E82EV402-4C Lenze 8200 Vector 4.0 kW Inverter with EMC Filter

Product Overview

• Model E82EV402-4C is a Lenze 8200 vector frequency inverter.
• It drives a 4.0 kW motor in the 400 V class.
• Built-in vector control gives stable speed and torque.
• An integrated EMC filter cuts wiring noise.
• A built-in brake transistor saves panel space.
• The unit handles 1.8 x rated torque for 60 s.
• This is a legacy product. Lenze lists it as a previous product.
• Lenze confirms a migration path to the i950 drive.

Technical Data

• Brand
  • Lenze
• Model
  • E82EV402-4C
• Series
  • 8200 vector
• Power section
  • Rated motor power: 4.0 kW (4-pole async motor)
  • Rated output current: 9.5 A at 8 kHz
  • Max output current: 14.2 A for 60 s
  • Output frequency: 0…650 Hz
  • Switching frequency: 2 / 4 / 8 / 16 kHz, 8 kHz default
  • Overload: 1.8 x rated torque for 60 s
• Mains and supply
  • Voltage class: 400 V
  • Supply: 3/PE 320…550 V AC, 45…65 Hz
  • DC supply option: 450…775 V DC
  • Power loss: 180 W at rated current / 8 kHz
• Communication and control
  • Built-in ports: RS232/485 system bus
  • Protocols: Lenze system bus
  • Fieldbus: plug-in modules for PROFIBUS DP, CANopen, DeviceNet, INTERBUS, AS-Interface
  • Slots: 2 control interfaces
• Temperature range
  • Operating: -10…+55 °C
  • Derating: 2.5 %/°C above +40 °C
  • Storage: -25…+60 °C
• Environmental resistance
  • Humidity: average 85 % RH, no condensation
  • Climatic class: 3K3 per EN 50178
  • Protection rating: IP20
• Noise immunity
  • Integrated EMC filter (C0xx base code)
  • Filter limits conducted noise on the mains side
• Physical
  • Dimensions (H x W x D): 240 x 100 x 140 mm
  • Weight: 2.9 kg

Installation Guide

• Mount the drive upright on a flat metal panel.
• Keep IP20 cabinets closed during operation.
• Wire the mains to 3/PE 320…550 V AC.
• Use the integrated EMC filter for clean mains.
• Connect the motor to the rated 9.5 A output.
• Fit the brake resistor to the built-in chopper.
• Derate output 2.5 %/°C above +40 °C.
• Keep the heat sink clear for good airflow.

Setup and Maintenance

• Set motor data with the Lenze keypad or PC tool.
• Default switching frequency is 8 kHz.
• Check fan and heat sink at each service.
• Tighten terminals after the first run.
• Read fault codes on the RS232/485 bus.
• Keep spare plug-in modules on hand.

Compatibility Notes

• Works with 400 V 4-pole async motors.
• Fieldbus options cover PROFIBUS DP, CANopen, DeviceNet, INTERBUS, AS-Interface.
• The i950 can emulate 8200 vector behaviour.
• Use an i950 PROFIBUS module or L_ICIP library.
• No drop-in same-order-code replacement exists.
• The order code uses Lenze short notation.

Certifications and Compliance

• Climatic class 3K3 per EN 50178.
• Integrated EMC filter supports mains noise limits.
• Confirm local approvals before panel build.

Packing List and Warranty

• 1 x Lenze E82EV402-4C inverter
• 1 x quick start guide
• 1 x terminal cover set
• Warranty: 12 months
• Dispatch: 12-24 hours
• Courier: FedEx, UPS, DHL

Expert Review

• The 8200 vector is a proven workhorse.
• Vector control holds torque at low speed.
• The built-in brake chopper saves space.
• The integrated filter cuts install time.
• Plan an i950 migration for new lines.

Manager’s Insight

• Buy this drive to keep existing 8200 vector machines running.
• Stock plug-in modules to avoid downtime.
• Pair each order with an i950 quote for future builds.
• Contact sales@powergearx.com for stock checks.
• Call +86 18030005825 on WhatsApp.

Best Fit Equipment and Applications

• Conveyors and packaging lines
• Pumps and fans with variable load
• Material handling and warehouse systems
• Textile and woodworking machines
• Retrofit of 400 V async motor drives

Buying Guide

• Check motor power: 4.0 kW is the design point.
• Check motor current against 9.5 A.
• Pick fieldbus modules before you order.
• Confirm panel space: 240 x 100 x 140 mm.
• Plan derating above +40 °C.
• Ask about the i950 path for new designs.
• Email sales@powergearx.com for a quote.

FAQ

• Is this drive still in production?
  • No. Lenze lists it as a previous product.
  • The official path is the i950.
• Can I drop in a new drive with the same order code?
  • No. Lenze confirms no same-code replacement.
  • Use the i950 with a PROFIBUS module.
• What motor does it drive?
  • A 4.0 kW 4-pole async motor.
  • Rated output current is 9.5 A.
• Does it have a brake chopper?
  • Yes. The brake transistor is built in.
  • Add a resistor for fast stops.
• How do I add fieldbus?
  • Fit a plug-in communication module.
  • Two control slots are available.
• What is the lead time?
  • We ship in 12-24 hours.
  • Couriers are FedEx, UPS, DHL.
• Experience: my old drive trips in summer. Why?
  • The unit derates 2.5 %/°C above +40 °C.
  • Improve panel airflow first.
• Experience: can I run it from a DC bus?
  • Yes. DC input range is 450…775 V DC.
  • Check polarity and fusing before power-up.
• How do I choose between repair and upgrade?
  • Keep the 8200 vector for existing machines.
  • Choose the i950 for new lines.
• Who do I contact for help?
  • Email sales@powergearx.com.
  • WhatsApp +86 18030005825.
