Double-Format PL7 Processor TSXP572823M – Ethernet & Fipio Controller

TSXP572823M – Double-Format PL7 Processor

• Transparent Ready – native Ethernet TCP/IP, Fipio, and serial links.
• Part of Modicon Premium automation platform.
• Designed for PL7 Junior/Pro software environments.
• Dual-format module, 1180 mA @ 5 V DC consumption.
• Supports up to 1024 discrete I/O and 80 analogue I/O.

Technical Specifications

• Brand & Model
  • Schneider Electric / TSXP572823M
• Processor Core
  • Double-format PL7 processor
  • Concept: Transparent Ready
• Memory & Capacity
  • Internal RAM (w/ PCMCIA): 64 Kwords data
  • Internal RAM (w/o PCMCIA): 64 Kwords prog. + data
  • PCMCIA card: 160 Kwords program
  • PCMCIA extra: 2688 Kwords additional data
  • Object areas: 30.5 %MWi, 32 %KWi, 8132 %Mi
• I/O & Channels
  • Discrete I/O: 1024
  • Analogue I/O: 80
  • Application specific channels: 24
  • Process control loops: 10–30 simple loops
• Communication Interfaces
  • Non-isolated serial link (2x mini DIN, 19.2 kbit/s)
  • Fipio manager (127 agents, SUB-D 9)
  • Ethernet TCP/IP (RJ45, 10/100 Mbit/s)
  • Fieldbus modules: 1 (CANopen), 4 AS-Interface
• Performance
  • Boolean execution: 0.19 µs (w/o PCMCIA)
  • Fixed-point: 0.25 µs (w/o PCMCIA)
  • Floating point: 2.6 µs
  • Throughput: 4.76 Kinst/ms (100% Boolean, no card)
• Environmental & Certifications
  • Operating temp: 0…60 °C (32…140 °F)
  • Storage: -25…70 °C (-13…158 °F)
  • Humidity: 10–95% (operation) / 5–95% (storage)
  • Altitude: 0–2000 m
  • IP20, pollution degree 2
  • Certifications: UL 508, CSA, DNV, LR, GL, ABS, BV, RINA, RMRS
  • Standards: IEC 61131-2, 92/31/EEC, 73/23/EEC, 89/336/EEC
• LED Indicators
  • RUN (green), ERR (red), FIP activity (red)
  • Ethernet link (STS yellow), TX/RX (yellow)
  • Terminal port (TER yellow), I/O fault (red)
• Physical
  • Double format, weight: 0.78 kg (1.72 lb)
  • Package: 9.5×18×26 cm, 776 g

Installation & Maintenance

• Mounting – standard DIN rail or panel, double-width slot.
• Wiring – use shielded cables for Fipio and Ethernet.
• Debugging – PL7 Junior/Pro software offers online monitoring.
• LEDs provide real‑time status for quick fault isolation.
• Hot‑swap PCMCIA cards for easy memory upgrades.
• Firmware updates via Ethernet or serial link.

Compatibility

• Works with Modicon Premium racks (4/6/8/12 slots).
• Supports up to 16 racks and 128 slots total.
• Compatible with PL7 Junior, Pro, and Unity Pro (via conversion).
• Fieldbus: CANopen, AS‑Interface, and Fipio.

Certifications & Safety

• CE marked, UL 508, CSA C22.2 No. 213 (Class I, Div 2, Groups A–D).
• Marine approvals: BV, DNV, LR, GL, ABS, RINA, RMRS.
• Complies with IEC 61131-2 and EMC directives.

Package & Warranty

• In the box: processor module, 2x mini DIN connectors, documentation CD.
• 12‑month warranty against manufacturing defects.
• 12‑24 hour dispatch on stock items.
• Shipping: FedEx, UPS, or DHL (tracked express).

Expert Review – Why Choose TSXP572823M?

• “This processor bridges legacy PL7 systems with modern Ethernet architectures.”
• “Its dual‑format design and Transparent Ready feature reduce engineering time.”
• “Ideal for retrofitting existing Premium plants without rewiring.”
• “The 2688 Kwords PCMCIA option gives ample space for complex recipes.”
• “Rugged certifications make it suitable for marine and harsh environments.”

Applications & Suitable Equipment

• Machines: packaging lines, material handling, conveyors.
• Process: mixing, batching, temperature/pressure control.
• Infrastructure: water treatment, HVAC, energy management.
• Works with Modicon M340, M580 via Ethernet gateway.
• Compatible with HMI/SCADA (Vijeo Citect, Wonderware).

Frequently Asked Questions

• • Q: Can I use this processor without a PCMCIA card?
  • A: Yes. Internal RAM provides 64 Kwords for both program and data.
  • Q: Does it support CANopen and AS‑Interface at the same time?
  • A: No. The processor limits to 1 fieldbus module if CANopen is used.
  • Q: What software do I need to program it?
  • A: PL7 Junior or Pro. Unity Pro is possible with a conversion tool.
  • Q: How do I reset the processor?
  • A: Use the reset button or cycle power. Always save project first.
  • Q: Is the Ethernet port isolated?
  • A: No, it is non‑isolated. Use external surge protectors in harsh areas.

• Q: (Experience) The FIP LED stays red – what to check?
• A: Verify termination resistors and cable shielding. Also check bus voltage.
• Q: (Experience) Can I expand memory later?
• A: Yes. Insert a PCMCIA card up to 2688 Kwords without reprogramming.
• Q: (Selection guide) Which PCMCIA size do I need?
• A: For small machines, 160 Kwords is enough. For data‑heavy apps, choose 2688 Kwords.

Selection Guide – Choose the Right PL7 Processor

• For basic discrete control – TSXP572823M with no PCMCIA.
• For analogue + process loops – add PCMCIA 160 Kwords.
• For large data logging – choose 2688 Kwords card.
• If you need CANopen, you cannot use other fieldbus modules.
• For marine/oil&gas – this model has all required class approvals.
