EVS9322-CSV003 Lenze 9300 Servo Inverter: 0.75 kW Cold-Plate Drive
The EVS9322-CSV003 is a compact servo inverter from the Lenze 9300 Servo family. It comes in a cold-plate design. The rated motor power is 0.75 kW at 400 V. Output current is 2.5 A at 8 kHz. Peak current reaches 3.8 A. Field-oriented servo control runs both synchronous and asynchronous motors. The V003 code marks the software variant. This drive fits tight cabinets where air cooling is not an option.
Technical Data
- Brand: Lenze
- Model: EVS9322-CSV003
- Series: Global Drive 9300 Servo Inverters
- Type: Standard servo inverter, cold-plate design
- Software variant: V003
- Rated motor power: 0.75 kW at 4-pole, 400 V
- Rated output current: 2.5 A at 8 kHz switching frequency
- Max output current: 3.8 A at 8 kHz, 150% overload mode
- Control: field-oriented servo control (SC)
- Motor types: synchronous and asynchronous servo motors; standard async motors
- Analog inputs: 2, ±10 V (switchable 0 to 20 mA), 11 bits plus sign
- Analog outputs: 2, 9 bits plus sign
- Digital inputs: 6 (1 controller enable plus 5 free), PLC level per IEC 61131-2
- Digital outputs: 4, 50 mA each
- Resolver input: Sub-D 9-pin
- Encoder input: multi-encoder for TTL/SinCos and Hiperface absolute encoders
- Frequency input/output: two-track each, Sub-D 9-pin
- Supply voltage: 3/PE AC 320 to 528 V, 45 to 65 Hz
- DC supply: 460 to 740 V DC
- Power loss at 400 V: 110 W
- Operating temperature: 0 to +55 °C; derate 2.5% per °C above +40 °C
- Storage temperature: -25 to +55 °C
- Humidity: average 85% RH, non-condensing (3K3 per EN 50178)
- Protection rating: IP20
- Dimensions (H×W×D): 350 × 78 × 158 mm, cold-plate design
- Weight: not published for the cold-plate variant; built-in design is 3.5 kg
Order Code Tree
- EVS9322-CSV003
- EVS – servo inverter platform
- 9322 – 9300 servo size class
- 93 – 9300 Servo family
- 22 – 0.75 kW power step
- -CSV003 – hardware and software option block
- C – cold-plate design (flat rear cooling surface)
- SV – servo control firmware
- 003 – software variant number
Communication and Compatibility
- X4 carries the CANopen system bus.
- X1 AIF slot takes a keypad or a comms module.
- Module options: PROFIBUS DP (EMF2133IB), DeviceNet (EMF2179IB), INTERBUS (EMF2113IB), LECOM A/B (EMF2102IB).
- The multi-encoder port accepts TTL, SinCos and Hiperface types.
- Lenze confirms an i950 migration path with a compatibility switch.
- No same-code drop-in replacement exists.
Installation Guide
- Mount the flat rear surface onto a cooled plate.
- Apply thermal paste for best heat transfer.
- Keep the cold plate temperature within spec.
- Wire PE before you apply power.
- Use shielded cable on encoder and resolver lines.
- Leave front clearance for plugs and setup.
Setup and Maintenance
- Enter motor data before the first run.
- Tune the servo loop with the Lenze tool.
- Assign the 5 free digital inputs to your logic.
- Check plate contact at each service stop.
- Inspect encoder plugs for wear.
- Log current peaks to spot load drift.
Certification and Lifecycle
- Audit status: DERIVED_CROSS_REF.
- The 0 to +55 °C range is not UL-approved.
- Humidity class follows EN 50178.
- This code is legacy; Lenze lists it on the previous-products page.
- Last verified: 2026-10.
Packing List and Warranty
- One EVS9322-CSV003 servo inverter
- Printed quick-start guide
- 12-month warranty on the unit
- 12-24 hour dispatch after order confirmation
- Shipping by FedEx, UPS or DHL
Expert Review
The EVS9322-CSV003 packs strong servo control into a slim body. The cold plate saves cabinet air. Field-oriented control handles both motor types well. The multi-encoder port adds real flexibility. But the slim build needs a good cooling plate. Buyers must plan the thermal path first. As a legacy part, spare modules matter. For small axis retrofits, it is a neat and reliable choice.
Manager’s Insight
This unit sells to machine builders with tight panels. Cold-plate demand stays steady in compact cells. Pair each sale with an encoder cable quote. Confirm the V003 software code against the old label. The i950 path gives you a clear upsell story. Quick dispatch and a 12-month warranty reduce risk. Hold one unit for urgent axis failures.
Best Fit Applications
- Small servo axes in packaging machines
- Labeling and printing equipment
- Compact handling and pick-and-place cells
- Textile and winding drives
- Sealed cabinets with shared cooling plates
- Retrofits of existing 9300 servo panels
FAQ
Q: What makes the cold-plate design different?
A: Heat leaves through the flat rear face. You bolt it to a cooled plate. No cabinet air stream is needed.
Q: Which encoder types can I connect?
A: The multi-encoder port takes TTL and SinCos incremental types. It also reads Hiperface absolute encoders.
Q: Is the full temperature range UL-approved?
A: No. Lenze states the 0 to +55 °C range is not UL-approved. Check your local rules first.
Q: From repair experience, what wears out first?
A: Plate contact and encoder plugs. Poor thermal contact shortens life. Clean and re-paste at service.
Q: How do I plan a future upgrade?
A: Lenze confirms the i950 copies 9300 servo behaviour with a compatibility switch. Plan the swap early.
Q: What are the delivery and warranty terms?
A: Each drive has a 12-month warranty. We ship in 12-24 hours by FedEx, UPS or DHL.
Buying Guide
- Match motor current to the 2.5 A rating.
- Confirm the CSV003 code on your old unit.
- Check your encoder type before you order.
- Plan a cooled plate for the rear face.
- List the fieldbus your panel uses.
- Ask us for a fit check before purchase.
