Name: E82EV552-4C040 Lenze 8200 Vector Drive 5.5 kW EMC Filter
SKU: E82EV552-4C040
Price: 214.00 USD
Availability: InStock

Product details

Product Overview

Model E82EV552-4C040 is a Lenze 8200 vector frequency inverter.
It drives a 5.5 kW four-pole asynchronous motor with reliable control.
This panel-mounted E design includes an integrated EMC filter.
The x4x variant adds Safe Torque Off (STO) for safer machine stops.
It supports V/f control, vector control, and sensorless torque control.
Rated output current is 13.0 A at 8 kHz switching frequency.
Max output current reaches 19.5 A for 60 s under periodic load.
This inverter suits conveyors, pumps, fans, and general machine drives.
Lenze lists the 8200 vector as a legacy series with a clear migration path.
The official path leads to the i950 drive generation.

Technical Specifications

Brand: Lenze
Model: E82EV552-4C040
Series: 8200 vector
Rated motor power: 5.5 kW typical, four-pole three-phase asynchronous motor
Rated output current: 13.0 A nominal at 8 kHz switching frequency
Max output current: 19.5 A for 60 s, periodic load change cycle
Overload: 1.8 x rated torque for 60 s when rated motor power equals rated controller power
Motor control: V/f characteristic control (linear/quadratic), vector control, sensorless torque control
Switching frequency: 2 / 4 / 8 / 16 kHz, noise-optimised setting
Max output frequency: 0 to 650 Hz
Supply voltage: 3/PE 320 to 550 V AC, 45 to 65 Hz; alternative DC 450 to 775 V DC
Power loss: 230 W at rated current and 8 kHz
Operating temperature: -10 to +55 °C, derated by 2.5 %/°C above +40 °C
Storage temperature: -25 to +60 °C
Relative humidity: average 85 % RH, without condensation, climatic class 3K3 per EN 50178
Protection rating: IP20 per EN 60529; IP41 with push-through thermally separated mounting
Dimensions (H x W x D): 240 x 125 x 140 mm
Weight: 3.6 kg
Built-in ports: control terminals X3 with digital inputs, analog input/output, and relay output K1
Protocols: none onboard; no integrated fieldbus or Ethernet
Communication expansion: plug-in I/O and fieldbus option modules, such as E82ZAFSC010 Standard I/O and E82ZAFAC010 Application I/O
Measurement range, frequency response, sensitivity, linearity, resolution: not specified in the supplied data
Environmental resistance: designed for cabinet-mounted industrial use within the stated temperature and humidity limits
Interference immunity: integrated EMC filter supports compliant installation in industrial environments

Installation Guide

Mount the unit vertically inside a clean control cabinet.
Keep the specified clearance for heat dissipation.
Use the push-through mounting option for IP41 protection.
Connect the motor cable with proper shielding and grounding.
Wire control terminals X3 for digital and analog signals.
Use relay output K1 for status or fault signalling.
Check supply voltage against the 320 to 550 V AC range.
Follow Lenze EMC wiring rules to reduce noise.
Derate output above +40 °C ambient temperature.
For safe torque off, wire the STO function per the x4x variant requirements.

Commissioning and Maintenance Convenience

Set motor data and control mode through the standard parameter structure.
Choose linear or quadratic V/f curves for simple pump and fan duty.
Use vector control for better torque behaviour at low speed.
Select 2, 4, 8, or 16 kHz switching frequency for noise and load balance.
The integrated EMC filter reduces external filter work.
Plug-in option modules simplify later I/O or fieldbus upgrades.
Keep spare fans and clean air paths for long service life.
Record parameter sets for quick replacement or migration.

Compatibility Notes

Matches a 5.5 kW four-pole asynchronous motor at rated current.
Works with standard three-phase industrial supply systems in the stated range.
Accepts plug-in Lenze option modules for expanded I/O and fieldbus use.
No onboard fieldbus or Ethernet port is present.
Lenze confirms no drop-in same-order-code replacement for newer drives.
Lenze confirms that the i950 emulates 8200 vector behaviour via the i950 PROFIBUS module and L_ICIP library.
Plan migration with Lenze AKB articles 321231 and 316137 for 8200 vector, 9300, 8400, and 9400 families.
Check motor insulation and cable length before commissioning.

Certification and Compliance Information

Protection rating follows EN 60529.
Climatic class follows 3K3 per EN 50178.
Integrated EMC filter supports industrial EMC compliance when installed correctly.
Safe Torque Off is included in the x4x variant for machine safety integration.
Confirm local panel and machinery directives before final installation.
Audit status: OFFICIAL_VERIFIED.

Packing List and Warranty

1 x Lenze E82EV552-4C040 8200 vector inverter
1 x safety and installation information set
12-month warranty included
12 to 24 hour dispatch for in-stock orders
Shipping by FedEx, UPS, or DHL
Tracking details sent after dispatch

Expert Review

The E82EV552-4C040 remains a practical choice for legacy machine upgrades.
Its integrated EMC filter saves panel space and wiring effort.
STO support adds real value for safer maintenance access.
Vector control gives solid performance for conveyors and mixers.
The main limit is the missing onboard fieldbus port.
Buyers should plan option modules or a future i950 migration.
Stock spare units if downtime is costly on existing lines.

Manager’s Insight

Treat this model as a proven legacy drive, not a current flagship.
Confirm the exact x4x STO wiring before quoting a replacement.
Check cabinet temperature and derating above +40 °C.
Bundle spare units and parameter backups for critical machines.
For new designs, compare the i950 path with this 8200 vector unit.
For urgent repairs, ask about stock and same-day packing.

Best-Fit Equipment and Applications

Conveyor lines and material handling systems
Pumps and fans with variable speed demand
Mixers, agitators, and simple process machines
Packaging and textile machinery
Legacy production cells using Lenze 8200 vector drives
Retrofit projects that need a known, documented drive platform

FAQ

Is the E82EV552-4C040 a current Lenze product?
No. Lenze lists the 8200 vector as a previous product series.
Can I replace it with an i950 directly?
Not as a same-order-code drop-in. Lenze confirms a migration path with i950 emulation support.
Does this model have an onboard fieldbus?
No. It has no integrated fieldbus or Ethernet port.
How do I add fieldbus or extra I/O?
Use Lenze plug-in option modules such as E82ZAFSC010 or E82ZAFAC010.
What motor does it suit?
A 5.5 kW four-pole asynchronous motor with a rated current near 13.0 A.
Can it run above +40 °C?
Yes, with derating of 2.5 % per °C above +40 °C.
What is the max output frequency?
0 to 650 Hz.
Does it include a safety function?
Yes, the x4x variant includes Safe Torque Off.
What is the protection rating?
IP20, or IP41 with push-through thermally separated mounting.
How fast does shipping take?
In-stock orders dispatch in 12 to 24 hours by FedEx, UPS, or DHL.
What warranty applies?
A 12-month warranty is included.
How do I choose between repair and replacement?
Compare fault history, spare availability, and the cost of an i950 migration.
What should I check before buying a used or legacy unit?
Check the x4x STO variant, firmware, parameter backup, and cabinet history.
Can this drive handle high starting torque?
Yes within its overload rating: 1.8 x rated torque for 60 s.
What should I confirm before ordering?
Confirm supply voltage, motor current, STO need, and option module plan.
