Bently Nevada 3300 NSv Proximity Probe 330902-00-25-05-01-05 1/4-28 UNF New

Probe Highlights

This Bently Nevada 3300 NSv Proximity Probe (model 330902-00-25-05-01-05) delivers precise vibration and position measurements. It is made in the U.S.A. and comes factory-new. The compact design fits tight installations.

• High reliability: PPS tip and 304 stainless steel case.
• Quick disconnect: Miniature coaxial ClickLoc connector.
• Global use: Multiple agency approvals (suffix 05).
• 12-month warranty against defects.

Model & Suffix Tree

• 330902 – 3300 NSv Probe, 1/4-28 UNF thread, armored
  • 00 – Unthreaded length: 0.0 inch (minimum).
  • 25 – Overall case length: 2.5 inches.
  • 05 – Total length: 0.5 meter (20 inches).
  • 01 – Mini coaxial ClickLoc connector, standard cable.
  • 05 – Multiple approvals (CSA, ATEX, IECEx).
• Cable: 75 Ω coaxial, FEP insulated, 0.5 m long.
• Weight: approx. 14 to 150 g (0.5–5.3 oz).

Electrical & Mechanical Data

• DC resistance (RPROBE): 4.0 Ω ± 0.5 (center to outer conductor).
• Thread size: 1/4-28 UNF.
• Max thread engagement: 0.375 inch.
• Recommended torque: 5.1 N•m (45 in•lb); max 7.3 N•m (65 in•lb).
• Pressure seal: Viton O-ring (differential type). Not pressure tested before shipping.

Temperature & Environment

• Operating/storage temp: -52°C to +177°C (-62°F to +351°F).
• Low temp caution: Sustained exposure below -34°C may damage pressure seal.
• Temperature classifications: T1 to T5 per EPL Ga/Gc; special Dc ratings available (see schedule).
• Tip material: Polyphenylene sulfide (PPS) – chemically resistant.
• Case material: AISI 304 stainless steel.

Installation Essentials

• Mounting torque: tighten to 5.1 N•m (45 in•lb) maximum.
• Thread engagement: do not exceed 0.375 inch.
• Connector: ClickLoc allows fast locking without tools.
• Cable: 0.5 m integral; extension cables available up to 305 m.
• Target gap: set using -9 Vdc output for radial vibration (typical).

Package & Logistics

• Includes: one 3300-nsv-proximity-probe with attached cable and ClickLoc protector.
• Warranty: 12 months from shipment.
• Shipping partners: FedEx, UPS, DHL – tracked and insured.
• Origin: Made in U.S.A.

Frequently Asked Questions (FAQ)

• What is the difference between 3300 NSv and 3300 XL probes?NSv series have a smaller body and 1/4-28 UNF thread, ideal for space-limited machines. XL series use M10 thread and are common in larger turbomachinery.
• Can I use this probe with a 3300 XL Proximitor?Yes, both use the same eddy current principle and output characteristic. Ensure the Proximitor model matches the cable length.
• Why is the resistance 4.0 Ω for 0.5 m cable?Shorter cable has lower resistance. This helps verify probe integrity during troubleshooting.
• Is the probe tip field-replaceable?No. The tip and cable are one sealed assembly. If damaged, replace the entire 3300-nsv-proximity-probe.
• What torque tool do you recommend?Use a precision torque wrench set to 5.1 N•m (45 in•lb). Over-tightening can strip threads or damage the O-ring seal.

Selection Guide

• Need a different cable length? Suffix 05 = 0.5 m. Options also exist for 1, 5, or 7 meters.
• For hazardous areas, suffix 05 includes multiple approvals – suitable for most international zones.
• If your application has sustained low temperature (<-34°C), consider a custom pressure seal.
• Confirm thread type: 1/4-28 UNF (inch). Metric M8 x 1 also available as separate model.
