Bently Nevada 3300 XL 8mm Proximity Probe: Core Overview
The Bently Nevada 3300 XL 8mm proximity probe delivers precise vibration monitoring for industrial machinery. This robust sensor, model 330103-00-07-50-02-00, ensures reliable performance in demanding environments. For technical support, contact sales@powergearx.com or +86 18030005825.
Key Product Specifications
- Brand: Bently Nevada
- Model: 330103-00-07-50-02-00
- Product Type: 3300 XL 8mm Proximity Probes
- Linear Range: 2.0 mm (80 mils) from 0.25 to 2.3 mm
- Recommended Gap: 1.27 mm (50 mils) at -9 Vdc
- Temperature Range: -52°C to +177°C
- Case Material: AISI 303/304 stainless steel
- Thread Size: M10 x 1.0 metric
Detailed Configuration
- Base Model: 330103 (8mm Probe, M10x1)
- Case Length: 07 (70 mm overall)
- Cable Length: 50 (5.0 meters fixed length)
- Connector: 02 (Miniature coaxial ClickLoc)
- Approval: 00 (Standard certification)
Electrical Characteristics
- DC Resistance: 8.73 Ω ± 0.50 at 5.0m
- Wire Size: 0.2 to 1.5 mm² (16-24 AWG)
- Max Cable Run: 305 meters to monitor
- Output Range: Approximately -1 to -17 Vdc
- Thread Engagement: 15 mm maximum
Environmental Ratings
- Operating Temp: -52°C to +177°C
- Extended Temp: Up to +218°C for probe tip
- Humidity: <3% ASF change at 93% RH
- Pressure Seal: Viton O-ring design
- Safety Rating: Class I, Zone 0 compliant
Installation Guidelines
- Set initial gap to 1.27 mm (50 mils)
- Verify output voltage reads approximately -9 Vdc
- Use only with matching 5-meter Proximitor
- Maximum 15 mm thread engagement
- Consult response graphs for long runs
Frequently Asked Questions
What is the probe’s pressure rating?
The probe features a Viton O-ring seal but is not pressure tested before shipment.
Can I cut the 5-meter cable shorter?
No, the cable length is fixed and calibrated for the 5-meter system.
What happens below -34°C?
Temperatures below -34°C may damage the pressure seal.
How do I verify proper installation?
Check the gap setting and output voltage match specifications.
What is the probe tip material?
The tip uses durable Polyphenylene sulfide (PPS).
Shipping Information
- Individually packaged and tested
- Worldwide shipping via FedEx, UPS, DHL
- Includes probe with integrated cable
