E82EV222K4C200 Lenze 8200 Vector Drive 5.6 A Brake Chopper

Lenze E82EV222K4C200 – 2.2 kW Vector Frequency Inverter

The Lenze E82EV222K4C200 is a built-in vector-controlled frequency inverter from the 8200 vector series. It delivers reliable motor control for 4-pole asynchronous motors in the 400 V class. This unit suits demanding industrial tasks with 2.2 kW rated power and 5.6 A nominal output current. The factory-set 8 kHz switching frequency keeps operation smooth and quiet. A built-in brake transistor supports fast stops without extra hardware.

Core Technical Data

• Brand: Lenze
• Model: E82EV222K4C200
• Series: 8200 vector
• Rated Motor Power: 2.2 kW typical for 4-pole asynchronous motors
• Rated Output Current: 5.6 A at 8 kHz switching frequency
• Max Output Current: 8.4 A for 60 s periodic load cycles
• Output Frequency Range: 0 to 650 Hz
• Switching Frequency: 2/4/8/16 kHz selectable, 8 kHz factory default
• Mains Voltage Class: 400 V
• Supply Voltage: 3/PE 320 to 550 V AC, 45 to 65 Hz; DC 450 to 775 V alternative
• Power Loss: 130 W at rated current and 8 kHz
• Overload Capacity: 1.8 times rated torque for 60 s
• Integrated Brake Transistor: Yes, built-in chopper up to 11 kW
• Integrated EMC Filter: No, C2xx variant without filter
• Built-in Communication Ports: RS232/485 serial system bus
• Supported Protocols: Lenze system bus; fieldbus via plug-in modules (PROFIBUS DP, CANopen, DeviceNet, INTERBUS, AS-Interface)
• Communication Slots: 2 control interfaces
• Operating Temperature: -10 to +55 °C, derate 2.5%/°C above +40 °C
• Storage Temperature: -25 to +60 °C
• Relative Humidity: Average 85 % RH, no condensation, climatic class 3K3 per EN 50178
• Protection Rating: IP20
• Dimensions (H×W×D): 240 × 60 × 140 mm
• Weight: 1.6 kg
• Lifecycle Status: Legacy product, superseded by newer generations. Official migration path to i950 exists. No drop-in same-order-code replacement.

Installation Guide

• Mount the unit vertically on a flat panel inside a protective enclosure.
• Keep IP20 rating in mind. Use a cabinet with at least IP54 for dusty or wet areas.
• Maintain clearance above and below the heatsink for airflow.
• Connect 3-phase AC supply to L1, L2, L3. Observe terminal labels.
• Wire the motor to U, V, W. Check motor nameplate for correct voltage.
• Use the built-in brake transistor with a suitable external resistor for fast braking.
• Derate output current above +40 °C ambient by 2.5 % per °C.
• For DC supply, use 450 to 775 V DC on the appropriate terminals.
• Tighten all power terminals to the torque stated in the Lenze manual.

Commissioning and Maintenance

• Set motor parameters via the keypad or Lenze software. Match rated current, voltage, and frequency to the motor.
• Select switching frequency (2/4/8/16 kHz) based on acoustic noise and cable length. 8 kHz is the default.
• Use the RS232/485 port for PC-based configuration and diagnostics.
• Check fan and heatsink every 6 months. Clean dust with dry compressed air.
• Verify DC bus capacitors after long storage. Reform them if the unit sat unused for over one year.
• Keep spare plug-in communication modules on hand for fast fieldbus swaps.

Compatibility Notes

• Works with standard 4-pole asynchronous motors up to 2.2 kW at 400 V.
• Plug-in slots accept Lenze communication modules for PROFIBUS DP, CANopen, DeviceNet, INTERBUS, and AS-Interface.
• Fieldbus modules let the inverter join common PLC networks without extra gateways.
• For new projects, Lenze confirms the i950 drive emulates 8200 vector behavior. This helps migration via the i950 PROFIBUS module and L_ICIP library.
• No drop-in replacement with the same order code exists. Plan a migration path for long-term spares.

Certifications and Compliance

• Climatic class 3K3 per EN 50178 for humidity and temperature endurance.
• Designed for industrial EMC environments. An external EMC filter may be needed for Class B or C1 limits.
• IP20 protection for use inside control cabinets.
• Lenze official lifecycle page marks this model as a previous product with a verified migration path.

Expert Review

The E82EV222K4C200 remains a solid choice for legacy 8200 vector systems. Its 1.8× overload for 60 seconds handles demanding starts. The built-in brake chopper saves panel space. The RS232/485 bus and plug-in fieldbus slots give good network flexibility. The main drawback is the legacy status. New designs should consider the i950 series. For existing machines, this unit keeps operations running with a known, verified migration path.

Manager’s Insight

This inverter shines in retrofits. Many plants still run 8200 vector drives on conveyors, mixers, and pumps. Keeping one spare on the shelf cuts downtime. The IP20 housing and compact 1.6 kg frame fit tight cabinets. The 2.2 kW rating covers a wide range of small to medium motors. Stock this model if you service older Lenze installations. Pair it with a plug-in PROFIBUS module for easy PLC integration.

Best Applications and Equipment

• Conveyor belts and material handling systems
• Centrifugal pumps and fans with variable speed needs
• Mixers and agitators in food or chemical plants
• Packaging machines with 4-pole asynchronous motors
• Retrofits of existing 8200 vector drive cabinets
• Test benches needing 0 to 650 Hz output
• Woodworking and textile machinery with moderate overload cycles

FAQ

Q: Does this unit include an EMC filter?

A: No. The C2xx variant ships without an integrated EMC filter. Add an external filter if your site needs Class B emissions.

Q: Can I use a single-phase supply?

A: No. This model needs 3-phase AC or a DC bus supply. Check your mains before ordering.

Q: What is the overload capacity?

A: It delivers 1.8 times rated torque for 60 seconds. That helps with high starting loads.

Q: How do I add PROFIBUS?

A: Use a Lenze plug-in communication module in one of the two slots. The inverter then joins a PROFIBUS DP network.

Q: Is this drive still supported?

A: Lenze lists it as a previous product. The i950 series emulates 8200 vector behavior. Migration is possible, but no drop-in same-order-code replacement exists.

Q: What ambient temperature range is allowed?

A: The unit runs from -10 to +55 °C. Above +40 °C, derate by 2.5 % per °C.

Buying Guide

• Confirm motor power and current. This model fits 2.2 kW and 5.6 A nominal.
• Check your network type. Pick the right plug-in module for PROFIBUS DP, CANopen, or DeviceNet.
• Decide if you need an external EMC filter for your installation site.
• Plan for spare units. Legacy status means limited future availability.
• Review the i950 migration path if your project runs beyond the next few years.
• Order the correct brake resistor if you use the built-in chopper for frequent stops.

Packaging List and Warranty

• 1 × Lenze E82EV222K4C200 frequency inverter
• 1 × printed quick-start guide (where supplied by Lenze)
• Warranty: 12 months from shipment date
• Dispatch time: 12 to 24 hours after payment clears
• Shipping: FedEx, UPS, DHL
