Name: GT27-R2-Z Mitsubishi GOT2000 RGB Input Unit – Dual-Channel Video Input
SKU: GT27-R2-Z
Availability: InStock

Product details

GT27-R2-Z – Mitsubishi GOT2000 RGB Input Unit

Bring external video sources to your GT27 HMI. Dual-channel analog RGB input for cameras, PCs, or other displays.

▶ General Info
- ▪ Brand: Mitsubishi Electric
- ▪ Model: GT27-R2-Z
- ▪ Series: GOT2000 Series
- ▪ Type: RGB input unit (external video source adapter)
- ▪ Compatibility: GT27 model only
▶ Input Specs
- ▪ Input channels: 2 channels (one RGB screen per channel)
- ▪ Connector: D-Sub 15-pin female (each channel)
- ▪ Signal type: Analog RGB
- ▪ Sync signal: TTL level, 1 Vp-p, 75 Ω impedance
▶ Supported Resolutions
- ▪ XGA: 1024 x 768 pixels
- ▪ SVGA: 800 x 600 pixels
- ▪ VGA: 640 x 480 pixels
- ▪ Auto-detects input resolution
▶ Power & Physical
- ▪ Current consumption: 0.49 A at 3.3 V DC / 0.35 A at 5.0 V DC
- ▪ Weight: approx. 0.33 kg (with GT27-IF1000 interface converter)
- ▪ Installation: Plugs into GT27 rear expansion slot

💡 Expert Review – “Flexible Video Integration”
“The GT27-R2-Z turns your GT27 HMI into a central display hub. Connect two external RGB sources like PC screens or cameras, then view them directly on the HMI. Great for machines where operators need to see camera feeds alongside control data.” — Senior Integration Engineer
📊 Manager’s Insight – “Reduce Panel Clutter”
Instead of adding separate monitors for each video source, this unit consolidates everything into one HMI screen. Saves panel space and simplifies operator training. With 12-month warranty and quick shipping, it’s a smart upgrade for production lines.

✅ Compatible devices: Mitsubishi GT27 series HMIs (GOT2000 platform).
✅ Ideal applications:
- ▪ Machine vision: show camera feed next to machine data.
- ▪ PC integration: display computer screen on HMI for guidance.
- ▪ Security monitoring: view surveillance cameras on operator panel.
- ▪ Training setups: share instructor screen with trainees.
- ▪ Process control: combine external video with HMI controls.

Q: Can I display both input channels at the same time?
A: Yes, but one at a time on screen. You can switch between channels via HMI programming or touch buttons. Both inputs are always available.
Q: What type of devices can I connect?
A: Any device with analog RGB output (D-Sub 15-pin). Examples: industrial cameras, desktop PCs, legacy video sources, and some document cameras.
Q: Do I need extra software to use this unit?
A: Simple setup via GT Designer3. Enable RGB input function and assign display areas. No complex coding required.
Q: What is the maximum cable length for stable signal?
A: Up to 10 meters (33 ft) with quality shielded VGA cable. For longer runs, use a VGA extender or signal booster.
Q: Can I record the video input to a CF card?
A: This unit only displays input, it does not record. For recording, use GT27-MMR-Z multimedia unit (sold separately).

📦 What’s included: GT27-R2-Z unit, installation screws, quick guide.
🛡️ Warranty: 12 months against defects. Free technical support via email or WhatsApp.
🚚 Fast shipping: Orders ship in 12–24 hours after payment. Carriers: FedEx, UPS, DHL with tracking.
💡 Expert tip: Before connecting, verify your external device outputs analog RGB (not HDMI or DVI). Use short, shielded cables to avoid interference in noisy factory environments.
✅ Why choose this unit: Adds dual external video inputs without extra monitors. Keeps operator focus on one screen. Simple plug-and-play expansion for GT27 HMI.
