15F5A1E-35GA KEB Combivert F5 | 11kW 400V Inverter with Brake & TTL Encoder

15F5A1E-35GA – KEB Combivert F5

17 kVa / 400V / 24.0A / 11.0 kW | AC/DC, 3Ph

• 15F5A1E-35GA is a controlled frequency inverter.
• Runs on 400V AC, 3-phase input.
• Delivers 11 kW motor power at 50/60 Hz.
• Includes brake transistor GTR7 and air cooling.
• Encoder type: TTL-IN (dual channel).

Technical Specifications

• Brand: KEB
• Series: Combivert F5
• Model: 15F5A1E-35GA
• Power (kVA): 17 kVA
• Motor Power: 11 kW (2/4P, 50/60Hz)
• Input Voltage: 305–528V AC 3PH
• Output Voltage: 0 to Uin
• Rated Current: 24.0 A
• Short-time Limit: 36.0 A (max.)
• Max Frequency: 599 Hz
• Switching Freq: 4 kHz
• Protection: IP20
• Dimensions (W×H×D): 130 × 290 × 208 mm
• Cooling: Air-cooled heat sink

Installation & Maintenance

• Mount vertically – allow 100 mm clearance for airflow.
• Use shielded motor cables for noise reduction.
• Check cooling fan every 6 months.
• Keep ambient temperature below 50 °C.

Compatibility & Certifications

• Works with standard 3-phase AC motors.
• CE marked and UL recognized.
• RoHS compliant.

Package Contents

• 1 × 15F5A1E-35GA inverter
• Quick start guide (printed)
• Warranty card

Warranty: 12 months. Ships in 12–24 hours via FedEx, UPS, or DHL.

Manager’s Insight

• “This F5 unit gives great torque control at low speeds.”
• “The built-in brake transistor saves external hardware.”
• “Ideal for cranes and hoists with high starting torque.”

Applications & Compatible Devices

• Conveyors, mixers, and extruders.
• Hoisting and lifting equipment.
• Pumps and fans with variable speed.
• Machine tools and textile machinery.

Professional FAQs

• Q: What motor types can this drive?
• A: Standard 3-phase induction motors up to 11 kW.
• Q: Is an external brake resistor needed?
• A: No, the GTR7 transistor handles internal braking.
• Q: Can I run it on 480V?
• A: Yes, input range goes to 528V AC.
• Q: What is the max output frequency?
• A: 599 Hz – suitable for high-speed spindles.
• Q: Does it support encoder feedback?
• A: Yes, dual TTL-IN encoder inputs are built-in.

Experiential Q&A & Selection Guide

• Q: Which model for a 15 kW motor?
• A: This 11 kW unit is for smaller loads – choose higher model.
• Q: How to reduce EMI in installation?
• A: Use shielded cables and a line filter.
• Q: Can I parallel two units?
• A: Not recommended – use a single larger drive.

Selection Guide:

• Pick 15F5A1E-35GA for 11 kW, 400V applications.
• Choose it if you need TTL encoder and brake transistor.
• For higher power, check KEB F5 22 kW models.

Compare with:
KEB F5 15F5A1E-25GA |
KEB F5 15F5A1E-45GA |
KEB F5 22kW variant
