Product details
Product Overview
The Bently Nevada 330104-00-08-05-02-05 is a high-precision 8mm proximity probe. It measures vibration and position on rotating machinery. This sensor helps prevent unexpected machine failures.
Complete Product Specification
- Core Product
- Manufacturer: Bently Nevada
- Base Model: 330104 (3300 XL 8mm Probe, M10x1, Armored)
- Configuration Suffix: 00-08-05-02-05
- 00: Unthreaded Length = 0 mm
- 08: Overall Case Length = 80 mm
- 05: Total Cable Length = 0.5 meter (1.6 feet)
- 02: Connector = Miniature Coaxial ClickLoc
- 05: Approvals = CSA, ATEX, IECEx
- Key Performance Data
- Linear Range: 2.0 mm (from 0.25 mm to 2.3 mm)
- Gap Setting: 1.27 mm for -9 Vdc output
- Probe Resistance: 7.45 Ω ± 0.50 (for 0.5m length)
- Temperature Range: -52°C to +177°C (Operating)
- Thread: M10 x 1.0
- Max Thread Engagement: 15 mm
- Tip Material: PPS (Polyphenylene Sulfide)
- Case Material: AISI 303/304 Stainless Steel
- Seal: Viton® O-ring
Hazardous Area Certifications
- With Safety Barriers (Drawing 141092):
- Class I, Zone 0: AEx/Ex ia IIC T5…T1 Ga
- Suitable for Groups A, B, C, D, E, F, G
- With Non-incendive Circuit (Drawing 140979):
- Class I, Zone 2: AEx/Ex nA IIC T5…T1 Gc
- Class I, Division 2, Groups A, B, C, D
FAQs (Frequently Asked Questions)
What approvals does this specific model have?
This 330104-00-08-05-02-05 holds CSA, ATEX, and IECEx approvals. It is certified for use in hazardous industrial locations worldwide.
Why is the probe cable only 0.5 meters long?
The 0.5m length is for short connections. You extend it with shielded field wiring up to 305 meters to your monitor. This design offers flexible installation.
How does cold weather affect this probe?
Temperatures below -34°C (-30°F) can damage the pressure seal. For very cold environments, check storage and operating conditions carefully.
What does the ‘armor’ in the description mean?
“With armor” means the probe has a robust stainless steel case. It protects the internal components from physical damage in tough plant conditions.
Is this probe ready for pressure testing?
No. Probes are not pressure tested before shipping. The seal uses a Viton® O-ring. Contact Bently Nevada for custom pressure testing if your application needs it.
Ordering & Support Information
- Warranty: All products come with a 12-month warranty.
- Shipping: We ship quickly via FedEx, UPS, and DHL.
- Compatibility: Works with Bently Nevada 3300 XL monitor systems.
Need help or a quote? Contact our team: Email sales@powergearx.com or message us on WhatsApp at +86 18030005825.
