Name: E82EV402K4C200 Lenze 8200 vector Drive, 9.5 A, Panel Mount
SKU: E82EV402K4C200
Price: 214.00 USD
Availability: InStock

Product details

E82EV402K4C200 Lenze 8200 vector Frequency Inverter

The E82EV402K4C200 is a panel-mounted drive from the Lenze 8200 vector series. It runs a 4.0 kW four-pole asynchronous motor. Rated output current is 9.5 A at 8 kHz. The unit delivers 14.2 A for 60 s on periodic loads. This is the 2xx design variant, so it ships without an integrated EMC filter. Control modes include V/f, vector control, and sensorless torque control.

Technical Specifications

Brand: Lenze
Model: E82EV402K4C200
Series: 8200 vector
Module type: Panel-mounted frequency inverter (E design)
Rated motor power: 4.0 kW typical, 4-pole three-phase asynchronous motor
Rated output current: 9.5 A nominal at 8 kHz switching frequency
Max output current: 14.2 A for 60 s, periodic load change cycle
Overload: 1.8 x rated torque for 60 s when rated motor power equals rated controller power
Motor control: V/f characteristic (linear or quadratic), vector control, sensorless torque control
Switching frequency: 2 / 4 / 8 / 16 kHz, noise-optimised setting
Output frequency range: 0 to 650 Hz
Supply voltage: 3/PE 320 to 550 V AC (45 to 65 Hz); alternative DC 450 to 775 V DC
Power loss: 180 W at rated current and 8 kHz
Operating temperature: -10 to +55 °C; derate 2.5 % per °C above +40 °C
Storage temperature: -25 to +60 °C
Humidity tolerance: average 85 % RH, no condensation, climatic class 3K3 per EN 50178
Protection rating: IP20 (EN 60529); IP41 with push-through thermally separated mounting
Dimensions (H x W x D): 240 x 100 x 140 mm
Weight: 2.9 kg
Built-in ports: control terminals X3 with digital inputs, analog input/output, relay output K1
Onboard fieldbus or Ethernet: none
Integrated protocol: none; fieldbus and extra I/O come from plug-in option modules, e.g. E82ZAFSC010 Standard I/O and E82ZAFAC010 Application I/O
Noise immunity: designed for industrial EMC environments per EN 50178 climatic class 3K3; add an external EMC filter for the 2xx variant where site rules demand it

Installation Guide

Mount the unit vertically on a panel. Keep the heatsink clear.
Use push-through thermally separated mounting to reach IP41.
Feed 3/PE 320 to 550 V AC or DC 450 to 775 V. Check terminal X3 wiring first.
Derate 2.5 % per °C above +40 °C. Do not exceed +55 °C.
Fit an external EMC filter when local rules require one. This 2xx variant has none inside.
Keep humidity at or below 85 % RH with no condensation.

Commissioning and Maintenance

Set motor data first. Then pick V/f, vector, or sensorless torque mode.
Choose 2, 4, 8, or 16 kHz switching frequency to balance noise and loss.
Run the autotune routine for vector mode to improve low-speed torque.
Check the heatsink and fan airflow at each service visit.
Inspect DC bus capacitors on ageing units. Legacy drives deserve a yearly check.
Keep spare option modules on hand. Plug-in I/O cuts downtime.

Compatibility Notes

Matches 4.0 kW four-pole three-phase asynchronous motors.
Works with Lenze plug-in I/O and fieldbus modules, such as E82ZAFSC010 and E82ZAFAC010.
No drop-in same-order-code replacement exists. Lenze confirms the i950 emulates 8200 vector behaviour via the i950 PROFIBUS module and the L_ICIP library.
That migration path covers 8200 vector, 9300, 8400, and 9400 per Lenze AKB articles 321231 and 316137.
The official Lenze previous-products page stays active. Plan the move to a newer drive generation.

Certifications and Compliance

Protection rating IP20 per EN 60529.
Climatic class 3K3 per EN 50178.
Audit status: OFFICIAL_VERIFIED, last verified 2026-10.
Confirm site-specific approvals with your panel builder before install.

Packing List and Warranty

1 x Lenze E82EV402K4C200 panel-mounted inverter
1 x terminal and wiring guide
12-month warranty on the unit
Dispatch within 12 to 24 hours
Shipping by FedEx, UPS, or DHL

Expert Review

The 8200 vector is a proven workhorse. Its 1.8 x overload for 60 s suits pumps, fans, and conveyors with short peaks. The 0 to 650 Hz range covers most general tasks. Buyers should note two points. First, the 2xx variant lacks an internal EMC filter, so budget for one. Second, this is a legacy drive. Stock spares now or plan the i950 migration with Lenze support.

Manager’s Insight

Demand for the E82EV402K4C200 stays steady because many lines still run 8200 vector drives. Keep a buffer stock. Pair each sale with an option module and an EMC filter to cut repeat calls. Push the i950 path for new builds. That protects the customer and our margin.

Best Fit Equipment and Applications

Pumps and fans with moderate starting torque
Conveyors and material handling lines
Packaging and textile machines
Retrofit of existing 8200 vector panels
General 4.0 kW three-phase motor control in IP20 cabinets

FAQ

Does this model include an EMC filter?
- No. The 2xx design variant ships without one. Add an external filter where rules demand it.
Can I run a 4.0 kW motor at full load?
- Yes, at 9.5 A and 8 kHz. Short peaks reach 14.2 A for 60 s.
Is a fieldbus port built in?
- No. Fit a plug-in module such as E82ZAFSC010 for fieldbus or extra I/O.
What happens above +40 °C?
- Derate 2.5 % per °C. The ceiling is +55 °C.
Is there a direct replacement?
- No same-code drop-in exists. The i950 emulates 8200 vector behaviour with the PROFIBUS module and L_ICIP library. From experience, plan a day for wiring and parameter transfer per unit.
How fast do you ship?
- Within 12 to 24 hours by FedEx, UPS, or DHL.

Buying Guide

Check your motor nameplate first. Match 4.0 kW and 9.5 A before you order.
Decide on EMC. The 2xx variant needs an external filter in most plants.
List the I/O you need. Pick the option module before checkout.
For new machines, compare the i950 path. For old panels, keep this drive as a spare.
Confirm cabinet temperature stays under +40 °C, or apply the derating rule.
