Q: Can I use this motor without a brake?
A: Yes. The HG-MR23 has no brake. For vertical loads, add an external brake or use a different model.

Q: Does it support absolute positioning after power loss?
A: Yes. The absolute encoder retains position data. No homing routine needed on restart.

Q: What drive works best with HG-MR23?
A: Use MR-J4-10B or MR-J4-20A from MELSERVO-J4 series.

Q: Is the shaft key included?
A: Yes. The straight shaft key is inside the package.

Q: How do I clean the motor?
A: Wipe with a dry cloth. IP65 allows low-pressure water rinse, but avoid high-pressure jets.

Q: Can it replace a 3300 5mm Proximity Probes system?
A: No. That is a different sensor type. For vibration or position monitoring, see 5mm Proximity Probes.

Q: What is the maximum cable length?
A: Keep encoder cables under 30 meters. Power cables up to 20 meters for full torque.

Q: Can I use this with non-Mitsubishi drives?
A: Not recommended. Encoder protocol is proprietary to Mitsubishi J4 series.

Q: Does the motor get hot at full load?
A: Surface temperature may reach 80°C. This is normal under rated conditions.

Selection Guide

• Torque needs:
  • Need 0.64 Nm rated torque? Choose HG-MR23.
  • For higher torque, select HG-MR43 (1.3 Nm) or HG-MR73 (2.4 Nm).
• Axis type:
  • Vertical axis applications require a brake – pick HG-MR23B.
  • Horizontal axis – HG-MR23 works fine.
• Environment:
  • Harsh washdown? IP65 is sufficient.
  • For submersion, choose IP67 models.
• Shaft preference:
  • Straight shaft reduces cost and alignment time.
  • Keyway shaft available on request.

Product Title (SEO optimized, ≤65 chars):
HG-MR23 Mitsubishi Servo Motor HG Series 0.2kW 6000rpm

Alternative SEO Title:
Mitsubishi HG-MR23 HG/MELSERVO-J4 High-Speed Servo Motor

Meta Description (≤156 chars):
Mitsubishi HG-MR23 servo motor, 0.2kW, 6000rpm, IP65, absolute encoder, 12mo warranty, 24h ship. For robots & conveyors.

For inquiries: sales@powergearx.com | +86 18030005825
