Product Introduction
The 170CPS11100 from Schneider Electric is a dependable power supply adaptor for the Modicon Momentum series. It converts 120 to 230 Volts AC into a stable 24 Volts DC output. This unit ensures reliable operation in diverse industrial environments.
Designed for efficiency, this adaptor supports a wide input voltage range and delivers 0.7 Amperes of current. Its compact design and robust construction make it suitable for various automation tasks. The built-in RUN LED provides clear operational status at a glance.
Key Features & Benefits
- Wide Input Range: Operates with 120 or 230 Volts AC, adjustable via jumper.
- Stable Output: Provides regulated 24 Volts DC at 0.7 Amperes.
- Durable Design: Operates in temperatures from 0 to 60°C and up to 2000 meters altitude.
- Easy Integration: Features a terminal strip connector for straightforward wiring.
- Visual Status: Single RUN LED indicator for quick diagnostics.
- Protection: Built-in fuses rated 0.63A (120V) and 0.315A (230V).
Technical Specifications
- Brand: Schneider Electric
- Model: 170CPS11100
- Product Line: Modicon Momentum
- Type: Processor Adaptor Power Supply
- Input Voltage: 120 to 230 Volts AC (adjustable)
- Output Voltage: 24 Volts DC
- Output Current: 0.7 Amperes
- Frequency: 50 to 60 Hertz
- Operating Temperature: 0 to 60°C
- Storage Temperature: -25 to 70°C
- Humidity Tolerance: 5% to 95% RH (non-condensing)
- Operating Altitude: ≤ 2000 meters (6,561.68 feet)
- Fuse Ratings: 0.63A (120V) / 0.315A (230V)
- Weight: 0.284 kg (0.626 lbs)
- Terminal Type: Terminal strip connector
- Local Signalling: 1 LED (RUN)
Installation & Compatibility
- Mounting: Easily snaps onto standard DIN rails.
- Wiring: Use the terminal strip connector for secure connections.
- Compatibility: Designed for the Modicon Momentum automation platform.
- Applications: Ideal for PLC systems, control panels, and industrial machinery.
Expert Review
Manager’s Insight: “The 170CPS11100 is a workhorse for automation engineers. Its adjustable input and robust output make it a versatile choice. The RUN LED and protective fuses add reliability, reducing downtime. A solid investment for any control cabinet.”
Ideal For
- Modicon Momentum PLC systems
- Industrial automation control panels
- Process control applications
- Factory floor machinery and equipment
Frequently Asked Questions (FAQ)
- What is the input voltage range?
- It supports 120 Volts AC or 230 Volts AC, selectable via an internal jumper.
- What is the output current rating?
- The nominal output current is 0.7 Amperes at 24 Volts DC.
- Is it compatible with other PLC brands?
- This adaptor is specifically designed for the Modicon Momentum series. While it provides standard 24V DC, ensure your system matches the specifications.
- How do I know if the unit is working?
- A green RUN LED on the front panel indicates normal operation.
- Can I use this outdoors?
- It is rated for indoor use only, with an operating temperature range of 0 to 60°C and humidity up to 95% non-condensing.
Selection Guide
- Check your input power: Verify if your system uses 120V or 230V AC.
- Calculate your load: Ensure total current draw does not exceed 0.7A at 24V.
- Environmental factors: Confirm ambient temperature and humidity are within specified limits.
- Space constraints: The compact design fits easily into most cabinets.
Ordering & Shipping
- Warranty: 12 months against manufacturing defects.
- Shipping: Orders ship within 12-24 hours via FedEx, UPS, or DHL.
- Package Contents: 1x 170CPS11100 power supply, terminal connector, and user manual.
- Return Policy: Contact us within 30 days for returns.
