Bently Nevada 3500/94M-03-00-02 10 in VGA Display | ATEX Approved

🖥️ Product highlights

The Bently Nevada 3500/94M-03-00-02 is a 10″ VGA display module for the 3500 monitoring system. It gives clear, real-time machinery data. Panel-mount design with multi-agency approvals. Works with 3500/94M systems and TDI modules.

Need help? sales@powergearx.com or WhatsApp +86 18030005825.

🧩 Model breakdown – 3500/94M-03-00-02

• 3500/94M – VGA display module for 3500 rack
• ⤷ 03 = 10″ display, panel mount (hardware included)
• ⤷ 00 = no KVM extender / display router cables
• ⤷ 02 = Multi-agency approval (CSA/ATEX/IECEx) – only for 10″

⚙️ Technical specifications

• Display
  10″ diagonal LCD · LED backlight · industrial hardened · GFG resistive touch
• Power
  Max 4.6 W · 24 Vdc supply included (accepts 10-28 Vdc) · inrush 3.5 A @ 24 V
• Temperature range
  Operating -20°C to 65°C · storage -40°C to 85°C
• Humidity
  10% to 85% RH non-condensing · 95% for I/O module
• Dimensions (10″)
  387.4 x 248.9 x 49.0 mm · cutout 342.9 x 228.6 mm · weight 4.0 kg
• I/O module
  1 full-height rear slot · VGA port · front port for touch · OK/TX/RX LEDs

📦 What’s included & shipping

• Package contains
  3500/94M monitor module · I/O module · panel mount kit · 24 Vdc power supply · quick start guide
• Warranty
  12 months against defects · full parts & labor
• Shipping
  FedEx, UPS, DHL · fully insured · tracking provided

🔌 Compatibility & requirements

• Required hardware
  3500/22 TDI (Transient Data Interface) module · 1 front slot + 1 rear slot in rack
• Firmware versions (minimum)
  94M: 4.06 Rev C · TDI: 1.71 · Rack Config 5.6 · Op Display 2.21 · Data Acq 1.22

✅ Certifications & compliance

• Hazardous area
  Class I, Div 2 · ATEX/IECEx (option 02) · CE, UL, CUL
• EMC & safety
  EN 61000-6-2/4 · CSA C22.2 61010-1 · UL EN 61010-1 · RoHS
• Protection
  Designed for IP54 front · not NEMA 4X

🏭 Typical applications

• Where to use
  Turbine/generator monitoring · compressor control rooms · panel-mounted HMI for 3500 racks
• Data displayed
  Real-time vibration · shaft position · trend data · system status via high-speed network

❓ Professional FAQ (real‑world experience)

• Q: What is the difference between 3500/94M-03-00-02 and the 15″ Advantech display?
  A: The 94M-03 is a complete 10″ Bently Nevada module with I/O and multi‑agency approvals (ATEX/IECEx). The 15″ Advantech is a separate display (FPM-8151) with wider temp range but no hazardous area certs. For most 3500 racks, the 10″ integrated version is simpler.
• Q: Can I use this display without a TDI module?
  A: No. The 3500/94M requires a 3500/22 TDI module in the same rack. The TDI provides the data link. Check firmware compatibility before ordering.
• Q: Is the touch screen resistive or capacitive?
  A: It uses GFG resistive touch. Works with gloved hands and in industrial environments. Not multi‑touch.
• Q: What does option 02 (Multi) give me?
  A: Option 02 adds CSA/ATEX/IECEx certification for the 10″ display. Required for installation in hazardous areas (Zone 2/Div 2). Without it, the display is general purpose only.
• Q: Can I panel‑mount this in an existing cutout?
  A: Yes, panel mount hardware is included. Cutout size is 342.9 mm x 228.6 mm. Always check dimensions before cutting.
