Bently Nevada 31000-16-10-15-063-03-02 Proximity Probe Housing

Bently Nevada 31000-16-10-15-063-03-02 Proximity Probe Housing

• Strong build for harsh zones
• Stainless contact areas, PPS body
• Clean cable path and fast install
• 12 months warranty
• FedEx / UPS / DHL shipping

Overview

Stable mount, secure routing, good heat tolerance. Designed to protect probe systems. Made in U.S.A for heavy industry fields.

Contact: sales@powergearx.com / +86 18030005825

Model Tree Structure

31000-16-10-15-063-03-02
 ├─ 16 : 3300 XL 8 mm probe
 ├─ 10 : 1.0 m cable length
 ├─ 15 : 1.5 in standoff adapter
 ├─ 063: 6.3 in penetration
 ├─ 03 : NPT plugs + reducer + cable seal
 └─ 02 : 3/4-14 NPT mounting thread

Key Parameters

• Material: PPS thermoplastic with conductive fibers
• Sleeve: AISI 304 stainless steel
• Exterior Screws: AISI 303 stainless steel
• O-Ring: Neoprene
• Temp Range: -51°C to +105°C
• Rating: CSA Type 4X / IP66
• Weight: 1.2 kg
• Torque: 29.4 N·m

Extra Technical Data

• Dielectric strength: 2.2 kVAC
• Ground path: less than 0.5 Ω
• Seal temperature peak: +210°C
• Cable gland fit: 1/8″ to 3/8″
• Impact verification: 4 J certified / 7 J tested

Warranty & Logistics

• Warranty: 12 months
• Packing: impact-safe industrial box
• Shipping: FedEx / UPS / DHL worldwide

Use Benefits

• Lower interference
• Stable signal gap
• Heat and vibration tolerance
• Service-friendly installation

FAQ

Q: Can this be used near rotating gear rooms?

A: Yes, it handles vibration well when mounted to spec and sealed correctly.

Q: Do I need special thread seal compounds?

A: Normal industrial thread sealants are fine. Do not overtighten.

Q: What is the top mistake during field install?

A: Mis-set O-ring compression leading to small ingress paths.

Q: Can it handle fast maintenance turnover?

A: Yes, sleeve and adapter allow quick removal and reset.

Q: Should calibration follow depth change?

A: Yes, any change in penetration may alter signal spacing.

Order & Support

• Email: sales@powergearx.com
• WhatsApp: +86 18030005825
• Partner: Ubest Automation Limited
