Industrial Vibration Monitoring Solution
Introducing the specialized Bently Nevada 3300 XL 8mm Proximity Probe. This sensor delivers critical machine health data. Model 330104-08-15-10-02-CN features an extended 80mm unthreaded section. It’s designed for challenging deep-mount applications. Protect your turbines, compressors, and pumps with reliable measurements. Need application advice? Contact our engineers: sales@powergearx.com or +86 18030005825.
Key Advantages
- Deep Mount Design: 80mm unthreaded length for thick housings
- Precision Measurement: 2.0mm linear range for accurate gap data
- Robust Construction: Stainless steel case withstands industrial environments
- Global Compatibility: M10x1 metric thread for worldwide use
- Quick Connection: ClickLoc connector ensures secure attachment
- Local Compliance: Country-specific approvals for regulated markets
Product Configuration Details
- Bently Nevada 3300 XL Series
- 330104: 8mm Probe with M10x1 Thread & Armor
- 08: Unthreaded Shank = 80 Millimeters
- 15: Case Length = 150 Millimeters
- 10: Cable Length = 1.0 Meter (3.3 Feet)
- 02: Connector Type = Miniature Coaxial ClickLoc
- CN: Approval = Country Specific Certification
Essential Technical Specifications
- Measurement Performance
- Linear Range: 0.25mm to 2.3mm from target surface
- Optimal Gap Setting: 1.27mm (produces -9 Vdc output)
- Electrical Resistance: 7.59 Ohms ± 0.50 Ohms
- Frequency Response: Suitable for vibration analysis
- Physical Properties
- Probe Tip: Polyphenylene Sulfide (PPS) – Non-conductive
- Probe Body: AISI 303/304 Stainless Steel
- Thread Specification: M10 x 1.0mm metric
- Maximum Thread Engagement: 15mm
- Operating Temperature: -52°C to +177°C standard range
- Environmental Sealing: Viton O-ring for pressure differential
- Certification & Safety
- Approval Type: Country Specific (CN option)
- Hazardous Area Use: Possible with proper barriers
- Compliance: Meets local market requirements
Professional FAQ & Selection Guide
What does the “CN” approval option mean for my application?
The CN designation indicates this probe meets certification requirements for specific countries. This is essential for projects requiring locally approved equipment in regulated markets like industrial plants with strict compliance standards.
How does the 80mm unthreaded length benefit installation?
This extended smooth section allows mounting through thicker machine housings or deep counterbores. It provides flexibility where standard probes cannot reach, ensuring proper sensor placement for accurate measurements.
Can this probe withstand high-pressure environments?
The probe includes a Viton O-ring seal for differential pressure between tip and case. However, probes are not factory pressure tested. For high-pressure applications, consult our technical team for custom testing options.
What maintenance is required for long-term reliability?
These probes require minimal maintenance. Periodically check the gap setting and cable condition. Avoid exposing the probe to temperatures below -34°C to prevent seal damage. Monitor signal stability during routine machine checks.
What shipping and warranty terms apply?
We provide 12-month warranty coverage against manufacturing defects. Orders ship via FedEx, UPS, or DHL with tracking. Delivery times vary by destination. Contact us for specific shipping estimates to your location.
Ordering Information
Ready to purchase 330104-08-15-10-02-CN? Contact our sales team for current pricing and stock availability. We provide technical support to ensure proper sensor selection for your specific application requirements.
