Product details
Overview
This product is the Bently Nevada 330104-00-13-10-01-CN 3300XL8mm Proximity Probe, which is manufactured in the U.S.A. It is designed to seal differential pressure between the probe tip and case. The product is suitable for systems that solely consist of 3300 XL 8 mm components and works well within specific temperature, altitude, and power supply conditions.
Technical Specification
- Brand: Bently Nevada
- Product No.: 330104-00-13-10-01-CN
- Product Type: 3300XL8mm Proximity Probes
- Suffix Meanings:
- 00: Unthreaded Length Option, 00 mm
- 13: Overall Case Length Option, 130 mm
- 10: Total Length Option, 1.0 meter (3.3 feet)
- 01: Miniature coaxial ClickLoc connector with connector protector, standard cable
- CN: Country Specific Approval
- Probe Resistance: For a 1.0 – meter probe, the nominal DC resistance (RPROBE) from center conductor to outer conductor is 7.59 ± 0.50 Ω.
- Probe Tip Material: Polyphenylene sulfide (PPS)
- Probe Case Material: AISI 303 or 304 stainless steel (SST)
- Proximitor Sensor Input: Accepts one non – contacting 3300 – series 5 mm, 3300XL8mm Proximity Probe and Extension Cable.
- Power Supply: Requires – 17.5 Vdc to – 26 Vdc with non – incendive circuit (max 12 mA consumption), – 23 Vdc to – 26 Vdc with barriers.
- Supply Sensitivity: Less than 2 mV change in output voltage per volt change in input voltage.
- Output Resistance: 50 Ω
Contact Information
Contact: For COO requests or pressure seal testing inquiries, email sales@powergearx.com.
For more detailed information: 3300 XL 8 mm Proximity Transducer System Datasheet
