Product Snapshot

• ABB FEN-31 is an HTL encoder interface module.
• It reads HTL encoder signals for ABB drives.
• It also emulates a TTL encoder output.
• It adds position latch inputs for fast capture.
• It suits speed and position feedback tasks.
• Small size, simple wiring, clear LED status.

Key Data

• Brand: ABB
• Model: FEN-31
• Type: HTL Encoder Interface
• Max. power use: 350 mA at 24 V
• Total power budget: 5 W for encoders, latches, and cables
• Protection class: IP20
• Ambient conditions: same as the drive hardware manual
• Isolation: HTL input isolated with digital inputs
• TTL output isolation: separate from HTL input and control board

Port and Connector Layout

• One 20-pin socket.
• Two 7-pin detachable plugs, max 2.5 mm² wire, torque 0.5 N·m.
• One 9-pin D-Sub.
• One 6-pin detachable plug, max 1.5 mm² wire, torque 0.3 N·m.
• Plugs are removable for faster service.

HTL Input Tree (X81 and X82)

• Encoder Supply
  • +15 V DC ± 20%, 200 mA max, for HTL encoders
  • +24 V DC ± 20%, 200 mA max, for HTL encoders
  • External supply range: 10 to 24 V DC
• Channels
  • A, B, and Z are supported
  • Signal frequency up to 300 kHz
  • Long cables or single-ended encoders may limit high frequency
  • Logic “0” is below 3.5 V
  • Logic “1” is above 7.5 V
• Encoder Types
  • Differential push-pull HTL, 10 to 24 V supply
  • Single-ended push-pull HTL, 15 to 24 V supply
  • Open collector HTL, 15 to 24 V supply
  • Open emitter HTL, 15 to 24 V supply
• Cable Length by Type
  • 300 m for differential push-pull
  • 200 m for single-ended push-pull
  • 100 m for open collector or open emitter
• Performance
  • Speed range: -32768 to 32767 rpm
  • Speed resolution: 0.04 RPM (24 bits)
  • Position resolution: 16 M per rev (24 bits)
  • Position accuracy: 4x pulse count per rev

TTL Emulation Output Tree (X83)

• Emulation
  • TTL incremental encoder emulation
  • 1 to 65535 pulses per rev
  • Reference mark supported
• Signals
  • CH A, CH B, CH Z
  • RS-422 or RS-485 level
  • 500 kHz max
• Limits
  • Max cable length 100 m
  • Speed range: -32768 to 32767 rpm
  • Position resolution: 4x pulse count per rev

Latch Inputs and LEDs

• Latch Inputs (X84)
  • Output +24 V DC ± 15%, short-circuit proof
  • Below 5 V means 0
  • Above 15 V means 1
  • Isolated with the TTL encoder input
• STATUS LED
  • Green: OK
  • Orange: not initialized or control link fault
  • Red: not in use
• ENC ST LED
  • Green: encoder OK
  • Orange: encoder fault
  • With ACS880, status updates after fault reset

Expert Review

• Signal load is modest: 350 mA at 24 V.
• The 300 kHz input covers most fast feedback loops.
• Four encoder types mean fewer extra parts.
• Long cable support helps large machines.
• Isolation cuts noise between power and logic.
• LEDs make first checks quick.
• Plan cable type before you order.

Manager’s Insight

• Match the encoder type to the cable length table.
• Differential push-pull gives the longest runs.
• Open collector setups need shorter cables.
• Check drive ambient limits in its manual.
• IP20 means a clean cabinet is required.
• Keep spare detachable plugs on site.

Best Fit Equipment and Applications

• ABB drives that accept FEN option modules.
• Speed feedback on motors and rollers.
• Position feedback on conveyors and lifts.
• Latch capture on moving parts.
• TTL input cards that need an HTL source.
• Retrofit jobs with old HTL encoders.
• Paper, metal, and packaging lines.
• Crane and hoist motion control.

Installation Notes

• Power off the drive before you fit the module.
• Use shielded cable for encoder runs.
• Keep signal cable away from motor cables.
• Tighten plugs to the stated torque.
• Check LEDs after power up.
• Confirm encoder supply voltage first.

Setup and Care

• Set encoder pulses in the drive.
• Test at low speed before full run.
• Watch ENC ST for fault signs.
• Reset faults, then recheck LED state.
• Clean dust from the cabinet.
• Re-seat plugs after service.

Fit and Limits

• Works with differential push-pull HTL encoders.
• Works with single-ended push-pull HTL encoders.
• Works with open collector HTL encoders.
• Works with open emitter HTL encoders.
• TTL output feeds RS-422 or RS-485 inputs.
• No TTL input on this module.
• No safety certification data in the source.

FAQ

• Q: Can I use a 5 V encoder?
• A: No. The HTL input needs 10 to 24 V supply, or 15 to 24 V for some types.
• Q: Why does my signal drop at high speed?
• A: Long cable or a single-ended encoder can cause this. Shorten the run or switch to differential.
• Q: What does an orange STATUS LED mean?
• A: The module is not initialized or the control link has a fault.
• Q: Does the ENC ST LED clear by itself?
• A: With ACS880, it updates after you reset the encoder fault.
• Q: How do I pick the right module version?
• A: Check your drive option slot, encoder type, cable length, and needed TTL output.
• Q: What is the warranty?
• A: 12 months.
• Q: How fast do you ship?
• A: We dispatch in 12 to 24 hours by FedEx, UPS, or DHL.
