6ES7431-7KF00-6AA0 S7-400 Analog Module Connector | 48-Pole Screw Terminals

Product Overview

• Siemens 6ES7431-7KF00-6AA0 – 48-pole front connector for S7-400 analog modules
  • Specifically designed for module 6ES7431-7KF00-0AB0
  • Features screw-type contacts for secure wiring
  • Includes reference temperature detection capability
  • This connector comes standard with the analog module purchase

Key Technical Specifications

• Brand & Model
  • Brand: Siemens
  • Model: 6ES7431-7KF00-6AA0
  • Series: SIMATIC S7-400
  • Product Type: Front Connector
• Physical Details
  • Pole count: 48-pin connector
  • Contact type: Screw terminals
  • Weight: approx. 100 g
  • Includes: Reference temperature detection
• Compatibility
  • Belongs to product: S7-400 series
  • Designed for: 6ES7431-7KF00-0AB0 analog module
  • Also works with: Other S7-400 analog modules (check pinout)
• Classification Codes
  • eClass 14: 27-24-26-92
  • ETIM 9: EC002584
  • UNSPSC 15: 32-15-17-03
  • IDEA 4: 3552

Expert Review

• Field Engineer’s Insight: This 48-pin connector provides reliable screw termination for S7-400 analog I/O. The reference temperature detection helps with thermocouple cold-junction compensation. Use this connector when replacing damaged wiring or building new panels. Always torque screws to 0.5-0.6 Nm to prevent loose connections. The connector ships as part of the analog module package but buying spares saves downtime.

Compatibility & Applications

• Compatible Systems
  • Siemens SIMATIC S7-400 PLC systems
  • Analog module: 6ES7431-7KF00-0AB0
  • Other S7-400 analog modules with 48-pin interface
• Suitable Applications
  • Analog signal wiring for process automation
  • Temperature sensor connections (thermocouples, RTDs)
  • 4-20 mA and 0-10 V analog input wiring
  • Replacement of damaged or worn connectors

Installation & Maintenance Tips

• Strip wires to 8-9 mm before inserting into screw terminals.
• Torque screws to 0.5-0.6 Nm for reliable connections.
• Use ferrules on stranded wires for better contact.
• Label each wire before removal to avoid reconnection errors.
• Check reference temperature sensor connection for accurate readings.

Package Contents

• 1x Siemens 6ES7431-7KF00-6AA0 front connector
• 48x screw terminals (pre-installed)
• No cables included
• Shipping: 12-24 hour dispatch via FedEx, UPS, or DHL

Compare with Similar Models

• 6ES7431-7KF00-0AB0 – Analog module that uses this connector
• 6ES7492-1AL00-0AA0 – 48-pin connector for S7-400 digital modules
• 6ES7431-1KF10-0AB0 – 8-channel analog input module

Frequently Asked Questions

• Q: Is this connector included with the analog module?
  • A: Yes. Siemens ships the 6ES7431-7KF00-6AA0 connector with the 6ES7431-7KF00-0AB0 module.
• Q: Can I use this connector with other S7-400 modules?
  • A: Yes, but verify pin assignments first. Some modules use different wiring layouts.
• Q: What is the reference temperature detection feature?
  • A: It helps the analog module compensate for cold-junction errors when using thermocouples.
• Q: What wire size fits the screw terminals?
  • A: Use 0.5 to 1.5 mm² (AWG 20-16) stranded or solid wires.
• Q: Do I need this spare connector in my inventory?
  • A: Yes, if you frequently rewire panels or work in harsh environments. It reduces downtime.

Selection Guide

• Order 6ES7431-7KF00-6AA0 for analog module 6ES7431-7KF00-0AB0.
• Need a connector for digital modules? Choose 6ES7492-1AL00-0AA0.
• Need spring terminals instead of screw? Select 6ES7492-1BL00-0AA0.
• Warranty: 12 months against manufacturing defects.
