DO571 ABB 3ABD10094783 Digital Output Module | 8 Relay 2A AC/DC

Product Overview

• ▸ ABB DO571 3ABD10094783 – digital output module for S500-eCo PLC system.Controls relays, contactors, and indicators easily.
• ▸ 8 relay outputs – each rated 2A, accepts wide voltage range.Works with 24 V DC, 24 V AC, or 100‑240 V AC loads.
• ▸ Part of AC500-eCo family – compact and cost‑effective automation.Simple installation with IP20 protection for control cabinets.
• ▸ Reliable switching for industrial applications.Perfect for mixed voltage environments.

Key Technical Data

• ▸ Output specifications8 relay outputs, form A (NO)

  Contact rating: 2 A per channel

  Voltage range: 24 V DC, 24 V AC, 100‑240 V AC

  Isolated between channels and logic

• ▸ Power & communicationPowered via S500 backplane

  Compatible with AC500-eCo CPUs

  No external power supply needed

• ▸ ProtectionIP20 enclosure (for cabinet use only)

  Short circuit protection on outputs

• ▸ DiagnosticsLED per channel for output status

  Module status LED

Environmental & Certifications

• ▸ Operating conditionsTemperature: [typical -20 to +55 °C – check manual]

  Humidity: 5‑95% non‑condensing

  Pollution degree 2

• ▸ ComplianceCE marked

  RoHS compliant

  WEEE category: Non- WEEE product

• ▸ MechanicalDimensions: 34×135×75 mm (W×H×D)

  Weight: 0.12 kg net, 0.22 kg gross

  Package: 170×93×63 mm cardboard box

Installation & Setup

• ▸ MountingSnap onto DIN rail in control cabinet

  Width only 34 mm – saves space

• ▸ WiringScrew terminals for field wiring

  Use copper conductors only

• ▸ System integrationConnect to AC500-eCo CPU via backplane

  Configure with Automation Builder or PS501 software

• ▸ Mixed voltage capabilityEach relay can switch different voltages

  Ideal for controlling both DC and AC loads

Diagnostics & Maintenance

• ▸ LED indicatorsGreen LED per channel: output active

  Module power/status LED

• ▸ MaintenanceRelay contacts are replaceable

  No special tools needed

• ▸ TroubleshootingVisual check of LEDs

  Software diagnostics via CPU

Package Contents & Warranty

• ▸ In the box1× ABB DO571 digital output module

  1× product documentation

  Mounting instructions

• ▸ Warranty12 months against defects
• ▸ ShippingFedEx, UPS, DHL worldwide express

Typical Applications

• On/off control of motors and valves
• Lighting control in buildings
• Heater switching in industrial ovens
• Signal lamps and alarms
• Small machine automation

Frequently Asked Questions

• Q: What does “7” in DO571 mean?A: The “7” indicates relay output type with 8 channels. Different numbers (like DO5xx) mean different output types (transistor, triac, etc.).
• Q: Can I mix AC and DC loads on same module?A: Yes. Each relay is independent. You can have 24 V DC on channel 1 and 230 V AC on channel 2. No problem.
• Q: What is the maximum switching current?A: 2 A per channel resistive load. For inductive loads (motors, contactors), use external snubbers or derate to 1 A.
• Q: Is DO571 compatible with AC500 (non-eCo) CPUs?A: Yes, it works with both AC500 and AC500-eCo CPUs. Same backplane compatibility.
• Q: How do I select between DO571 and DO524?A: Choose DO571 for relay outputs (multi-voltage, 2A). Choose DO524 for fast transistor outputs (24 V DC, 0.5A) if you need high-speed switching.
• Q: Does it come with connector included?A: Yes, screw terminal connector is attached. No need to order separately.
