Name: 330193-00-02-10-05 | Bently Nevada 3300 XL 8mm M10 Thread Probe
SKU: 330193-00-02-10-05
Availability: InStock

Product details

Product Overview

The 330193-00-02-10-05 is a 3300 XL 8 mm Probe from Bently Nevada. It features an M10 x 1 thread and comes without armor. This probe delivers precise vibration and position monitoring for rotating machinery. Built for reliability in tough industrial environments.

Model Number Decoder

330193 — 3300 XL 8 mm Probe, M10 x 1 thread, without armor
- -00 — Unthreaded Length: 0 mm
  - Maximum unthreaded length: 230 mm
  - Minimum unthreaded length: 0 mm
- -02 — Overall Case Length: 20 mm
- -10 — Total Length: 1.0 meter (3.3 feet)
- -05 — Agency Approval: CSA, ATEX, IECEx

Key Technical Data

Brand: Bently Nevada
Model: 330193-00-02-10-05
Series: 3300 XL 8 mm Probe
Thread Type: M10 x 1 (without armor)
Thread Engagement: Maximum 15 mm
DC Resistance: 7.59 ± 0.50 Ω (center to outer conductor)
Tip Material: Polyphenylene sulfide (PPS)
Case Material: AISI 303 or 304 stainless steel
Pressure Seal: Viton® O-ring for differential pressure sealing
Temperature Range: -52°C to +177°C (-62°F to +350°F)
- Extended tip range: -52°C to +218°C
- Extended cable range: -51°C to +260°C
- Note: Below –34°C may damage pressure seal
Humidity Rating: Less than 3% scale factor change after 56 days at 93% RH (IEC 68-2-3)

Hazardous Area Certifications

ia (Intrinsically Safe)
- Class I, Zone 0: AEx/Ex ia IIC T5…T1 Ga
- Class I, Groups A, B, C, D
- Class II, Groups E, F, G
- Class III
- Use with zener barriers (drawing 141092) or galvanic isolators
nA / ec (Nonincendive)
- Class I, Zone 2: AEx/Ex nA IIC T5…T1 Gc
- Class I, Division 2, Groups A, B, C, D
- Class I, Zone 2: AEx/Ex ec llC T5…T1 Gc
- Use with nonincendive circuit per drawing 140979
Temperature Schedule (EPL Ga/Gc)
- T1: -55°C to +232°C
- T2: -55°C to +177°C
- T3: -55°C to +120°C
- T4: -55°C to +80°C
- T5: -55°C to +40°C

Installation & Compatibility

Proximitor: Use with matching Proximitor sensor for 1.0 meter length
Extension Cables: Compatible with
- 330190-045-00-00
- 330190-045-01-05
Mounting: M10 x 1 thread with 15 mm max engagement
Pressure Test: Contact custom design department if seal testing is needed

Manager’s Insight

This probe is a top choice for European-style machinery with M10 threads. The 1.0 meter length suits compact installations. CSA, ATEX, and IECEx approvals make it ready for global hazardous area use. Ideal for gas turbines, centrifugal compressors, and large motors where space is limited but safety is critical.

Expert Review

The M10 x 1 thread simplifies mounting on metric equipment. Without armor, it fits tight spaces easily. The 7.59 Ω resistance provides a clear baseline for field checks. Pair with 330190-045-00-00 or 330190-045-01-05 extension cables for flexible system design. The Viton® seal holds up well under moderate pressure differences.

Frequently Asked Questions (FAQ)

How do I know if this probe fits my machine?Check your mounting thread. This probe uses M10 x 1 thread. Measure the available space. The case length is 20 mm. Total cable length is 1.0 meter.
What approvals does this probe carry?It has CSA, ATEX, and IECEx certifications. These cover Zone 0, Zone 2, and Division 2 hazardous areas.
Is the pressure seal tested before shipping?No. Probes are not pressure tested. Contact our custom design team if your application requires a test.
What is the warranty and shipping policy?We offer 12 months warranty against defects. In-stock items ship within 12-24 hours via FedEx, UPS, or DHL.
Can I use this probe with longer extension cables?Yes. Use compatible extension cables like 330190-045-00-00 or 330190-045-01-05. Ensure total system length matches the Proximitor rating.

Selection Guide

Choose 330193-00-02-10-05 if:
- Your machine has M10 x 1 mounting threads
- You need 1.0 meter total cable length
- Global hazardous area approvals are required (CSA, ATEX, IECEx)
- Armor is not needed for your installation
Choose 330190-045-00-00 if:
- You need a standard extension cable without connector
Choose 330190-045-01-05 if:
- You need a 5.0 meter extension cable with connector for modular setups
